Solid State Devices, Inc.
14701 Firestone Blvd * La Mirada, Ca 90638
Phone: (562) 404-4474 * Fax: (562) 404-1773
ssdi@ssdi-power.com * www.ssdi-power.com
SSR4010/3
40 AMPS
100 VOLTS
SCHOTTKY
RECTIFIER
TO-3
Designer’s Data Sheet
FEATURES:
PIV: 100 Volts
Low Forward Voltage Drop
Low Reverse Leakage
Hermetically Sealed Package
Guard Ring for Overvoltage Protection
Available in Isolated and Non-isolated
versions
Eutectic Die Attach
175
°
C Operating Junction Temperature
TX, TXV, and Space Level Screening
Available
•
•
•
•
•
•
•
•
•
MAXIMUM RATINGS
Peak Repetitive Reverse Voltage
and DC Blocking Voltage
SSR4010/3
Symbol
V
RRM
V
RWM
V
R
I
O
I
FSM
T
OP
& Tstg
R
θJC
Value
100
40
400
-65 to +175
0.6
Units
Volts
Amps
Amps
°
°
Average Rectified Forward Current
1/
(Resistive Load, 60 Hz, Sine Wave, T
A
=25
°
C)
Peak Surge Current
1/
(8.3 ms Pulse, Half Sine Wave Superimposed on I
O
, allow junction to
reach equilibrium between pulses, T
A
=25
°
C)
Operating and Storage Temperature
Maximum Thermal Resistance
1/
Junction to Case
Notes:
1/
Both Legs Tied Together.
C
C/W
NOTE:
All specifications are subject to change without notification.
SCD's for these devices should be reviewed by SSDI prior to release.
DATA SHEET #: RS0103C
DOC
Solid State Devices, Inc.
14701 Firestone Blvd * La Mirada, Ca 90638
Phone: (562) 404-4474 * Fax: (562) 404-1773
ssdi@ssdi-power.com * www.ssdi-power.com
SSR4010/3
Symbol
I
F
= 10 Amps
I
F
= 20 Amps
I
F
= 40 Amps
V
F1
V
F2
V
F3
V
F4
I
R1
I
R2
C
J
ELECTRICAL CHARACTERISTICS
Instantaneous Forward Voltage Drop
(T
A
= 25
°
C, Pulse)
Instantaneous Forward Voltage Drop
(I
F
= 20 Amps, T
A
= -55
°
C, Pulse)
Reverse Leakage Current
(Rated V
R
, T
A
= 25
°
C, Pulse)
Reverse Leakage Current
(Rated V
R
, T
A
= 100
°
C, Pulse)
Junction Capacitance
(V
R
=10 V
DC
, T
A
= 25
°
C, f = 1 MHz)
CASE OUTLINE:
Max
0.7
0.77
0.90
0.89
400
20
1,600
Unit
Volts
Volts
µA
mA
pF
TO-3
PIN OUT:
CASE: CATHODE
PIN 1: ANODE
PIN 2: ANODE
.
NOTE:
All specifications are subject to change without notification.
SCD's for these devices should be reviewed by SSDI prior to release.
DATA SHEET #: RS0103C
DOC
