This document was generated on 09/05/2012
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Overview:
Description:
Documents:
3D Model
Drawing (PDF)
51336-1610
Active
Mini Mi II ™
1.25mm Pitch Mini Mi II™ System Wire-to-Board IDT Housing, Single Row, 16 Circuits
Product Specification PS-51336-010 (PDF)
RoHS Certificate of Compliance (PDF)
Series
IDT and Solder Connectors
51336
Yes
Mini Mi II ™
Mini Mi II™
800756586694
image - Reference only
EU RoHS
ELV and RoHS
Compliant
REACH SVHC
Contains SVHC: No
Low-Halogen Status
Not Low-Halogen
China RoHS
General
Product Family
Series
Crimp Quality Equipment
Overview
Product Name
UPC
Physical
Circuits (Loaded)
Circuits (maximum)
Color - Resin
Durability (mating cycles max)
Gender
Glow-Wire Compliant
Lock to Mating Part
Material - Metal
Material - Plating Mating
Material - Plating Termination
Material - Resin
Net Weight
Number of Rows
Packaging Type
Panel Mount
Pitch - Mating Interface
Plating min - Mating
Plating min - Termination
Polarized to Mating Part
Stackable
Temperature Range - Operating
Termination Interface: Style
Wire Insulation Diameter
Wire Size AWG
16
16
Natural
30
Female
No
Yes
Phosphor Bronze
Tin
Tin
Polyester
482.600/mg
1
Bag
No
1.25mm
0.914µm
0.914µm
Yes
No
-40°C to +105°C
IDT or Pierce
0.80-0.90mm
26, 28
Need more information on product
environmental compliance?
Email productcompliance@molex.com
For a multiple part number RoHS Certificate of
Compliance, click here
Please visit the Contact Us section for any
non-product compliance questions.
Search Parts in this Series
51336Series
Mates With
55447 Vertical Header, 55454 Right Angle
Header
Application Tooling
|
FAQ
Tooling specifications and manuals are
found by selecting the products below.
Crimp Height Specifications are then
contained in the Application Tooling
Specification document.
Global
Description
Product #
IDT System Hand
0621009800
Crimper
Electrical
Current - Maximum per Contact
Voltage - Maximum
1.5A
100V
Material Info
Reference - Drawing Numbers
Product Specification
Sales Drawing
PS-51336-010, RPS-51336-004, RPS-51336-005,
RPS-51336-006, RPS-51336-009
SD-51336-001
