P4SMA85A

Description
400 W, UNIDIRECTIONAL, SILICON, TVS DIODE
CategoryDiscrete semiconductor    diode
File Size948KB,4 Pages
ManufacturerCentral Semiconductor
Download Datasheet Parametric View All

P4SMA85A Overview

400 W, UNIDIRECTIONAL, SILICON, TVS DIODE

P4SMA85A Parametric

Parameter NameAttribute value
Is it lead-free?Contains lead
Is it Rohs certified?incompatible
MakerCentral Semiconductor
package instructionSMA, 2 PIN
Contacts2
Reach Compliance Codeunknow
ECCN codeEAR99
Maximum breakdown voltage108.2 V
Minimum breakdown voltage94.4 V
Breakdown voltage nominal value101.3 V
Maximum clamping voltage137 V
ConfigurationSINGLE
Diode component materialsSILICON
Diode typeTRANS VOLTAGE SUPPRESSOR DIODE
JESD-30 codeR-PDSO-C2
JESD-609 codee0
Maximum non-repetitive peak reverse power dissipation400 W
Number of components1
Number of terminals2
Maximum operating temperature150 °C
Minimum operating temperature-65 °C
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formSMALL OUTLINE
Peak Reflow Temperature (Celsius)NOT SPECIFIED
polarityUNIDIRECTIONAL
Certification statusNot Qualified
Maximum repetitive peak reverse voltage85 V
surface mountYES
technologyAVALANCHE
Terminal surfaceTin/Lead (Sn/Pb)
Terminal formC BEND
Terminal locationDUAL
Maximum time at peak reflow temperatureNOT SPECIFIED
P4SMA5.0A
THRU
P4SMA220A
SURFACE MOUNT SILICON
UNI-DIRECTIONAL
GLASS PASSIVATED JUNCTION
TRANSIENT VOLTAGE SUPPRESSORS
400 WATT, 5.0 THRU 220 VOLT
w w w. c e n t r a l s e m i . c o m
DESCRIPTION:
The CENTRAL SEMICONDUCTOR P4SMA5.0A
series types are surface mount, uni-directional, glass
passivated junction transient voltage suppressors
designed to protect sensitive components from high
voltage transients.
MARKING CODE: SEE MARKING CODE ON
ELECTRICAL CHARACTERISTICS TABLE
SMA CASE
MAXIMUM RATINGS:
(TA=25°C)
Peak Power Dissipation (Note 1)
Peak Forward Surge Current (JEDEC method)
Operating and Storage Junction Temperature
Typical Thermal Resistance (Note 2)
ELECTRICAL CHARACTERISTICS:
(TA=25°C)
REVERSE
STAND-OFF
VOLTAGE
VRWM
V
P4SMA5.0A
P4SMA6.0A
P4SMA6.5A
P4SMA7.0A
P4SMA7.5A
P4SMA8.0A
P4SMA8.5A
P4SMA9.0A
P4SMA10A
P4SMA11A
P4SMA12A
P4SMA13A
P4SMA14A
P4SMA15A
P4SMA16A
P4SMA17A
P4SMA18A
P4SMA20A
P4SMA22A
P4SMA24A
P4SMA26A
P4SMA28A
P4SMA30A
P4SMA33A
P4SMA36A
P4SMA40A
5.0
6.0
6.5
7.0
7.5
8.0
8.5
9.0
10
11
12
13
14
15
16
17
18
20
22
24
26
28
30
33
36
40
BREAKDOWN
VOLTAGE
VBR
MIN
V
6.40
6.67
7.22
7.78
8.33
8.89
9.44
10.0
11.1
12.2
13.3
14.4
15.6
16.7
17.8
18.9
20.0
22.2
24.4
26.7
28.9
31.1
33.3
36.7
40.0
44.4
@
IT
MAX
V
7.25
7.67
8.30
8.95
9.58
10.23
10.82
11.5
12.8
14.0
15.3
16.5
17.9
19.2
20.5
21.7
23.3
25.5
28.0
30.7
33.2
35.8
38.3
42.2
46.0
51.1
TEST
CURRENT
IT
mA
10.0
10.0
10.0
10.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
MAXIMUM
REVERSE
LEAKAGE
CURRENT
IR @ VRWM
μA
800
800
500
200
100
50
10
5.0
5.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
MAXIMUM
CLAMPING
VOLTAGE
VC @ IPP
V
9.2
10.3
11.2
12.0
12.9
13.6
14.4
15.4
17.0
18.2
19.9
21.5
23.2
24.4
26.0
27.6
29.2
32.4
35.5
38.9
42.1
45.4
48.4
53.3
58.1
64.5
PEAK
PULSE
CURRENT
(Note 1)
IPP
A
43.5
38.8
35.7
33.3
31.0
29.4
27.7
26.0
23.5
22.0
20.1
18.6
17.2
16.4
15.3
14.5
13.7
12.3
11.2
10.3
9.5
8.8
8.3
7.5
6.9
6.2
C4HE
C4HG
C4HK
C4HM
C4HP
C4HR
C4HT
C4HV
C4HX
C4HZ
C4IE
C4IG
C4IK
C4IM
C4IP
C4IR
C4IT
C4IV
C4IX
C4IZ
C4JE
C4JG
C4JK
C4JM
C4JP
C4JR
SYMBOL
PPK
IFSM
TJ, Tstg
Θ
JA
400
40
-55 to +150
70
UNITS
W
A
°C
°C/W
TYPE
MARKING
CODE
Notes: (1) Non-repetitive 10x1,000μs pulse.
(2) FR-4 epoxy PCB with copper mounting pad area of 5mm
2
.
R1 (18-March 2013)
