ZXTEM322 Overview

80V NPN LOW SATURATION TRANSISTOR

ZXTEM322
MPPS
TM
Miniature Package Power Solutions
80V NPN LOW SATURATION TRANSISTOR
SUMMARY
NPN —- V
CEO
= 80V; R
SAT
=
68m ; I
C
= 3.5A
DESCRIPTION
Packaged in the new
innovative 2mm x 2mm MLP (Micro Leaded
Package)
outline, these new 4
th
generation low saturation dual PNP transistors offer
extremely low on state losses making them ideal for use in DC-DC circuits and
various driving and power management functions.
Additionally users gain several other
key benefits:
Performance capability equivalent to much larger packages
Improved circuit efficiency & power levels
PCB area and device placement savings
Lower Package Height (0.9mm nom)
Reduced component count
MLP322
FEATURES
Low Equivalent On Resistance
Extremely Low Saturation Voltage
(185mV max @1A)
h
FE
specified up to 5A
I
C
=-3.5A Continuous Collector Current
2mm x 2mm MLP
APPLICATIONS
DC - DC Converters
DC - DC Modules
Power switches
Motor control
ORDERING INFORMATION
DEVICE
ZXTEM322TA
ZXTEM322TC
REEL
SIZE
7”
13”
TAPE
WIDTH
8mm
8mm
QUANTITY
PER REEL
3000
10000
Underside View
DEVICE MARKING
SE
ISSUE 2 - JUNE 2006
1
SEMICONDUCTORS
