PC8110xNSZ0F Series
PC8110xNSZ0F
Series
DIP 4pin
High Speed under High Load Resistance
Photocoupler
■
Description
PC8110xNSZ0F Series
contains an IRED optically
coupled to a phototransistor built-in schottky barrier
diode.
It is packaged in a 4-pin DIP, and SMT gullwing
lead-form option.
Input-output isolation voltage(rms) is 5.0kV.
CTR is 50% to 400% at input current of 5mA.
■
Agency approvals/Compliance
1. Recognized by UL1577 (Double protection isolation),
file No. E64380 (as model No.
PC8110)
2. Package resin : UL flammability grade (94V-0)
■
Applications
1. Home appliances
■
Features
1. 4pin DIP package
2. Double transfer mold package (Ideal for Flow
Soldering)
3. High speed response at turn-off time due to built-in
schottky barrier diode (at saturation mode)
4. High isolation voltage between input and output
(V
iso(rms)
: 5kV)
5. RoHS directive compliant
Notice The content of data sheet is subject to change without prior notice.
In the absence of confirmation by device specification sheets, SHARP takes no responsibility for any defects that may occur in equipment using any SHARP
devices shown in catalogs, data books, etc. Contact SHARP in order to obtain the latest device specification sheets before using any SHARP device.
1
Sheet No.: D2-A03802FEN
Date Jun. 30. 2005
© SHARP Corporation
PC8110xNSZ0F Series
■
Internal Connection Diagram
Schottky barrier diode
1
1
4
3
4
2
3
5
Anode
Cathode
Emitter
Collector
■
Outline Dimensions
1. Through-Hole [ex.
PC8110xNSZ0F]
Rank mark
(Unit : mm)
2. SMT Gullwing Lead-Form [ex.
PC8110xNIZ0F]
Anode mark
1.2
±0.3
0.6
±0.2
Rank mark
Factory identification mark
Date code
1
4
Anode mark
1.2
±0.3
0.6
±0.2
Factory identification mark
Date code
1
4
8 1 1 0
2
3
4.58
±0.5
2
8 1 1 0
6.5
±0.5
3
2.54
±0.25
6.5
±0.5
7.62
±0.3
4.58
±0.5
0.5
TYP.
3.5
±0.5
2.54
±0.25
4.58
±0.3
7.62
±0.3
0.35
±0.25
0.26
±0.1
4.58
±0.5
2.7
±0.5
Epoxy resin
0.26
±0.1
θ
θ
: 0 to 13˚
θ
3.0
±0.5
1.0
+0.4
−0
Epoxy resin
10.0
+0
−0.5
1.0
+0.4
−0
2.54
±0.25
0.5
±0.1
Product mass : approx. 0.23g
Product mass : approx. 0.22g
Plating material : SnCu (Cu : TYP. 2%)
Sheet No.: D2-A03802FEN
2
3.5
±0.5
PC8110xNSZ0F Series
Date code (2 digit)
1st digit
Year of production
A.D
Mark
2002
A
2003
B
2004
C
2005
D
2006
E
2007
F
2008
H
2009
J
2010
K
2011
L
2012
M
·
·
N
·
2nd digit
Month of production
Month
Mark
January
1
February
2
March
3
April
4
May
5
June
6
July
7
August
8
September
9
October
O
November
N
December
D
A.D.
1990
1991
1992
1993
1994
1995
1996
1997
1998
1999
2000
2001
Mark
P
R
S
T
U
V
W
X
A
B
C
·
·
·
repeats in a 20 year cycle
Factory identification mark
Factory identification Mark
no mark
Japan
Indonesia
China
* This factory marking is for identification purpose only.
Please contact the local SHARP sales representative to see the actural status of the
production.
