TAP10Y296UE datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> capacitor> TAP10Y296UE

TAP10Y296UE: DescriptionFilm Capacitor, Polypropylene, 10% +Tol, 5% -Tol, 29uF, Chassis Mount, RADIAL LEADED; CategoryPassive components capacitor; File Size152KB，6 Pages; ManufacturerNIPPON CHEMI-CON; Websitehttp://www.chemi-con.co.jp

Download Datasheet Parametric Compare View All

TAP10Y296UE Overview

Film Capacitor, Polypropylene, 10% +Tol, 5% -Tol, 29uF, Chassis Mount, RADIAL LEADED

TAP10Y296UE Parametric

Parameter Name	Attribute value
package instruction	,
Reach Compliance Code	unknow
ECCN code	EAR99
Other features	RATED AC VOLTAGE(V): 100
capacitance	29 µF
Capacitor type	FILM CAPACITOR
dielectric materials	POLYPROPYLENE
Manufacturer's serial number	TAP
Installation features	CHASSIS MOUNT
negative tolerance	5%
Number of terminals	2
Maximum operating temperature	75 °C
Minimum operating temperature	-25 °C
Package shape	RECTANGULAR PACKAGE
positive tolerance	10%
surface mount	NO
Terminal shape	LUG
Base Number Matches	1

Preview

Download Datasheet

View All

TAP

Series

Large Film

Polypropylene

AC Rated

Voltage

UL810 Approved

75 C

Maximum

Temperature

Actual

Size

FILM - VAC RATED

TAP

The TAP series offers higher capacitance values when compared to the FAN series. The maximum

capacitance value for the TAP series capacitors is 29 F, which allows for a larger capacitance range

than the FAN series. The TAP series capacitors are available with 5% to 10% tolerance, and the

variety of lead terminals, lug, fasten or radial wire lead, allow for many mounting styles. All models are

available with an optional mounting tab.

Summary of Specifications

Lug, radial or fasten lead terminals.

Capacitance range: 0.7 to 29µF.

Voltage range: 100 to 400VAC at 50-60Hz.

Operating temperature range: 25 C to 75 C.

Standard capacitance tolerance: 5% to 10%

Nominal case size (L W H): 31.0 14.5 23.5mm to 58.0

Rated lifetime: 800 hours at 75 C.

29.0 41.0mm.

United Chemi-Con, Inc. 9801 W. Higgins Road, Rosemont, IL 60018 Tel 847-696-2000 Fax 847-696-9278 www.chemi-con.com

TAP10Y296UE Related Products

	TAP10Y296UE	TAP20Y296UE
Description	Film Capacitor, Polypropylene, 10% +Tol, 5% -Tol, 29uF, Chassis Mount, RADIAL LEADED	Film Capacitor, Polypropylene, 10% +Tol, 5% -Tol, 29uF, Chassis Mount, RADIAL LEADED
Reach Compliance Code	unknow	unknow
ECCN code	EAR99	EAR99
Other features	RATED AC VOLTAGE(V): 100	RATED AC VOLTAGE(V): 200
capacitance	29 µF	29 µF
Capacitor type	FILM CAPACITOR	FILM CAPACITOR
dielectric materials	POLYPROPYLENE	POLYPROPYLENE
Manufacturer's serial number	TAP	TAP
Installation features	CHASSIS MOUNT	CHASSIS MOUNT
negative tolerance	5%	5%
Number of terminals	2	2
Maximum operating temperature	75 °C	75 °C
Minimum operating temperature	-25 °C	-25 °C
Package shape	RECTANGULAR PACKAGE	RECTANGULAR PACKAGE
positive tolerance	10%	10%
surface mount	NO	NO
Terminal shape	LUG	LUG
Base Number Matches	1	1
