Green
200 GHz Single Channel
OADM
(2x2)
OADMG2 2x2 Series
Product Description
Oplink’s 200GHz single Channel OADM is based on patented athermal plat-
form for optical device. This multiplexer features ultra low insertion loss, su-
per thermal stability, and unparallel reliability. The technology is a lead-free
packaging platform and no epoxy in the optical path. Green 200GHz DWDM
is Telcordia GR-1221 and GR-1209 tested, qualified for uncontrolled environ-
ment applications and complied with industry green initiatives such as RoHS
and WEEE.
Oplink can provide customized designs to meet specialized feature applica-
tions. Also, Oplink offers modular assemblies that integrate other components
to form a full function module or subsystem.
Performance Specificationns
OADMG 200GHz (2x2) Series
Min
Typical
Max
Unit
Features
Working Wavelength Range
Center Wavelength λ
C
Channel Spacing
Passband Bandwidth
Insertion Loss
1)
Add/Drop
Express
1528~1640
ITU Grid
200
λ
C
± 0.25
0.60
0.70
30
40
24
0.20
0.10
45
50
500
0 to +70
-40 to +85
Corning SMF-28
0.70
0.80
nm
nm
GHz
nm
dB
dB
dB
dB
dB
ps
dB
dB
mW
°C
°C
mm
Environmental Green Plan
Compliance
Ultra-Low Insertion Loss
Narrow Down Distribution
Super Thermal Stability
Highly Reliability
High Channel Isolation
Add/Drop Adjacent Channel Isolation
Add/Drop Non-adjacent Channel Isolation
Express Channel Isolation
Polarization Dependent Loss (PDL)
Polarization Mode Dispersion (PMD)
Return Loss
Directivity
Operating Power
Operating Temperature
Storage Temperature
Fiber Type
Package Dimensions
3)
Applications
Add/Drop Channels
Dense WDM System
CATV Fiberoptic Links
125 x 90 x 8
Note:
1)
The maximum IL is under all states of polarization and within the full operating temperature and wavelength
ranges specified..
2)
All the parameters are excluding connectors.
3)
The mechanical tolerance should be +/-0.2 mm on all package dimensions unless otherwise custom specified.
S0039 - R01. 20100616
Green
200GHz Single Channel OADM (2x2)
OADMG2 2x2 Series
Mechanical Drawing / Package Dimensions (dimension in mm)
8.0
125.0
15.0
COM OUT
ADD
90.0
φ 3.0X4
COM IN
See Detail A
30.0
60.0
DROP
8.0X2
15.0
4.0
8.0
R2.5
A
R1.5
4.0
2.0
Units: mm
4.0
Section A-A
46335 Landing Pkwy Fremont, CA 94538 Tel: (510) 933-7200 Fax: (510) 933-7300 Email: Sales@Oplink.com • www.oplink.com
5.0
A
3.0
Detail A
Ordering Information
Oplink can provide a remarkable range of customized optical solutions. For detail, please contact Oplink’s OEM
design team or account manager for your requirements and ordering information (510) 933-7200.
OADM
G
2
0
1
2
0
Platform
Green = G
Channel
1Ch = 01
ITU Channel Number
Refer ITU Channel Table
Fiber Length*
0.5 Meter = H
1.0 Meter = 1
1.5 Meters = 5
2.0 Meters = 2
Connector Type
None = 1
FC/PC = 2
FC/SPC = 3
FC/APC = 4
SC/PC = 5
SC/SPC = 6
SC/APC = 7
ST = 8
LC = 9
MU = A
Channel Spacing
200GHz = 2
Fiber Jacket
900μm Loose Tube = 2
* The tolerance of fiber length is +/-0.1m. 1 meter is standard. The lead-time for special fiber
length will be longer.
S0039 - R01. 20100616
