EJECT-A-DIP Lock/Eject DIP Socket
w/Collet Contacts & Surface Mount Pins
™
FEATURES
• Rugged, Solderable Socket with a Unique Ejector/Latch for Fast In-field Board Maintenance
• Latch Locks-in Connector or Device for High-vibration Environments
• Ejector/Latch removes DIP Packages without Damage
• High-temperature 4/6 Nylon Suitable for Any Surface Mount Soldering Application
GENERAL SPECIFICATIONS
•
LATCH & BODY: Black UL 94V-0 Glass-filled 4/6 Nylon
•
PIN BODY: Brass 360 1/2-hard per UNS C36000 ASTM-B16-00
•
PIN BODY PLATING: 10µ [0.25µ] min. Au per MIL-G-45204 –OR–
200µ [5.08µ]
ORDERING INFORMATION
min. 93/7 Sn/Pb per ASTM B545 –OR– 200µ [5.08µ] min. Sn per ASTM B545
XX-CXXX-X XXX XX
Type 1 over 100µ [2.54µ] min. Ni per SAE AMS-QQ-N-290B
•
6-FINGER COLLET CONTACT: BeCu per UNS C17200 ASTM-B194-01
Optional Plating
H = Heavy Au Collet
•
CONTACT PLATING: 10µ [0.25µ] min. Au per MIL-G-45204 over 50µ [1.27µ] min.
Ni per SAE AMS-QQ-N-290B. Heavy 30µ [0.76µ] Au plating on contacts also
Plating
0 = Au Collet, Sn Shell
available.
0TL = Au Collet, Sn/Pb Shell
•
CONTACT CURRENT RATING: 3 amps
1 = Au Collet & Shell
•
INSULATION RESISTANCE:
10,000 MΩ @ 500 VDC
Termination
•
WITHSTANDING VOLTAGE: 1000 V RMS
0 = Surface Mount Pins
•
OPERATING TEMPERATURE: -67°F to 221°F [-55°C to 105°C] for Sn plating,
Dim. “H”
-67°F to 257°F [-55°C to 125°C] for Au plating
(See Table)
•
INSERTION FORCE: 67g/pin, based on 0.018 [0.46] dia. test lead
•
WITHDRAWAL FORCE: 30g/pin, based on 0.018 [0.46] dia. test lead
No. of Pins
(See Table)
•
NORMAL FORCE: 45g/pin, based on 0.018 [0.46] dia. test lead long
MOUNTING CONSIDERATIONS
•
SUGGESTED PCB PAD SIZE:
0.063 [1.60] dia.
ALL DIMENSIONS: INCHES [MILLIMETERS]
ALL TOLERANCES: ±0.005 [0.13] UNLESS OTHERWISE SPECIFIED
FOR COLLET SOCKET w/SOLDER PIN TAILS, SEE DATA SHEET 12024
FOR COLLET SOCKET w/WIRE WRAP PINS, SEE DATA SHEET 12025
CONSULT FACTORY FOR OTHER SIZES AND CONFIGURATIONS
CUSTOMIZATION: ARIES SPECIALIZES IN CUSTOM DESIGN AND PRODUCTION.
SPECIAL MATERIALS, PLATINGS, SIZES, AND CONFIGURATIONS CAN BE
FURNISHED, DEPENDING ON QUANTITY.
ARIES RESERVES THE RIGHT TO CHANGE PRODUCT GENERAL SPECIFICATIONS
WITHOUT NOTICE
PRINTOUTS OF THIS DOCUMENT MAY BE OUT-OF-DATE AND SHOULD BE
CONSIDERED UNCONTROLLED
2609 Bartram Road
•
Bristol, PA 19007-6810 USA
TEL 215-781-9956
•
FAX 215-781-9845
WWW.ARIESELEC.COM
•
INFO@ARIESELEC.COM
12023
Rev. 5.2
1 of 2
EJECT-A-DIP Lock/Eject DIP Socket
w/Collet Contacts & Surface Mount Pins
™
No. of Pins
14
14
16
16
24
24
24
28
28
28
32
32
32
40
40
40
Catalog No.
