Crystal oscillator
Product Number (please contact us)
VOLTAGE -CONTROLLED CRYSTAL OSCILLATOR
(VCXO)
X1G004141xxxx00
VG-4513CA
Frequency
range
Supply
voltage
Absolute
pull range
External
dimensions
Function
Output
:
:
:
:
:
100 MHz to 500 MHz
3.3 V
-6
-6
-6
30 × 10 , 50 × 10 , 100 × 10
7.0 × 5.0 × 1.6 t (mm) Typ.
Output Enable(OE)
Active High
: LV-PECL
Actual size
Absolute Maximum ratings
Item
Supply voltage
Control voltage
Operating temperature range
Storage temperature range
Item
Output frequency range
Supply voltage
Current consumption
Frequency tolerance
(includes 10years aging)
Absolute pull range
Symbol
V
CC
V
C
T_use
T_stg
Symbol
f
O
V
CC
I
CC
f_tol
APR
Specifications
-0.5 V to 5.0 V
-0.5V to Vcc+0.5 V
-40
℃to
+85
℃
-55
C
to +125
C
Specifications
100.000 MHz½500.000 MHz
3.3 V
0.165
V
65 mA Max.
fo≦200MHz：±50 × 10
-6
Max.
fo＞200MHz：±70 × 10
-6
Max.
±30 × 10
-6
Min. ±50 × 10
-6
Min. ±100 × 10
-6
Min.
fo≦200MHz
±80 × 10
-6
to ±160 × 10
-6
(APR ±30 × 10
-6
Min.)
±100 × 10
-6
to ±200 × 10
-6
(APR ±50 × 10
-6
Min.)
±150 × 10
-6
to ±300 × 10
-6
(APR ±100 × 10
-6
Min.)
fo＞200MHz
±100 × 10
-6
to ±200 × 10
-6
(APR ±30 × 10
-6
Min.)
±120 × 10
-6
to ±240 × 10
-6
(APR ±50 × 10
-6
Min.)
±170 × 10
-6
to ±340 × 10
-6
(APR ±100 × 10
-6
Min.)
100 k Min.
50Ω at Vcc -2.0V
Vcc-1.1 V Min.
Vcc-1.5 V Max.
40 % to 60 %
0.5 ns Max.
70% Vcc
30% Vcc
10ms Max.
122.88 MHz
-75 dBc/Hz
-105 dBc/Hz
-129 dBc/Hz
-147 dBc/Hz
-151 dBc/Hz
153.6 MHz
-70 dBc/Hz
-100 dBc/Hz
-124 dBc/Hz
-143 dBc/Hz
-152 dBc/Hz
(Unit :mm)
245.76 MHz
-64 dBc/Hz
-94 dBc/Hz
-118 dBc/Hz
-138 dBc/Hz
-149 dBc/Hz
Remarks
Specifications (characteristics)
Remarks
Includes 10years aging
Vc= 0 V to 3.3 V
Pull range
PR
Vc= 0 V to 3.3 V
Input resistance
Output load condition
High output voltage
Low output voltage
Symmetry
Rise/Fall times
High input voltage
Low input voltage
Oscillation start up time
Item
Phase noise
(Typical value)
APR ±50 × 10
-6
Min.
Rin
L_ECL
DC level
V
OH
V
OL
SYM
Tr/Tf
V
IH
V
IH
toec
Offset
frequency
10 Hz
100 Hz
1 kHz
10 kHz
100 kHz
At Vcc-1.30 V, Vc=1/2Vcc V
At 20 % to 80 % output swing
V
IH
or OPEN => Enable
V
IL
or GND => Disable
368.64 MHz
-57 dBc/Hz
-87 dBc/Hz
-114 dBc/Hz
-137 dBc/Hz
-152 dBc/Hz
491.52 MHz
External dimensions
7.0±0.2
#6
#5
#4
Footprint
C=0.1 µF Min.
-55 dBc/Hz
-85 dBc/Hz
-110 dBc/Hz
-132 dBc/Hz
-150 dBc/Hz
(Recommended)
(Unit :mm)
#6
#5
1.8
#4
2.0
1.4
1.2
5.0±0.2
#1
#2
#3
C0.5
1.6±0.2
Pin map
Pin
1
2
3
4
5
6
2.54
2.54
Connection
Vc
OE
GND
OUT1(Positive)
OUT2(Negative)
Vcc
Resist
#1
#2
5.08
#3
Note
OE pin = "H" or "open" : Specified frequency output.
OE pin = "L" : Output is disable.
To maintain stable operation, provide by-pass capacitor with
more than 0.1
F
at a location as near as possible to the power
source terminal of the crystal products (between V
CC
- GND).
4.2
E 491.520
VAA2Z3C
2.6
C