Country of origin
Rank mark
Refer to the Model Line-up table
Sheet No.: D2-A03802FEN
3
PC8110xNSZ0F Series
■
Absolute Maximum Ratings
Parameter
Symbol
I
F
Forward current
*1
Peak forward current
I
FM
Reverse voltage
V
R
P
Power dissipation
Collector-emitter voltage V
CEO
Emitter-collector voltage V
ECO
Collector current
I
C
Collector power dissipation
P
C
Total power dissipation
P
tot
*2
Isolation voltage
V
iso (rms)
T
opr
Operating temperature
Storage temperature
T
stg
*3
Soldering temperature
T
sol
(T
a
=25˚C)
Rating
Unit
50
mA
1.0
A
6
V
70
mW
V
70
V
0.1
mA
30
150
mW
200
mW
5.0
kV
−30
to
+100
˚C
−55
to
+125
˚C
260
˚C
*1 Pulse width≤100µs, Duty ratio : 0.001
*2 40 to 60%RH, AC for 1 minute, f=60Hz
*3 For 10s
■
Electro-optical Characteristics
Symbol
Parameter
V
F
Forward voltage
Peak forward voltage
V
FM
I
R
Reverse Current
Terminal capacitance
C
t
Collector dark current
I
CEO
*4
Collector-emitter breakdown voltage BV
CEO
Collector current
I
C
Collector-emitter saturation voltage V
CE (sat)
Isolation resistance
R
ISO
Floating capacitance
C
f
Rise time
t
r
Not saturated
Fall time
t
f
Turn-on time
t
on
Saturated 1 Storage time
t
s
Turn-off time
t
off
Turn-on time
t
on
Saturated 2 Storage time
t
s
Turn-off time
t
off
Response time
Conditions
I
F
=20mA
I
FM
=0.5A
V
R
=4V
V=0, f=1kHz
V
CE
=50V,
I
F
=0
I
C
=0.1mA,
I
F
=0
I
F
=5mA,
V
CE
=5V
I
F
=20mA,
I
C
=1mA
DC500V, 40 to 60%RH
V=0, f=1MHz
Output
Input
Input
Output
Transfer
charac-
teristics
V
CE
=2V,
I
C
=2mA,
R
L
=100Ω
V
CC
=5V,
I
C
=20mA,
R
L
=10kΩ
V
CC
=5V,
I
C
=20mA,
R
L
=100kΩ
MIN.
−
−
−
−
−
70
2.5
−
5×10
10
−
−
−
−
−
−
−
−
−
TYP.
1.2
−
−
30
−
−
−
0.15
10
11
0.6
3
2
2
9
23
3
10
27
MAX.
1.4
3.0
10
250
100
−
20
0.35
−
1.0
20
10
13
50
90
13
50
100
(T
a
=25˚C)
Unit
V
V
µA
pF
nA
V
mA
V
Ω
pF
µs
*4 The collector-emitter voltage has negative resistance characteristics since this device has built-in base-emitter resistor.
Therefore, please be careful not to provide the voltage that goes beyond absolute maximum ratings.
Sheet No.: D2-A03802FEN
4
PC8110xNSZ0F Series
■
Model Line-up
Through-Hole
100pcs/sleeve
PC81100NSZ0F
PC81101NSZ0F
PC81102NSZ0F
Model No.
PC81103NSZ0F
PC81105NSZ0F
PC81106NSZ0F
PC81108NSZ0F
Lead Form
Package
SMT Gullwing
2000pcs/reel
100pcs/sleeve
PC81100NIZ0F PC81100NIP0F
PC81101NIZ0F PC81101NIP0F
PC81102NIZ0F PC81102NIP0F
PC81103NIZ0F PC81103NIP0F
PC81105NIZ0F PC81105NIP0F
PC81106NIZ0F PC81106NIP0F
PC81108NIZ0F PC81108NIP0F
Rank mark
with or without
A
B
C
A or B
B or C
A, B or C
I
C
[mA]
(I
F
=5mA,
V
CE
=5V,
T
a
=25˚C)
2.5 to 20.0
3.0 to 6.0
5.0 to 10.0
7.5 to 15.0
3.0 to 10.0
5.0 to 15.0
3.0 to 15.0
Please contact a local SHARP sales representative to inquire about production status.
Sheet No.: D2-A03802FEN
5
