132P224X0100S12

Description
Film Capacitor, Mixed (paper+polyester), 100V, 20% +Tol, 20% -Tol, 0.22uF, Through Hole Mount, AXIAL LEADED
CategoryPassive components    capacitor
File Size1MB,8 Pages
ManufacturerEXXELIA Group
Download Datasheet Parametric View All

132P224X0100S12 Overview

Film Capacitor, Mixed (paper+polyester), 100V, 20% +Tol, 20% -Tol, 0.22uF, Through Hole Mount, AXIAL LEADED

132P224X0100S12 Parametric

Parameter NameAttribute value
Objectid8039131922
package instruction,
Reach Compliance Codeunknown
ECCN codeEAR99
capacitance0.22 µF
Capacitor typeFILM CAPACITOR
dielectric materialsMIXED (PAPER+POLYESTER)
Installation featuresTHROUGH HOLE MOUNT
negative tolerance20%
Number of terminals2
Maximum operating temperature125 °C
Minimum operating temperature-65 °C
Package shapeTUBULAR PACKAGE
positive tolerance20%
Rated (DC) voltage (URdc)100 V
GuidelineMIL-PRF-19978
surface mountNO
Terminal shapeWIRE

132P224X0100S12 Preview

Type 132p
PaPer / Polyester dieleCtriC
eXteNded Foil eleCtrodes
eleCtriCal sPeCiFiCatioNs
CapaCitanCe range:
0.001 μF to 1.0 μF
VOltage rating:
100 VDC to 1,000 VDC
CapaCitanCe tOleranCe:
±20%, ±10%, ±5%
Operating temperature:
-65°C to +125°C
VOltage Derating:
At +125°C, 50% of the 85°C rating
FeatUres
• Moderate cost
• Small size
• High peak current ratings
• High corona starting voltage
• Approved to MIL-PRF-19978
majOr appliCatiOns:
High voltage, high current, high pulse operations, protection circuits, and snubber
applications.
DissipatiOn FaCtOr:
1.0% maximum
DC VOltage test:
200% of rated voltage for 2 minutes
insulatiOn resistanCe:
Measure at rated VDC or 500 V, whichever is less, after a 2 minute charge.
• At +25°C, 20,000 Megaohm-Microfarads, need not exceed 30,000 Megaohms
• At +125°C, 20 Megaohm-Microfarads, need not exceed 250 Megaohms
PHysiCal CHaraCteristiCs
COnstruCtiOn:
Non-inductive wound paper / polyester dielectric with extended foil electrodes.
Impregnated with vitamin Q.
Case:
Hermetically sealed metal enclosure. Styles and dimensions are in Guide to
Ordering section in the front of the catalog.
leaD material:
Solder coated solid wire.
leaD Wire sizes:
Case Dia.
< 0.235
< 0.235 and 0.312
0.400 and over
leaD pull:
5 lbs (2.3 kg) for one minute. No physical damage.
leaD BenD:
After three complete consecutive bends. No damage.
marking:
Dearborn trademark, type or catalog number, capacitance, tolerance, and voltage.
lead aWg
No. 24
No. 22
No. 20
MaXiMUM PUlse rise tiMe
Capacitor
length
(inch)
0.687 / 0.750
0.812 / 0.875
1.062 / 1.125
1.312 / 1.375
1.562 / 1.625
1.812 / 1.875
2.062 / 2.125
2.312 / 2.375
rise time dv / dt (V / μs)
100 VDC
800
700
400
300
200
-
-
-
200 VDC
1600
1000
500
350
250
-
200
-
300 VDC
2000
1000
650
425
300
-
250
-
400 VDC
3000
1000
800
500
350
-
300
-
600 VDC
4500
1500
1000
800
500
-
400
300
1,000 VDC
-
2500
1500
1000
800
550
500
450
52
PaPer / Polyester dieleCtriC
eXteNded Foil eleCtrodes
staNdard ratiNGs
Capacitance
μF
0.0010
0.0015
0.0022
0.0033
0.0047
0.0068
0.010
0.015
0.022
0.033
0.047
0.068
0.10
0.15
0.22
0.33
0.47
0.68
1.00
Code
102
152
222
332
472
682
103
153
223
333
473
683
104
154
224
334
474
684
105
Voltage Code 100
100 VDC
D
l
0.175
0.687
0.175
0.687
0.175
0.687
0.175
0.687
0.175
0.687
0.195
0.687
0.235
0.687
0.235
0.687
0.312
0.812
0.312
0.812
0.312
0.812
0.400
0.812
0.400
0.812
0.400
1.062
0.400
1.062
0.562
1.062
0.562
1.312
0.562
1.562
0.670
1.562
Voltage Code 200
200 VDC
D
l
0.235
0.687
0.235
0.687
0.235
0.687
0.235
0.687
0.235
0.687
0.235
0.687
0.312
0.812
0.312
0.812
0.312
0.812
0.312
0.812
0.400
0.812
0.400
0.812
0.400
1.062
0.400
1.312
0.562
1.062
0.562
1.312
0.562
1.562
0.670
1.562
0.750
2.062
Voltage Code 300
300 VDC
D
l
0.235
0.687
0.235
0.687
0.235
0.687
0.235
0.687
0.235
0.687
0.312
0.812
0.312
0.812
0.312
0.812
0.312
0.812
0.400
0.812
0.400
0.812
0.400
1.062
0.400
1.312
0.562
1.062
0.562
1.312
0.562
1.562
0.670
1.562
0.750
2.062
-
-
Voltage Code 400
400 VDC
D
l
0.235
0.687
0.235
0.687
0.235
0.687
0.235
0.687
0.312
0.812
0.195
0.812
0.312
0.812
0.312
0.812
0.400
0.812
0.400
0.812
0.400
1.062
0.400
1.312
0.562
1.062
0.562
1.312
0.562
1.562
0.670
1.562
0.750
2.062
-
-
-
-
Voltage Code 600
600 VDC
D
l
0.235
0.687
0.235
0.687
0.235
0.687
0.312
0.812
0.312
0.812
0.312
0.812
0.312
0.812
0.400
0.812
0.400
0.812
0.400
1.062
0.400
1.312
0.562
1.062
0.562
1.312
0.562
1.562
0.670
1.562
0.750
2.062
0.750
2.312
-
-
-
-
Voltage Code 1000
1,000 VDC
D
l
0.400
0.812
0.400
0.812
0.400
0.812
0.400
0.812
0.400
0.812
0.400
0.812
0.400
0.812
0.400
1.062
0.400
1.312
0.562
1.062
0.562
1.312
0.562
1.562
0.670
1.562
0.670
1.812
0.750
2.062
1.000
2.062
1.000
2.312
-
-
-
-
Additional capacitance values, voltages, and tolerances are available upon request.
* The dimensions Tabulated above are for styles 01, 03, and 12. Add 0.062” to the length for styles 02, 04, and 13.
Type 132p
53
Guide to orderinG
