19017-0007 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> 19017-0007

19017-0007: Description2 mm2, PUSH-ON TERMINAL; CategoryThe connector; File Size30KB，2 Pages; ManufacturerMolexKits; Websitehttp://www.molexkits.com

Download Datasheet Parametric Compare View All

19017-0007 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	19017-0007	-	-	View	Buy Now

19017-0007 Overview

2 mm2, PUSH-ON TERMINAL

19017-0007 Parametric

Parameter Name	Attribute value
Lead-free	Yes
EU RoHS regulations	Yes
state	ACTIVE
contact surface	NOT SPECIFIED
Contact materials	NOT SPECIFIED
Manufacturer Series	19003
Terminal male and female	FEMALE
Terminal type	PUSH-ON TERMINAL
Wire cross section	2 mm2
Wire gauge	14 AWG

Preview

Download Datasheet

View All

1801 Morgan Street

Rockford, Illinois 61102

800-435-2931

www.molexkits.com

Datasheet for 76650-0042

General Information

76650-0042

Part Number:

Manufacturer:

Title:

Description:

Product Family:

Certificates:

Molex / Waldom

Solderless Terminal Kit

.187" Tab Size PVC and Nylon Insulated Quick Disconnect Solderless Terminals

Quick Disconnects

(Molex Parts within this kit) - EU RoHS Compliant, UL and CSA

Country of Origin:

Kit assembled in U.S.A.

Specifications

Design

Configuration:

Size:

Connector Type:

Insulation:

Current Rating:

Voltage:

Wire size:

Product Highlights

Quick disconnects allow for quickly connecting or disconnecting a terminal. The

front end of the terminal has a female-type receptacle which allows the terminal to

slide onto and off of a male blade.

Features and Benefits

• Translucent "see-through" insulator

provides fast, on-line quality control

inspection by allowing a quick visual check

of the wire/terminal assembly.

• Color-coded insulator allows easy

indentification of terminal size and wire

gauge.

• A wire stop stamped into the crimp barrel

prevents insertion of over-stripped wires.

• Terminal's funnel entrance is designed for

increased crimping rates by speeding wire

delivery into the crimp section and

eliminating wire strand fold back.

Applications

• MRO (Maintenance Repair and Operations)

• Consumer applications

• Power applications

• Motor applications

Wire-to-Wire / Solderless Terminals

.187"

Male and Female

Nylon

(3-15) Amps - Dependant on Wire Gauge

600 Volts

(22-18) and (16-14) AWG

For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com

Page 1 of 2

19017-0007 Related Products

	19017-0007	64001-0700	64001-2400	76650-0042	19023-0003	19003-0050
Description	2 mm2, PUSH-ON TERMINAL	2 mm2, PUSH-ON TERMINAL	2 mm2, PUSH-ON TERMINAL	2 mm2, PUSH-ON TERMINAL	2 mm2, PUSH-ON TERMINAL	2 mm2, PUSH-ON TERMINAL
Lead-free	Yes	Yes	Yes	Yes	Yes	Yes
EU RoHS regulations	Yes	Yes	Yes	Yes	Yes	Yes
state	ACTIVE	ACTIVE	ACTIVE	ACTIVE	ACTIVE	ACTIVE
contact surface	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
Contact materials	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
Manufacturer Series	19003	19003	19003	19003	19003	19003
Terminal male and female	FEMALE	FEMALE	FEMALE	FEMALE	FEMALE	FEMALE
Terminal type	PUSH-ON TERMINAL	PUSH-ON TERMINAL	PUSH-ON TERMINAL	PUSH-ON TERMINAL	PUSH-ON TERMINAL	PUSH-ON TERMINAL
Wire cross section	2 mm2	2 mm2	2 mm2	2 mm2	2 mm2	2 mm2
Wire gauge	14 AWG	14 AWG	14 AWG	14 AWG	14 AWG	14 AWG
