State of the Art, Inc.
Semi-Precision Thick Film Chip Resistor
MIL-PRF-55342/11 Solderable RM0402
1Ω to 22 MΩ
1, 2, 5, 10
100, 200, 300
50 mW
30 V
-65 to 150°C
M, P, R, S, U, V, T
Noise
c
d
a
b
e
Performance
Resistance Range*
Tolerances (± %)*
TCR (± ppm/°C)*
Power Rating
Voltage Rating
Operating Range
Product Levels
40
Noise (dB)
20
0
-20
-40
125
100
75
50
25
0
0
0.25 0.50 0.75 1.00 1.25
Power (W)
ceramic board
Power Dissipation
fiber epoxy board
*see QPL55342 for part number availability
1
1k
1M
Resistance Value (Ω)
Maximum Allowable Drift
Temperature Characteristic
TCR (ppm/°C)
Thermal Shock
Power Conditioning
Low Temperature Operation
Short Time Overload
High Temperature Exposure
Moisture Resistance
Life (Qualification)
Life (FR Level)
Resistance to Soldering Heat
Resistance to Bonding Exposure
K
±100
±0.5%
±0.5%
±0.25%
±0.25%
±0.5%
±0.5%
±0.5%
±2.0%
±0.25%
±0.25%
L
±200
±0.5%
±0.5%
±0.25%
±0.25%
±0.5%
±0.5%
±0.5%
±2.0%
±0.25%
±0.25%
M
±300
±0.5%
±0.5%
±0.5%
±0.5%
±1.0%
±0.5%
±2.0%
±2.0%
±0.25%
±0.25%
0.5
Drift (|%∆R|)
0.4
0.3
0.2
0.1
0
0
2k
Temperature Rise (°C)
Life Test
Percent Power
100
75
50
25
0
Power Derating
4k 6k
Hours
8k
10k
-10
70
150
Ambient Temperature (°C)
Part Number
M 5 5 3 4 2 K 11 B 1 0 0 D S - T R
Packaging: -TR: Tape & Reel
Product Level (/1000 hrs.): M: 1%
Resistance Value and Tolerance:
Three numerals and a letter indicating
decimal, value range, and tolerance
-W: Waffle Tray
P: 0.1%
R & U: 0.01%
S & V: 0.001%
T: Space 0.001%
Ω: D: 1% G: 2% J: 5% M: 10%
kΩ: E: 1% H: 2% K: 5% N: 10%
MΩ: F: 1% T: 2% L: 5% P: 10%
Termination Material: B: Solderable (SnPb solder over nickel)
Size: 11: RM0402
Temperature Characteristic (ppm/°C): K: ±100
Performance Specification MIL-PRF-55342
L: ±200
M: ±300
Mechanical
Length (a)
Width (b)
Thickness (c)
Top Termination (d)
Bottom Termination (e)
Approximate Weight
Inches
.042(.034 - .050)
.022(.017 - .027)
.018(.010 - .033)
.007(.005 - .015)
.009(.005 - .015)
0.00108 g
Millimeters
1.07(0.86 - 1.27)
0.56(0.43 - 0.69)
0.46(0.25 - 0.84)
0.18(0.13 - 0.38)
0.24(0.13 - 0.38)
.072
Recommended
Minimum
Bond Pads
(inches)
.025
.022
.026
State of the Art, Inc.
www.resistor.com
Specifications Subject to Change Without Notice
2470 Fox Hill Road, State College, PA, USA 16803-1797
Telephone: 814-355-8004 Toll Free: 800-458-3401 Fax: 814-355-2714
All Products Made in the USA
Copyright 2015 by State of the Art, Inc.
