TAZ Series
CWR09 - MIL-PRF-55365/4
Fully qualified to MIL-PRF-55365/4,
this series represents the most flexible
of surface mount form factors, offering
eight case sizes (A through H). This
series is fully interchangeable with
CWR06 conformal types, while offering
the advantages of molded body/
compliant termination construction,
polarity and capacitance. The molded
construction is compatible with a wide
range of SMT board assembly
processes including wave or reflow
solder, conductive epoxy or compres-
sion bonding techniques. The five smaller
cases are characterized by their low
profile construction, with the A case
being the world’s smallest molded mili-
tary tantalum. There are three termination
finishes available: fused solder plated (“K”
per MIL-PRF-55365), hot solder dipped
(“C”) and gold plated (“B”). In addition,
the molding compound has been select-
ed to meet the requirements of UL94V-0
and outgassing requirements of NASA
SP-R-0022A.
CASE DIMENSIONS:
Case Length (L)
Width (W)
Height (H)
Code ±0.38 (0.015) ±0.38 (0.015) ±0.38 (0.015)
A
B
2.54 (0.100)
3.81 (0.150)
5.08 (0.200)
3.81 (0.150)
5.08 (0.200)
5.59 (0.220)
6.73 (0.265)
7.24 (0.285)
1.27 (0.050)
1.27 (0.050)
1.27 (0.050)
2.54 (0.100)
2.54 (0.100)
3.43 (0.135)
2.79 (0.110)
3.81 (0.150)
1.27 (0.050)
1.27 (0.050)
1.27 (0.050)
1.27 (0.050)
1.27 (0.050)
1.78 (0.070)
Term. Width (W
1
)
1.27±0.13
(0.050±0.005)
1.27±0.13
(0.050±0.005)
1.27±0.13
(0.050±0.005)
2.41+0.13/-0.25
(0.095+0.005/-0.010)
2.41+0.13/-0.25
(0.095+0.005/-0.010)
millimeters (inches)
Term. Length (A)
±0.13 (0.005)
0.76 (0.030)
0.76 (0.030)
0.76 (0.030)
0.76 (0.030)
0.76 (0.030)
0.76 (0.030)
1.27 (0.050)
1.27 (0.050)
S min
1.80 (0.071)
1.65 (0.065)
2.92 (0.115)
1.65 (0.065)
2.92 (0.115)
3.43 (0.135)
3.56 (0.140)
0.70 (0.028)
MARKING
(White marking on black body)
Polarity Stripe (+)
C
D
E
F
Capacitance Code
Rated Voltage
G
H
3.30±0.13
(0.130±0.005)
2.67±0.13
2.79 (0.110)
(0.105±0.005)
3.68+0.13/-0.51
2.79 (0.110) (0.145+0.005/-0.020)
HOW TO ORDER
CWR09
J
^
225
*
@
+
Type
Voltage
Code
C = 4Vdc
D = 6Vdc
F = 10Vdc
H = 15Vdc
J = 20Vdc
K = 25Vdc
M = 35Vdc
N = 50Vdc
Termination
Finish
K = Solder Fused
C = Hot Solder
Dipped
B = Gold Plated
Capacitance
Code
pF code:
1st two digits
represent
significant
figures 3rd digit
represents
multiplier
(number of zeros
to follow)
Capacitance
Tolerance
M = ±20%
K = ±10%
J = ±5%
Reliability
Grade
Weibull: B =
0.1%/1000 Hrs.
(90% C =
0.01%/1000
Hrs. conf.)
Comm: Z =
Non ER
Surge Test
Option
A = 10 cycles,
+25°C
B = 10 cycles,
-55°C &
+85°C
C = 10 cycles,
-55°C &
+85°C
before
Weibull
Packaging
Bulk = Standard
\TR = 7" T&R
\TR13 = 13" T&R
\W = Waffle
TECHNICAL SPECIFICATIONS
Technical Data:
Capacitance Range:
Capacitance Tolerance:
Rated Voltage: (V
R
)
Category Voltage: (V
C
)
Surge Voltage: (V
S
)
Temperature Range:
Unless otherwise specified, all technical
0.1 μF to 100 μF
±5%; ±10%; ±20%
4
6
10
15
2.7
4
7
10
5.2
8
13
20
3.4
5
8
13
-55°C to +125°C
data relate to an ambient temperature of 25°C
85°C:
125°C:
85°C:
125°C:
20
13
26
16
25
17
32
20
35
23
46
28
50
33
65
40
57
