Features
Regulated
Converters
●
●
●
●
●
●
●
●
●
●
●
●
2:1 Wide Input Voltage Range
5 Watts Regulated Output Power
1.6kVDC Isolation
Suffix “H “3kVDC Isolation
Low Profile, 10.2 mm Height
Over Current Protection
Five-Sided Shield
No Derating to 71°C
Non-Conductive Black Plastic
Ideal for Telecom/Networking
Standard DIP24 and SMD-Pinning
Efficiency to 81%
POWERLINE
DC/DC-Converter
RP05-
S_DF
Series
5 Watt
DIP24
&
SMD,
Single
&
Dual
Output
Selection Guide
5V, 12V, 24V and 48V Input Types
Part Number
DIP24 (SMD)
RP05-123.3SF**
RP05-1205SF**
RP05-1212SF**
RP05-1215SF**
RP05-243.3SF**
RP05-2405SF**
RP05-2412SF**
RP05-2415SF**
RP05-483.3SF**
RP05-4805SF**
RP05-4812SF**
RP05-4815SF**
RP05-1205DF**
RP05-1212DF**
RP05-1215DF**
RP05-2405DF**
RP05-2412DF**
RP05-2415DF**
RP05-4805DF**
RP05-4812DF**
RP05-4815DF**
Input
Range
VDC
9-18
9-18
9-18
9-18
18-36
18-36
18-36
18-36
36-75
36-75
36-75
36-75
9-18
9-18
9-18
18-36
18-36
18-36
36-75
36-75
36-75
Output
Voltage
VDC
3.3
5
12
15
3.3
5
12
15
3.3
5
12
15
±5
±12
±15
±5
±12
±15
±5
±12
±15
Output
Current
mA
1000
1000
470
400
1000
1000
470
400
1000
1000
470
400
±500
±230
±190
±500
±230
±190
±500
±230
±190
Input
(4)
Current
mA
404
579
618
658
202
278
306
325
100
141
153
162
571
605
625
282
299
309
143
149
154
Efficiency
(5)
%
72
76
80
80
72
79
81
81
73
78
81
81
77
80
80
78
81
81
77
81
81
Capacitive
(6)
Load max.
µF
2200
1000
220
150
2200
1000
220
150
2200
1000
220
150
±680
±100
±68
±680
±100
±68
±680
±100
±68
** add Suffix SMD for SMD package
Description
The F-Series of DC/DC Converters are fully certified to EN 60950: 2000. This makes them ideal for all
Telecom and safety applications where approved isolation is required.
198
April-2005
www.recom-international.com
POWERLINE
DC/DC-Converter
RP05-S_DF
Series
RP05-4805SF
125
100
75
Output Power (%)
50
25
0
-25
-10 0
50 60 70
80 90 100
Derating-Graph
(Ambient Temperature)
Natural Convection
Ambient Temperature Range (°C) 71
Derating graphes are valid only for the shown part numbers. If you need detailed derating-information about a
part-number not shown here please contact our technical customer service at info@recom-development.at
Specifications
(typical at nominal input and 25°C unless otherwise noted)
Input Voltage Range
12V nominal input
24V nominal input
48V nominal input
9-18VDC
18-36VDC
36-75VDC
Pi Type
12V Input
24V Input
48V Input
36VDC
50VDC
100VDC
150mAp-p
30ms typ.
5W max.
±2%
10% of FL
±0.2%
Single
Dual
±0.5%
±2%
±5%
3.3V, 5V
others
Temperature Coefficient
Transient Response (25% load step change)
Over Load Protection (% of full load at nominal Vin)
Short Circuit Protection
75mVp-p
1%/p-p of Vout max.
±0.02%/°C, max.
500µS
180% typ
Continuous, automatic recovery
continued on next page
www.recom-international.com
April-2005
199
Input Filter
Input Surge Voltage (100 ms max.)
