MBR1090CT, MBR10100CT
Vishay General Semiconductor
Dual Common-Cathode High Voltage Schottky Rectifier
TMBS
®
FEATURES
• Trench MOS Schottky technology
• Lower power losses, high efficiency
• Low forward voltage drop
• High forward surge capability
• High frequency operation
3
2
1
TO-220AB
• Solder bath temperature 275 °C maximum, 10 s,
per JESD 22-B106
• Compliant to RoHS directive 2002/95/EC and in
accordance to WEEE 2002/96/EC
TYPICAL APPLICATIONS
For use in high frequency rectifier of switching mode
power supplies, freewheeling diodes, dc-to-dc
converters or polarity protection application
PIN 1
PIN 3
PIN 2
CASE
PRIMARY CHARACTERISTICS
I
F(AV)
V
RRM
I
FSM
V
F
T
J
max.
2 x 5.0 A
90 V, 100 V
120 A
0.75 V
150 °C
MECHANICAL DATA
Case:
TO-220AB
Molding compound meets UL 94 V-0 flammability
rating
Base P/N-E3 - RoHS compliant, commercial grade
Terminals:
Matte tin plated leads, solderable per
J-STD-002 and JESD 22-B102
E3 suffix meets JESD 201 class 1A whisker test
Polarity:
As marked
Mounting Torque:
10 in-lbs maximum
MAXIMUM RATINGS
(T
C
= 25 °C unless otherwise noted)
PARAMETER
Maximum repetitive peak reverse voltage
Working peak reverse voltage
Maximum DC blocking voltage
Maximum average forward rectified current at T
C
= 105 °C
total device
per diode
SYMBOL
V
RRM
V
RWM
V
DC
I
F(AV)
I
FSM
E
AS
I
RRM
dV/dt
T
J
, T
STG
MBR1090CT
90
90
90
10
5.0
120
60
0.5
10 000
- 65 to + 150
MBR10100CT
100
100
100
UNIT
V
V
V
A
A
mJ
A
V/µs
°C
Peak forward surge current 8.3 ms single half sine-wave superimposed
on rated load per diode
Non-repetitive avalanche energy
at T
J
= 25 °C, L = 60 mH per diode
Peak repetitive reverse current at t
p
= 2 µs, 1 kHz,
T
J
= 38 °C ± 2 °C per diode
Voltage rate of change (rated V
R
)
Operating junction and storage temperature range
Document Number: 89125
Revision: 26-Apr-10
For technical questions within your region, please contact one of the following:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
www.vishay.com
1
New Product
MBR1090CT, MBR10100CT
Vishay General Semiconductor
ELECTRICAL CHARACTERISTICS
(T
C
= 25 °C unless otherwise noted)
PARAMETER
Maximum instantaneous forward voltage per diode
(1)
Maximum reverse current per diode at working peak
reverse voltage
(2)
Notes
(1)
(2)
TEST CONDITIONS
I
F
= 5.0 A
I
F
= 5.0 A
T
C
= 125 °C
T
C
= 25 °C
T
J
= 25 °C
T
J
= 100 °C
SYMBOL
V
F
I
R
MBR1090CT
MBR10100CT
UNIT
V
µA
mA
0.75
0.85
100
6.0
Pulse test: 300 µs pulse width, 1 % duty cycle
Pulse test: Pulse width
≤
40 ms
THERMAL CHARACTERISTICS
(T
C
= 25 °C unless otherwise noted)
PARAMETER
Typical thermal resistance per diode
SYMBOL
R
θJC
MBR1090CT
4.4
MBR10100CT
UNIT
°C/W
ORDERING INFORMATION
(Example)
PACKAGE
TO-220AB
PREFERRED P/N
MBR10100CT-E3/4W
UNIT WEIGHT (g)
1.87
PACKAGE CODE
4W
BASE QUANTITY
50/tube
DELIVERY MODE
Tube
RATINGS AND CHARACTERISTICS CURVES
(T
A
= 25 °C unless otherwise noted)
10
Resistive or Inductive Load
120
Peak Forward Surge Current (A)
Average Forward Current (A)
8
100
T
J
= T
J
Max.
8.3
ms Single Half Sine-Wave
80
6
60
4
40
2
20
0
0
50
100
150
0
1
10
100
Case Temperature (°C)
Number
of Cycles at 60 Hz
Figure 1. Forward Current Derating Curve
Figure 2. Maximum Non-Repetitive Peak Forward Surge
Current Per Diode
www.vishay.com
2
For technical questions within your region, please contact one of the following:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
Document Number: 89125
Revision: 26-Apr-10
New Product
MBR1090CT, MBR10100CT
Vishay General Semiconductor
4.0
D = 0.8
3.5
10 000
D = 0.5
D = 0.3
D = 0.2
D = 1.0
T
J
= 25 °C
f = 1 MHz
V
sig
= 50 mVp-p
1000
3.0
2.5
2.0
1.5
1.0
0.5
0
0
1
2
D = 0.1
T
Junction Capacitance (pF)
6
Average Power Loss (W)
100
D = t
p
/T
t
p
10
3
4
5
0.1
1
10
100
Average Forward Current (A)
Reverse
Voltage
(V)
Figure 3. Forward Power Loss Characteristics Per Diode
Figure 6. Typical Junction Capacitance Per Diode
100
10
Transient Thermal Impedance (°C/W)
Instantaneous Forward Current (A)
Junction to Case
T
A
= 150 °C
10
T
A
= 125 °C
T
A
= 100 °C
1
T
A
= 25 °C
0.1
0
0.2
0.4
0.6
0.8
1.0
1.2
1.4
1.6
0.1
0.01
0.1
1
10
100
Instantaneous Forward
Voltage
(V)
t - Pulse Duration (s)
Figure 4. Typical Instantaneous Forward Characteristics Per Diode
Figure 7. Typical Transient Thermal Impedance Per Diode
100
Instantaneous Reverse Current (mA)
10
T
A
= 150 °C
T
A
= 125 °C
1
T
A
= 100 °C
0.1
0.01
T
A
= 25 °C
0.001
0.0001
0
20
40
60
80
100
Percent of Rated Peak Reverse
Voltage
(%)
Figure 5. Typical Reverse Characteristics Per Diode
Document Number: 89125
Revision: 26-Apr-10
For technical questions within your region, please contact one of the following:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
www.vishay.com
3
New Product
MBR1090CT, MBR10100CT
Vishay General Semiconductor
PACKAGE OUTLINE DIMENSIONS
in inches (millimeters)
TO-220AB
0.415 (10.54) MAX.
0.370 (9.40)
0.360 (9.14)
0.154 (3.91)
0.148 (3.74)
0.113 (2.87)
0.103 (2.62)
0.145 (3.68)
0.135 (3.43)
0.635 (16.13)
0.625 (15.87)
3
0.603 (15.32)
0.573 (14.55)
0.350 (8.89)
0.330 (8.38)
1.148 (29.16)
1.118 (28.40)
0.110 (2.79)
0.100 (2.54)
0.560 (14.22)
0.530 (13.46)
0.035 (0.90)
0.028 (0.70)
0.205 (5.20)
0.195 (4.95)
0.022 (0.56)
0.014 (0.36)
0.185 (4.70)
0.175 (4.44)
0.055 (1.39)
0.045 (1.14)
1
0.160 (4.06)
0.140 (3.56)
0.057 (1.45)
0.045 (1.14)
0.105 (2.67)
0.095 (2.41)
0.104 (2.65)
0.096 (2.45)
PIN
2
www.vishay.com
4
For technical questions within your region, please contact one of the following:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
Document Number: 89125
Revision: 26-Apr-10
