ALUMINUM ELECTROLYTIC CAPACITORS
BC
Chip Type , High Temperature Range,
Vibration Resistance
series
Highly dependable reliability withstanding load life of
1000 hours at +150
°C.
Suited for automobile electronics where heavy duty
services are indispensable.
Compliant to the RoHS directive (2011/65/EU).
BC
High
Temperature
UE
Specifications
Item
Category Temperature Range
Rated Voltage Range
Rated Capacitance Range
Capacitance Tolerance
Leakage Current
Performance Characteristics
– 40 to +150°C
(
φ
8
to
10),
– 55 to +150°C
(
φ
12.5
to
18)
10 to 50V
33 to 3300µF
± 20% at 120Hz, 20°C
After 1 minute's application of rated voltage, leakage current is not more than 0.03CV or 4 (µA), whichever is greater.
Rated voltage (V)
10
0.26
0.22
16
0.20
0.18
25
0.16
0.16
35
0.14
0.14
50
0.14
0.12
120Hz 20
°C
tan
δ
(MAX.)
Tangent of loss angle (tan
δ)
φ
8
•
φ
10
φ
12.5
to
φ
18
For capacitance of more than 1000µF, add 0.02 for every increase of 1000µF.
Rated voltage (V)
Stability at Low Temperature
Impedance ratio
Z
–
40°C / Z+20°C
(MAX.)
10
16
25
35
50
120Hz
φ
8
•
φ
10
10
8
8
6
6
4
Capacitance change
tan
δ
Leakage current
4
4
4
4
φ
12.5
to
φ
18
Endurance
The specifications listed at right shall be met when the
capacitors are restored to 20°C after the rated voltage is
applied for 1000 hours at 150°C.
Within ±30% of the initial capacitance value
300% or less than the initial specified value
Less than or equal to the initial specified value
Shelf Life
Marking
After storing the capacitors under no load at 150°C for 1000 hours and then performing voltage treatment based on JIS C 5101-4
clause 4.1 at 20°C, they shall meet the specified values for the endurance characteristics listed above.
Black print on the case top.
Chip Type
(φ8 to
φ10)
0.5 MAX.
Voltage( A : 10V )
Lot N0.
Type numbering system (Example : 10V 220
µ
F)
Plastic platform
Series
1
2
3
4
5
6
7
8
9
10 11 12 13 14
Package code
0.3 MAX.
C±0.2
UBC 1 A 2 2 1 M NS 1 GS
A
±
0.2
φ8
to 10
φ12.5
to 18
φ12.5
to 18
Taping
Taping
Tray
GS
MS
ZD
Size code
Trade mark
A2
220A
BC
φ
D±0.5
B±0.2
E
A
±
0.2
Configuration
Capacitance Tolerance (
±20%
)
Rated capacitance (220µF)
Rated voltage (10V)
Series name
Type
(mm)
8
2.9
8.3
8.3
3.1
10
3.2
10.3
10.3
4.5
12.5
4.8
13.6
13.6
4.0
16
5.4
17.1
17.1
6.3
18
6.4
19.1
19.1
6.3
Capacitance
L±1.0
φD
8 to 18
Code
NS
Pressure relief vent
H
(φ12.5 to
φ18)
Trade mark
Voltage
Lot N0.
Plastic platform
0.3MAX.
C
±
0.2
0.5MAX.
A
±
0.2
φ
D
A
B
C
E
H
φD ±
0.5
100
µF
BC 50V
H1015
nichicon
B
±
0.2
E
A
±
0.2
Series
Capacitance
L±1.0
Pressure relief vent
1.1 to 1.5 1.1 to 1.5 1.0 to 1.4 1.0 to 1.4 1.0 to 1.4
H
Aid electrode
Dimensions
V
Cap.(µF)
Code
10
1A
16
1C
25
1E
8
×
10
35
1V
8
×
10
80
120
550
650
750
950
1150
10
×
10
50
1H
70
100
420
550
650
850
1100
Rated
ripple
33
47
100
220
330
470
680
1000
2200
3300
330
470
101
221
331
471
681
102
222
332
8
×
10
8
×
10
10
×
10
12.5
×
13.5
12.5
×
13.5
18
×
21.5
18
×
21.5
110
150
12.5
×
13.5
800
900
1350
1400
12.5
×
13.5
16
×
16.5
18
×
21.5
10
×
10
110
150
750
800
850
1350
8
×
10
10
×
10
12.5
×
13.5
12.5
×
13.5
16
×
16.5
16
×
21.5
110
150
650
700
800
1000
10
×
10
12.5
×
13.5
12.5
×
13.5
16
×
16.5
16
×
21.5
18
×
21.5
12.5
×
13.5
16
×
16.5
16
×
21.5
16
×
21.5
18
×
21.5
Case size
φ
D
×
L (mm)
Rated ripple current (mArms) at 150°C 100kHz
Frequency coefficient of rated ripple current
Frequency
Coefficient
120 Hz
0.67
300 Hz
0.79
1 kHz
0.91
10kHz or more
1.00
Taping specifications are given in page 23.
Recommended land size, soldering by reflow are given
in page 18, 19.
Please refer to page 3 for the minimum order quantity.
CAT.8100C
