Features
■
Available in E6 series
■
Low unit height of 4.8 mm
■
High current
■
RoHS compliant*
Applications
■
Input/output of DC/DC converters
■
Power supplies for:
*R
oH
S
CO
•
•
•
•
Portable communication equipment
Camcorders
LCD TVs
Car radios
SRR0604 Series - Shielded Power Inductors
Electrical Specifications
Inductance 1 KHz
Bourns Part No.
uH
Tol. %
Q
Ref.
Test
Frequency
(MHz)
SRF
Min.
(MHz)
RDC
Max.
(Ω)
I rms
Max.
(A)
I sat
Typ.
(A)
General Specifications
Test Voltage ...................................1 Volt
Reflow Soldering .. 230 °C, 50 sec. max.
Operating Temperature
................................-40 °C to +125 °C
(Temperature rise included)
Storage Temperature
................................-40 °C to +125 °C
Resistance to Soldering Heat
................................. 260 °C for 5 sec.
Materials
Core ............................... Ferrite DR & RI
Wire ............................Enameled copper
Base .....................................LCP E4008
Terminal ....................................Cu/Ni/Sn
Rated Current
...............Ind. drop of 10 % typ. at Isat
Temperature Rise
.....................40 °C max. at rated Irms
Packaging .................. 1000 pcs. per reel
Product Dimensions
6.5
±0.2
(.256
±.008)
6.5
±
0.2
(.256
±.008)
MAX.
4.8
(.189)
SRR0604-1R5ML
SRR0604-2R2ML
SRR0604-2R5ML
SRR0604-3R3ML
SRR0604-4R7ML
SRR0604-6R8ML
SRR0604-100ML
SRR0604-150ML
SRR0604-220ML
SRR0604-330KL
SRR0604-470KL
SRR0604-680KL
SRR0604-101KL
SRR0604-151KL
SRR0604-221KL
SRR0604-331KL
SRR0604-471KL
SRR0604-681KL
SRR0604-102KL
SRR0604-222KL
1.5
2.2
2.5
3.3
4.7
6.8
10
15
22
33
47
68
100
150
220
330
470
680
1000
2200
±20
±20
±20
±20
±20
±20
±20
±20
±20
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
±10
23
21
21
21
10
20
18
18
16
16
15
15
23
21
20
18
18
16
15
80
7.96
7.96
7.96
7.96
7.96
7.96
2.52
2.52
2.52
2.52
2.52
2.52
0.796
0.796
0.796
0.796
0.796
0.796
0.252
0.252
110.0
100.0
100.0
90.0
50.0
37.0
30.0
30.0
25.0
21.0
18.0
15.0
13.0
12.0
10.0
7.0
6.5
6.0
5.5
0.65
0.028
0.032
0.035
0.050
0.060
0.070
0.12
0.13
0.19
0.25
0.36
0.52
0.65
1.00
1.70
2.10
3.30
4.80
6.10
16.0
2.80
2.50
2.50
2.30
2.00
1.60
1.30
1.10
0.90
0.70
0.60
0.50
0.40
0.30
0.25
0.20
0.18
0.15
0.12
0.10
3.95
3.50
3.50
2.90
2.55
2.05
1.80
1.45
1.20
0.95
0.80
0.68
0.57
0.47
0.32
0.28
0.22
0.19
0.15
0.08
Schematic
100
2.0
±0.2
(.099
±.008)
0.7
±0.1
(.028
±.004)
5.0
±0.2
(.197
±.008)
0.7
±0.1
(.028
±.004)
Recommended Layout
2.5
(.099)
4.5
(.177)
1.5
(.060)
DIMENSIONS:
*RoHS Directive 2002/95/EC Jan. 27, 2003 including annex and RoHS Recast 2011/65/EU June 8, 2011.
Specifications are subject to change without notice.
The device characteristics and parameters in this data sheet can and do vary in different applications and actual device performance may vary over time.
Users should verify actual device performance in their specific applications.
MM
(INCHES)
SRR0604 Series - Shielded Power Inductors
Packaging Specifications
330
DIA.
(13.00)
2.0 ± 0.5
(.079 ± .020)
22.4
(.882)
13.0
(.512)
DIA.
50.0 -0
(1.969 -0)
13.0
DIA.
(.512)
18 +0
(.709 +0)
EMBOSSED
CARRIER
THICKNESS
0.10
(.004)
MAX.
EMBOSSED
CAVITY
21.0 ± 0.8
(.827 ± .031)
END
12.0
(.472)
4
(.157)
START
100
100
100
100
NO COMPONENT
COMPONENTS
NO COMPONENT
200
(7.874)
400
(15.748
USER DIRECTION OF FEED
QTY: 1000 PCS. PER REEL
DIMENSIONS:
MM
(INCHES)
REV. 04/13
Specifications are subject to change without notice.
The device characteristics and parameters in this data sheet can and do vary in different applications and actual device performance may vary over time.
Users should verify actual device performance in their specific applications.