14-C280-XX
14-C195-XX
16-C280-XX
16-C195-XX
24-C300-XX
24-C212-XX
24-C182-XX
28-C300-XX
28-C212-XX
28-C182-XX
32-C300-XX
32-C212-XX
32-C182-XX
40-C300-XX
40-C212-XX
40-C182-XX
Dim. “A”
0.950 [24.10]
0.950 [24.10]
1.050 [26.70]
1.050 [26.70]
1.490 [37.85]
1.490 [37.85]
1.490 [37.85]
1.690 [42.90]
1.690 [42.90]
1.690 [42.90]
1.890 [48.00]
1.890 [48.00]
1.890 [48.00]
2.290 [58.20]
2.290 [58.20]
2.290 [58.20]
Dim.“B”
0.600 [15.24]
0.600 [15.24]
0.700 [17.78]
0.700 [17.78]
1.100 [27.94]
1.100 [27.94]
1.100 [27.94]
1.300 [33.02]
1.300 [33.02]
1.300 [33.02]
1.500 [38.10]
1.500 [38.10]
1.500 [38.10]
1.900 [48.26]
1.900 [48.26]
1.900 [48.26]
Centers “C”
0.300 [7.62]
0.300 [7.62]
0.300 [7.62]
0.300 [7.62]
0.600 [15.24]
0.600 [15.24]
0.600 [15.24]
0.600 [15.24]
0.600 [15.24]
0.600 [15.24]
0.600 [15.24]
0.600 [15.24]
0.600 [15.24]
0.600 [15.24]
0.600 [15.24]
0.600 [15.24]
Dim. “D”
0.400 [10.16]
0.400 [10.16]
0.400 [10.16]
0.400 [10.16]
0.700 [17.78]
0.700 [17.78]
0.700 [17.78]
0.700 [17.78]
0.700 [17.78]
0.700 [17.78]
0.700 [17.78]
0.700 [17.78]
0.700 [17.78]
0.700 [17.78]
0.700 [17.78]
0.700 [17.78]
Dim. “E”
0.770 [19.56]
0.770 [19.56]
0.870 [22.10]
0.870 [22.10]
1.300 [33.02]
1.300 [33.02]
1.300 [33.02]
1.500 [38.10]
1.500 [38.10]
1.500 [38.10]
1.700 [43.18]
1.700 [43.18]
1.700 [43.18]
2.100 [53.34]
2.100 [53.34]
2.100 [53.34]
Dim. “F”
1.300 [33.02]
1.300 [33.02]
1.540 [39.12]
1.390 [35.31]
1.970 [50.04]
1.850 [47.00]
1.800 [45.72]
2.170 [55.12]
2.050 [52.07]
2.000 [50.80]
2.540 [64.52]
2.070 [52.58]
2.200 [55.88]
2.780 [70.61]
2.650 [67.31]
2.600 [66.04]
Dim “G”
0.490 [12.45]
0.450 [11.43]
0.490 [12.45]
0.450 [11.43]
0.570 [14.48]
0.490 [12.45]
0.460 [11.68]
0.570 [14.48]
0.490 [12.45]
0.460 [11.68]
0.570 [14.48]
0.490 [12.45]
0.460 [11.68]
0.570 [14.48]
0.490 [12.45]
0.460 [11.68]
Dim “H”
0.280 [7.11]
0.195 [4.95]
0.280 [7.11]
0.195 [4.95]
0.300 [7.62]
0.212 [5.39]
0.182 [4.62]
0.300 [7.62]
0.212 [5.39]
0.182 [4.62]
0.300 [7.62]
0.212 [5.39]
0.182 [4.62]
0.300 [7.62]
0.212 [5.39]
0.182 [4.62]
ALL DIMENSIONS: INCHES [MILLIMETERS]
ALL TOLERANCES: ±0.005 [0.13] UNLESS OTHERWISE SPECIFIED
FOR COLLET SOCKET w/SOLDER PIN TAILS, SEE DATA SHEET 12024
FOR COLLET SOCKET w/WIRE WRAP PINS, SEE DATA SHEET 12025
CONSULT FACTORY FOR OTHER SIZES AND CONFIGURATIONS
CUSTOMIZATION: ARIES SPECIALIZES IN CUSTOM DESIGN AND PRODUCTION.
SPECIAL MATERIALS, PLATINGS, SIZES, AND CONFIGURATIONS CAN BE
FURNISHED, DEPENDING ON QUANTITY.
ARIES RESERVES THE RIGHT TO CHANGE PRODUCT GENERAL SPECIFICATIONS
WITHOUT NOTICE
PRINTOUTS OF THIS DOCUMENT MAY BE OUT-OF-DATE AND SHOULD BE
CONSIDERED UNCONTROLLED
2609 Bartram Road
•
Bristol, PA 19007-6810 USA
TEL 215-781-9956
•
FAX 215-781-9845
WWW.ARIESELEC.COM
•
INFO@ARIESELEC.COM
12023
Rev. 5.2
2 of 2