Input Reflected Ripple (nominal Vin and full load)
Start Up Time (nominal Vin and constant resistor load)
Output Power
Output Voltage Accuracy (full Load and nominal Vin)
Minimum Load (see Note 1)
Line Regulation (LL-HL at full load)
Load Regulation (25% to 100% FL)
Cross Regulation (asymmetrical load 25%/100% FL)
Ripple and Noise (20MHz bandwith)
POWERLINE
DC/DC-Converter
Specifications
(typical at nominal input and 25°C unless otherwise noted)
Efficiency
Isolation Voltage
Isolation Resistance
Isolation Capacitance
Operating Frequency
Approved to Safety Standards
Operating Temperature Range
Storage Temperature Range
Thermal Shock
Vibration
Relative Humidity
Case Material
Base Material
Potting Material
Conducted Emissions
Radiated Emissions
ESD
Radiated Immunity
Fast Transient
Surge
Conducted Immunity
Weight
Dimensions
MTBF (see note 2)
EN55022
EN55022
EN61000-4-2
EN61000-4-3
EN61000-4-4
EN61000-4-5
EN61000-4-6
DIP
SMD
DIP
SMD
In to out Standard
Suffix /H
RP05-S_DF
Series
see „Selection Guide“ table
1.600VDC min.
3.000VDC min.
10
9
Ω
min.
300pF max.
100kHz min.
EN60950
-25°C to +71°C
-55°C to +105°C
MIL-STD-810D
10-55Hz, 2G, 30 Min. along X, Y and Z
5% to 95% RH
Non-conductive black plastic
Non-conductive black plastic
Epoxy (UL94-V0)
Level A
Level A
Perf. Criteria 2
Perf. Criteria 2
Perf. Criteria 2
Perf. Criteria 2
Perf. Criteria 2
14g
15g
31.8 x 20.3 x 10.2mm
32.0 x 20.3 x 10.9mm
3.731 x 10
6
Hours
Notes :
1. The RP05 series requires a minimum of 10% loading on the output to maintain specified regulation. Operation under
no-load condition will not damage these devices, however they may not meet all listed specification.
2. BELLCORE TR-NWT-000332. Case l: 50% Stress, Temperature at 40°C (Ground fixed and controlled environment).
H
3. Suffix “H” for 3.000VDC Isolation
4. Maximum value at nominal input voltage and full load of standard type.
5. Typical value at nominal input voltage and full load.
6. Test by minimum Vin and constant resistor load.
7. See application notes for EMI-filtering.
200
April-2005
www.recom-international.com
POWERLINE
DC/DC-Converter
Package Style and Pinning (mm)
DIP24 Package Style
RP05-S_DF
Series
3rd angle
projection
20.30
31.80
10.20
3.8
4.60
17.80
5.10
15.20
Pin Connections
Pin #
2
3
9
10
11
14
15
16
22
23
NC = No Connection
Single
–Vin
–Vin
NC
NC
NC
+Vout
NC
–Vout
+Vin
+Vin
Dual
–Vin
–Vin
Com
NC
–Vout
+Vout
NC
Com
+Vin
+Vin
0.25 x 0.50
Rectangular Pin
2 3
Bottom View
23 22
16 15 14
9 10 11
Pin Pitch Tolerance ±0.35 mm
SMD Package Style
32.00
31.40
11.20
10.90
3.81
6.35
20.30
SMD Package Style
Same spec. as the original DIP spec. and pin
definition, excl. of the SMD type pin.
2.54
21.30
25.40
Pin Connections
Pin #
Single
–Vin
–Vin
NC
NC
NC
+Vout
NC
–Vout
+Vin
+Vin
NC
Dual
–Vin
–Vin
Com
NC
–Vout
+Vout
NC
Com
+Vin
+Vin
NC
Pin area
0.1 x 0.50
1 2 3 4 5
0.50
9 10 11 12
2.54
1.60
2.40
23.40
Bottom View
24 23 22 21 20
16 15 14 13
26.54
24.14
1
Top View
2
3
9
10
11
14
15
16
22
23
Others
NC = No Connection
11 x 2.54
27.94
Pin Pitch Tolerance ±0.35 mm
www.recom-international.com
April-2005
201
