5,2
8,4
6,1
PCB
0,6
2,54
0,92
4 x 2,54 = 10,16
7,62
12
8,64
M4
M 2:1
Leiterplattenbohrbild
PCB drillhole pattern
4 x 2,54 = 10,16
0,7
2,54
0,7
7,62
1,4
Dieser Bereich muß gleiches Potential
auf der LP-Oberfläche haben
This area must have same electrical
potential on surface of PCB
0,05
alle Löcher/
1
±0,1
all holes
Copyright by ERNI GmbH
Proprietary notice pursuant to ISO 16016 to be observed.
Information:
Tolerances
All Dimensions
in mm
Scale
5:1
All rights reserved.
Only for Information.
To ensure that this is the latest
version of this drawing, please
contact one of the ERNI companies
before using.
a
Index
07.07.2011
Date
Designation
Subject to modification without
prior notice.
Drawing will not be updated.
SVA 10-polig TL
Power Bug 10 pin TL 2,3
www.ERNI.com
Class
100100220002
EPSVA
K
A3
