This document was generated on 11/16/2009
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Overview:
Description:
Documents:
3D Model
Drawing (PDF)
General
Product Family
Series
Application
Application
Overview
Product Name
Physical
Breakaway
Circuits (Loaded)
Circuits (maximum)
Color - Resin
Durability (mating cycles max)
First Mate / Last Break
Flammability
Glow-Wire Compliant
Guide to Mating Part
Keying to Mating Part
Lock to Mating Part
Material - Metal
Material - Plating Mating
Material - Plating Termination
Material - Resin
Number of Rows
Orientation
PC Tail Length (in)
PC Tail Length (mm)
PCB Locator
PCB Retention
PCB Thickness Recommended (in)
PCB Thickness Recommended (mm)
Packaging Type
Pitch - Mating Interface (in)
Pitch - Mating Interface (mm)
Plating min: Mating (µin)
Plating min: Mating (µm)
Plating min: Termination (µin)
Plating min: Termination (µm)
Polarized to Mating Part
Polarized to PCB
Shrouded
Stackable
Surface Mount Compatible (SMC)
Temperature Range - Operating
Termination Interface: Style
Electrical
0010511101
Active
5.08mm (.200") Pitch KK® Header, Vertical, with Square Pin, 10 Circuits
RoHS Certificate of Compliance (PDF)
PCB Headers
3008
Board-to-Board
Wire-to-Board
KK®
KK®
No
10
10
Natural
25
No
94V-2
No
No
None
None
Brass
Gold
Gold
Nylon
1
Vertical
0.180 In
4.57 mm
No
None
0.062 In
1.60 mm
Bag
0.200 In
5.08 mm
20
0.5
20
0.5
No
No
No
Yes
No
-40°C to +105°C
Through Hole
Series image - Reference only
EU RoHS
China RoHS
ELV and RoHS
Compliant
REACH SVHC
Not Reviewed
Halogen-Free
Status
Not Reviewed
Need more information on product
environmental compliance?
Email productcompliance@molex.com
Please visit the Contact Us section for any
non-product compliance questions.
Search Parts in this Series
3008 Series
Mates With
3001 KK® Crimp Terminal Housing
