ZXGD3004E6
8A(peak) gate driver in SOT23-6
General description
The ZXGD3004E6 is a high-speed non-inverting single MOSFET gate driver capable of driving up to 8A into
a MOSFET or IGBT gate capacitive load from supply voltages up to 40V. With typical propagation delay
times down to ~1ns and rise/fall times down to 14ns this device ensures rapid switching of the power
MOSFET or IGBT to minimize power losses and distortion in high current fast switching applications.
The ZXGD3004E6 is inherently rugged to latch-up and shoot-through, and its wide supply voltage range
allows full enhancement to minimize on-losses of the power MOSFET or IGBT.
Its low input voltage requirement and high current gain allows high current driving from low voltage
controller ICs, and the optimized pin-out SOT23-6 package with separate source and sink pins eases board
layout, enabling reduced parasitic inductance and independent control of rise and fall slew rates.
Features
•
•
•
40V operating voltage range
8 amps peak output current
Fast switching emitter-follower configuration
• 1ns propagation delay time
• 14ns rise/fall time, 1500pF load
Low input current requirement
• 1.9A(source)/1.9A(sink) output current from 10mA input
SOT23-6 package
Separate source and sink outputs for independent control of rise and fall time
Optimized pin-out to ease board layout and minimize trace inductance
No Latch Up
No shoot through
Near - Zero quiescent and output leakage current
•
•
•
•
•
•
•
Typical application circuit
V
S
V
CC
V
CC
IN
1
SOURCE
Input
IN
2
ZXGD3004
SINK
GND
Issue 1 - October 2007
© Zetex Semiconductors plc 2007
1
www.zetex.com
ZXGD3004E6
Applications
Power MOSFET and IGBT Gate Driving in
•
•
•
•
•
Synchronous switch-mode power supplies
Secondary side synchronous rectification
Plasma Display Panel power modules
1, 2 and 3-phase motor control circuits
Audio switching amplifier power output stages
Pin configuration
V
CC
IN
1
GND
SOT236
Top view
SOURCE
IN
2
SINK
Pin description
Pin Name
V
CC
IN
1
/ IN
2
GND
SOURCE
SINK
Pin Function
Driver supply.
Driver input pins. These are normally connected together by circuit tracks.
Ground.
Source current output.
Sink current output.
Ordering information
Device
ZXGD3004E6TA
Reel size
(inches)
7
Tape width
(mm)
8 embossed
Quantity per
reel
3000
Device marking
3004
Issue 1 - October 2007
© Zetex Semiconductors plc 2007
2
www.zetex.com
ZXGD3004E6
Absolute maximum ratings
Parameter
Supply voltage
Input voltage
Peak sink current
(c)
Source current @ I
IN1
+ I
IN2
=10mA
(a)
Sink current @ I
IN1
+ I
IN2
=10mA
(a)
Input current
(c)
Power dissipation at T
A
=25°C
(a)(b)
Linear derating factor
Operating and storage temperature range
T
j
, T
stg
Symbol
V
CC
V
IN
I
(sink)PK
I
(source)
I
(sink)
I
IN1,
I
IN2
P
D
Limit
40
40
8
1.9
1.9
1
1.1
8.8
-55 to +150
Unit
V
V
A
A
A
A
W
mW/°C
°C
Thermal resistance
Parameter
Junction to ambient
(a)(b)
Symbol
R
JC
Value
113
Unit
°C/W
NOTES:
(a) For a device surface mounted on 25mm x 25mm x 0.6mm FR4 PCB with high coverage of single sided 1oz copper,
in still air conditions.
(b) For device with two active dice running at equal power.
(c) Pulse width <=300us limit repetition rate to comply with maximum junction temperature.
Issue 1 - October 2007
© Zetex Semiconductors plc 2007
3
www.zetex.com
