Bussmann
®
Fuseholders for GMT Type
Indicating Fuses
Dimensional Data
Printed Circuit Board Application
Shown With GMT Fuse Installed
.84"
(21.3mm)
HLS, HLT, PCT
Note: Similar Body Dimensions
of All Holders Are Identical.
.26"
(6.5mm)
.31" Approx.
(7.7mm)
.60"
(15.3mm)
.60"
(15.3mm)
1"
.13"
.1"
(25.4mm)
(25.4mm)
HLT
.19"
(3.2mm)
HLS
(4.8mm)
.25"
(6.4mm)
.18"
(4.8mm)
HLS-F
HLS-C
.25"
(6.4mm)
.13"
(3.2mm)
.41"
.25"
(6.4mm)
(10.4mm)
.07"
(1.8mm)
HLT-F
.84"
(21.3mm)
HLT-D
.63"
(15.9mm)
CATALOG SYMBOL: HLS, HLT, PCT
FUSEHOLDERS FOR GMT TYPE INDICATING FUSES
ELECTRICAL RATING–60V DC, 125V AC
U.L. RECOGNIZED (GUIDE # IZLT2, FILE E14853)
15AMP (60V DC)
Materials:
Body:
Terminals:
Wire Wrap Terminals
.025"
x
.063"
(.64mm)
(1.6mm)
.45"
(11.4mm)
.11"
(2.8mm)
PCT-A
PCT
Fuse Terminal
Alarm Terminal
.19"
(4.8mm)
Thermosplastic, U.L. 94VO flammability rating
Tin-plated bifrucated copper
Panel Mounting Data
.15"
(3.8mm)
Dia.
.16"
(3.9mm)
Dia.
.41"
(10.4mm)
(6.4mm)
x
"A" Spaces
Tolerance to be non-accumulative
.25"
For use with
GMT
Type Indicating Fuses
Multiple Fuseholders with bus bars
Ordering Information–Catalog No.
.86"
(21.8mm)
1.21"
(30.8mm)
.27"
(6.7mm)
.25"
(6.4mm)
.08" Dia. Holes
(2.1mm) (3 Holes Per Poles of Fuseholder)
Termination Location
Body Style
HLT
HLS
(No flanges)
No. of Poles
01
thru
25
(Min. of 2 poles required for bus bars)
L
(Left only)
R
(Right only)
B
(Both ends)
Bus Bar Position
P1†
(Inside–
Both Sides)
Type of bus bars used
B1*, B2, B3,
B4, B5, SL**
(Short Leads .135")
ML**
(Medium Leads .250")
** Not available with bus bars
P2
(Outside–
Both Sides)
P3
(Outside–
Right Only)
P4
(Outside–
Left Only)
B1
(Angle Bar Only)*
B2
("L" Bar Only)
B3
("U" Bar Only)
B4
(Angle & "L" Bars)
B5
("L" &"U" Bars)
* Angle Bar
mounts on common or center terminals only.
†Minimum of 4 Poles Required.
**SL
Version is not available with bus bars.
The only controlled copy of this BIF document is the electronic read-only version located on the Bussmann Network Drive. All other copies of this BIF document are by definition uncontrolled.This bulletin is intended to
clearly present comprehensive product data and provide technical information that will help the end user with design applications. Bussmann reserves the right, without notice, to change design or construction of any
products and to discontinue or limit distribution of any products. Bussmann also reserves the right to change or update, without notice, any technical information contained in this bulletin. Once a product has been select-
ed, it should be tested by the user in all possible applications.
12-21-98
SB98107
Rev. A
Form No. HLS, HLT, PCT
Page 1 of 1
BIF Doc #5010
