C0402JB1A472M020BC
TDK Item Description : C0402JB1A472MT****
DC Bias Characteristic
Application & Main Feature
Cap. Change/%
10
0
-10
-20
-30
-40
-50
0
2
4
6
8
10
12
Commercial Grade ( General (Up to 50V) )
Series
C0402 [EIA CC01005]
DC Bias/V
Dimensions
L
W
T
B
G
Cap. Change/%
|Z|, ESR/ohm
0.40mm
0.20mm
0.20mm
0.07mm
0.14mm
+/-0.02mm
+/-0.02mm
+/-0.02mm
Min.
Min.
|Z|, ESR vs. Freq. Characteristics
1000000
100000
10000
1000
100
10
1
0.1
0.001
0.01
0.1
1
10
100
1000
20
10
0
-10
-20
-30
-40
-50
-60
-70
-80
-90
-40
-20
Temperature Characteristic
Temperature Characteristic
Characterization Sheet ( Multilayer Ceramic Chip Capacitors )
JB (-25 to 85 degC +/-10%)
1A (10Vdc)
4.7nF
Rated Voltage
Capacitance
0
20
40
60
80
100
Frequency/MHz
|Z|
ESR
Temperature/degC
Temp.Chara.
TCBias(1/2Rated)
Capacitance Tolerance
M (+/-20%)
10% Max.
10
Cap. vs. Freq. Characteristic
6
Ripple Temperature Rise Characteristic
Temperature Rise/degC
5
4
3
2
1
0
0
0.02
0.04
0.06
0.08
0.1
0.12
Dissipation Factor
Insulation Resitance
10Gohm Min.
Cap./nF
1
0.001
0.01
0.1
1
10
100
1000
AEC-Q200
Not Applicable
Frequency/MHz
Current/Arms
100kHz
500kHz
1MHz
