The OPA623 is a current-feedback operational ampli-
fier designed for precision wide-bandwidth systems
including high-resolution video, RF and IF circuitry,
and communications equipment.
The new circuit design, together with the complemen-
tary bipolar process, achieves performance pre-
viously unattainable in monolithic integrated circuit
technology.
The current-feedback op amp is optimized for wide
bandwidth, excellent pulse response, gain flatness,
low distortion, and operation at a low quiescent cur-
rent of
±4mA.
It provides a 350MHz large-signal bandwidth at
2.8Vp-p output voltage, as well as a 2100V/µs slew
rate. The gain flatness of 0.05dB over a 30MHz
bandwidth makes it suitable for HDTV designs. An-
other feature of the op amp is its high output current
of
±70mA,
enabling it to drive two back-terminated
75Ω cables when using the amplifier as a line driver in
video routers, distribution amplifiers, and analog and
digital communications equipment.
The OPA623 operates from a
±5V
supply, is speci-
fied for the extended industrial temperature range
(–40°C to +85°C), and is available in plastic SO-8
and 8-pin plastic DIP packages.
LARGE SIGNAL PULSE RESPONSE
+2.5V
Output voltage
OV
–2.5V
Output Voltage - 5Vp-p, 5ns/DIV
R
IN
V
IN
= 2.5Vp-p
180Ω
+V
CC
3
2
7
OPA623
6
V
OUT
= 5.0Vp-p
–V
CC
4
R
2
R
1
300
Ω
300Ω
G = 1 + R
2
/R
1
= +2V/V
International Airport Industrial Park • Mailing Address: PO Box 11400, Tucson, AZ 85734 • Street Address: 6730 S. Tucson Blvd., Tucson, AZ 85706 • Tel: (520) 746-1111 • Twx: 910-952-1111
The information provided herein is believed to be reliable; however, BURR-BROWN assumes no responsibility for inaccuracies or omissions. BURR-BROWN
assumes no responsibility for the use of this information, and all use of such information shall be entirely at the user’s own risk. Prices and specifications are subject
to change without notice. No patent rights or licenses to any of the circuits described herein are implied or granted to any third party. BURR-BROWN does not
authorize or warrant any BURR-BROWN product for use in life support devices and/or systems.
®
OPA623
2
SPECIFICATIONS
AC-SPECIFICATION
At V
CC
=
±5VDC,
I
Q
=
±4mA,
R
L
= 100Ω, R
IN
= 210Ω, and T
AMB
= +25°C, unless otherwise specified.
OPA623AP, AU
PARAMETER
FREQUENCY DOMAIN
Large Signal
Closed-Loop Bandwidth (–3dB)
V
O
= 2.8Vp-p, Gain = +1V/V
V
O
= 2.8Vp-p, Gain = +2V/V
V
O
= 2.8Vp-p, Gain = +5V/V
V
O
= 2.8Vp-p, Gain = +10V/V
V
O
= 2.8Vp-p, Gain = –1V/V
V
O
= 2.8Vp-p, Gain = –2V/V
V
O
= 5.0Vp-p, Gain = +2V/V
V
O
= 0.2Vp-p, Gain = +2V/V
Pin 3 to Pin 6, Gain = +2V/V
G = +2V/V, f = 4.43MHz, R
L
= 150Ω
V
O
= +1.4V
G = +2V/V, f = 4.43MHz, R
L
= 150Ω
V
O
= +1.4V
Gain = +2V/V
f = 10MHz, V
O
= 2.0Vp-p
f = 30MHz, V
O
= 2.0Vp-p
f = 50MHz, V
O
= 2.0Vp-p
Gain = +2V/V
V
O
= 2.0Vp-p, DC to 30MHz
V
O
= 2.0Vp-p, DC to 100MHz
340
350
260
210
360
330
240
290
1.2
0.12
0.05
–56
–59
–30
–37
–30
–33
0.05
0.20
MHz
MHz
MHz
MHz
MHz
MHz
MHz
MHz
ns
%
Degrees
dBc
dBc
dBc
dBc
dBc
dBc
dB
dB
CONDITIONS
MIN
TYP
MAX
UNITS
SMALL SIGNAL BANDWIDTH
GROUP DELAY TIME
DIFFERENTIAL GAIN
DIFFERENTIAL PHASE
HARMONIC DISTORTION
Second Harmonic
Third Harmonic
Second Harmonic
Third Harmonic
Second Harmonic
Third Harmonic
GAIN FLATNESS PEAKING
TIME DOMAIN
Rise Time
Gain = +2V/V, 10% to 90%
V
O
= 2.0Vp-p
V
O
= 5.0Vp-p
Gain = +2V/V, 10% to 90%
V
O
= 2.0Vp-p
V
O
= 5.0Vp-p
Gain = +2V/V, Rise Time = 1ns
V
O
= 0.2Vp-p
V
O
= 5.0Vp-p
Gain = +2V/V, Rise Time = 2ns
V
O
= 2V
p-p
, 0.1%
1.4
1.9
1.4
2.6
140
2100
9
ns
ns
ns
ns
V/µs
V/µs
ns
Fall Time
SLEW RATE
SETTLING TIME
PIN CONFIGURATION
Top View
NC
–In
+In
–V
CC
1
2
3
4
8
7
6
5
NC
+V
CC
Out
NC
DIP/SO-8
ELECTROSTATIC
DISCHARGE SENSITIVITY
This integrated circuit can be damaged by ESD. Burr-Brown
recommends that all integrated circuits be handled with
appropriate precautions. Failure to observe proper handling and
installation procedures can cause damage.
ESD damage can range from subtle performance degradation to
complete device failure. Precision integrated circuits may be more
susceptible to damage because very small parametric changes
could cause the device not to meet its published specifications.
PACKAGE/ORDERING INFORMATION
PACKAGE
DRAWING
NUMBER
(1)
006
182
TEMPERATURE
RANGE
–40°C to +85°C
–40°C to +85°C
ABSOLUTE MAXIMUM RATINGS
Power Supply Voltage .........................................................................
