MTH Series 5 x 3.2 Ceramic SMD Oscillator



Frequency Range

Temperature Stability*

Aging (+25°C ±3°C)

Operating Temperature Range

Storage Temperature Range

Supply Voltage (±10%)

1.000MHZ to 34.999MHZ

35.000MHZ to 60.000MHZ

60.001MHZ to 99.999MHZ

100.000MHZ to 106.250MHZ

106.251MHZ to 160.000MHZ

Low Profile SMD Package

Hermetically Sealed

Standby & Tristate Available

Wide Frequency Range

1.000MHZ to

160.000MHZ

1.000MHZ to

160.000MHZ &

1.000MHZ to

160.000MHZ &

1.000MHZ to

106.250MHZ

Supply Current

+1.80 VDC

8mA

10mA

25mA

35mA

Output Type

Symmetry (50% of waveform)

Rise/Fall Time (10% to 90% of Supply Voltage)

Load

Start-up Time

Period Jitter: pk-pk

Period Jitter: One Sigma

Phase Jitter (12KHZ to 20MHZ)

* Inclusive of Temperature., Load and Voltage

Pin 1 Function

Tri-state Operation

Standby Current

(See Part Number Guide for Options)

±3ppm, ±5ppm for first year

(See Part Number Guide for Options)

-55°C to +125°C

+2.50 VDC

+3.30 VDC

10mA

16mA

20mA

25mA

30mA

40mA

50mA

40mA

50mA

HCMOS

40%/60% (45%/55% option)

10nS max

15pF

10mSec max

±100ps max

±25ps max

1ps max

+5.00 VDC

25mA

50mA

60mA

80mA

Vih = 70% of Vdd min to Enable Output

Vil = 30% max or grounded to Disable Output (High Impedance)

10µA max

Mechanical & Environmental Detail

Humidity

Hermetic Seal

Solderability

Reflow Solderability

Vibration

Shock

MIL-STD-883

85% RH, 85°C, 48 Hours

Leak Rate 2 X 10 ATM-cm /sec max

MIL-STD-202G, Method 208

260°C for 10 seconds

MIL-STD-202G, Method 204 35G, 50 to 2000 Hz

MIL-STD-202G, Method 203 Test Cond E, 1000G’s, ½

Sinewave

Available with Level B Screening

-8

Marking Detail

Line 1 = MXXXXX

XXXXX

YYWW

MMD

Frequency in MHZ

Internal Code

4 Digit Date Code (Year / Week)

Denotes RoHS Compliant

Line 2 = SYYWWL

Line 3 = XXXXX

Internal use only

May vary with lots

Black dot to denote Pin 1

MMD Monitor/Quartztek

30400 Esperanza, Rancho Santa Margarita, CA, 92688

Phone: (949) 709-5075, Fax: (949) 709-3536,

www.mmdcomp.com

Sales@mmdcomp.com

Revision:

Subject to change without notice

120925M

Pg 1 of 2
