8760 Paired - Shielded Twisted Pair Cable
For more information please
call
1-800-Belden1
See Put-ups and Colors
Description:
18 AWG stranded (16x30) tinned copper conductors, polyethylene insulation, twisted pair, overall Beldfoil® shield (100% coverage), 20
AWG stranded tinned copper drain wire, PVC jacket.
PHYSICAL CHARACTERISTICS:
CONDUCTOR:
Number of Pairs
Total Number of Conductors
AWG
Stranding
Conductor Material
INSULATION:
Insulation Material
Nom. Insulation Wall Thickness
Lay Length
Twists/ft.
Pair Color Code Chart :
Number
1
OUTER SHIELD:
Outer Shield Material Trade Name
Outer Shield Type
Outer Shield Material
Outer Shield %Coverage
OUTER SHIELD DRAIN WIRE :
Outer Shield Drain Wire AWG
Outer Shield Drain Wire Stranding
Outer Shield Drain Wire Conductor Material
OUTER JACKET:
Outer Jacket Material
PVC - Polyvinyl Chloride
Page 1 of 3
1
2
18
16x30
TC - Tinned Copper
PE - Polyethylene
.019 in.
1.5 in.
8
Color
Black & Clear
Beldfoil®
Tape
Aluminum Foil-Polyester Tape w/Shorting Fold
100 %
20
7x28
TC - Tinned Copper
8760 Paired - Shielded Twisted Pair Cable
Outer Jacket Nominal Wall Thickness
OVERALL NOMINAL DIAMETER:
Overall Nominal Diameter
MECHANICAL CHARACTERISTICS:
Operating Temperature Range
UL Temperature Rating
Bulk Cable Weight
Max. Recommended Pulling Tension
Min. Bend Radius (Install)
.028 in.
.222 in.
-20°C To +60°C
60°C (UL AWM Style 2092)
26.6 lbs/1000 ft.
62 lbs.
2.25 in.
APPLICABLE SPECIFICATIONS AND AGENCY COMPLIANCE:
APPLICABLE STANDARDS:
NEC/(UL) Specification
CEC/C(UL) Specification
AWM Specification
EU CE Mark (Y/N)
EU RoHS Compliant (Y/N)
EU RoHS Compliance Date (mm/dd/yyyy):
FLAME TEST:
UL Flame Test
PLENUM/NON-PLENUM:
Plenum (Y/N)
Plenum Number
ELECTRICAL CHARACTERISTICS:
Nom. Characteristic Impedance
Nom. Inductance
Nom. Capacitance Conductor to Conductor @ 1 KHz
Nom. Cap. Cond. to Other Cond. & Shield @ 1 KHz
Nom. Conductor DC Resistance @ 20 Deg. C
Max. Operating Voltage - UL
Max. Recommended Current
57 Ohms
.18 µH/ft
29.8 pF/ft
44 pF/ft
6.5 Ohms/1000 ft
300 V RMS (UL AWM Style 2092)
5.2 Amps per conductor @ 25°C
N
88760, 87760 or 82760
UL1685 UL Loading
CM
CM
UL Style 2092 (300 V 60°C)
Yes
Yes
01/01/2004
PUT-UPS AND COLORS:
Item
Description
Put-Up (ft.)
8760 0601000
2 #18 LDPE SH PVC 1000
8760 06010000
2 #18 LDPE SH PVC 10000
Ship Weight (lbs.)
26
260
Page 2 of 3
Jacket Color
CHROME
CHROME
Notes
C
CY
8760 Paired - Shielded Twisted Pair Cable
8760 0602000
8760 060250
8760 060500
8760 0605000
8760 060U1000
8760 060U500
2 #18 LDPE SH PVC 2000
2 #18 LDPE SH PVC 250
2 #18 LDPE SH PVC 500
2 #18 LDPE SH PVC 5000
2 #18 LDPE SH PVC U1000
2 #18 LDPE SH PVC U500
50
6.75
13
135
25
13.5
CHROME
CHROME
CHROME
CHROME
CHROME
CHROME
C
C
C
C = CRATE REEL PUT-UP.
Y = FINAL PUT-UP LENGTH MAY VARY -10% TO +20% FROM LENGTH SHOWN. MAY CONTAIN 2 PIECES. MINIMUM
LENGTH OF ANY ONE PIECE IS 1500'.
Revision Number: 1
Revision Date: 12-19-2005
© 2006 Belden Wire & Cable Company
All Rights Reserved.
Although Belden Electronics Division ("Belden") makes every reasonable effort to ensure their accuracy at the time of this publication,
information and specifications described herein are subject to error or omission and to change without notice, and the listing of such
information and specifications does not ensure product availability.
Belden provides the information and specifications herein on an "AS IS" basis, with no representations or warranties, whether express,
statutory or implied. In no event will Belden be liable for any damages (including consequential, indirect, incidental, special, punitive, or
exemplary damages) whatsoever, even if Belden has been advised of the possibility of such damages, whether in an action under contract,
negligence or any other theory, arising out of or in connection with the use, or inability to use, the information or specifications described
herein.
All sales of Belden products are subject to Belden's standard terms and conditions of sale.
Belden CDT Electronics Division believes this product to be in compliance with the following environmental regulations: California
Proposition 65 Consent Judgment For Wire & Cable Mfgs.(San Francisco Superior Court Nos. 312962 And 320342); EU RoHS
(Directive 2002/95/EC, 27-Jan-2003);Material manufactured prior to the compliance date may still be in stock at Belden facilities and in our
Distributor's inventory. EU ELV (Directive 2000/53/EC, 18-Sept-2000); EU WEEE (Directive 2002/96/EC, 27-Jan-2003); And EU BFR
(Directive 2003/11/EC, 6-Feb-2003). The information provided in this Product Disclosure, and the identification of materials listed as
reportable or restricted within the Product Disclosure, is correct to the best of Belden's knowledge, information and belief at the date of its
publication. The information provided in the Product Disclosure is designed only as a general guide for the safe handling, storage, and any
other operation of the product itself or the one that it becomes a part of. This Product Disclosure is not to be considered a warranty or quality
specification. Regulatory information is for guidance purposes only. Product users are responsible for determining the applicability of
legislation and regulations based on their individual usage of the product.
Belden CDT Electronics Division declares this product to be in compliance with EU LVD (Low Voltage Directive 73/23/EEC), as amended
by directive 93/68/EEC.
Page 3 of 3
