KBPC100 SERIES
3.0 AMPERE SINGLE-PHASE SILICON BRIDGE RECTIFIER
VOLTAGE RANGE
50 to 1000 Volts
CURRENT
3 Amperes
FEATURES
Plastic material has Underwriters Laboratory
flammability classification 94V-0.
Low leakage.
Surge overload rating - 50 amperes peak.
Ideal for printed circuit boards.
Exceeds environmental standards of
MIL - STD - 19500.
Ø 3.8
+
11.3
10.3
~
15.8
14.7
2.7
1.7
~
Ø 0.8
±
19.0
min
6.9
5.8
MECHANICAL DATA
Case
:
:
:
Terminals :
:
Polarity :
Weight :
Reliable low cost construction utilizing
moulded plastic technique results in
inexpensive product.
Leads, solderable per MIL - STD - 202,
Method 208.
Polarity symbols printed on body.
0.13 ounce, 3.8 grams.
Dimensions in millimetres
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25°C ambient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load. For capacitive load, derate current by 20%.
KBPC1005 KBPC101 KBPC102 KBPC103 KBPC104 KBPC106 KBPC108 KBPC110
Maximum Recurrent Peak Reverse Voltage
Maximum Bridge Input Voltage RMS
Maximum DC Blocking Voltage
Maximum Average Forward Current at
(see Fig 2)
V
RRM
V
RMS
V
DC
T
C
= 50°C* I
F(AV)
T
A
= 50°C**
50
35
50
100
70
100
200
140
200
300
210
300
3.0
2.0
50
1.2
10.0
1.0
- 55 to + 125
- 55 to + 150
400
280
400
600
420
600
800
560
800
1000
700
1000
V
V
V
A
A
V
µA
mA
°C
°C
Peak Forward Surge Current, 8.3 ms single
I
FSM
half sine - wave super-imposed on rated load (see Fig 1)
Maximum Forward Voltage Drop
(see Fig 3) V
F
per Element at 1.5A DC
T
A
= 25°C
Maximum Reverse Current at Rated DC
Blocking Voltage per Element (see Fig 4)
T
A
= 100°C I
R
Operating Temperature Range
Storage Temperature Range
Notes * Unit mounted on metal heatsink.
** Unit mounted on P.C board.
T
J
T
STG
Reformatted by Anglia 9907
E-MAIL:
info@angliac.com
WEB:
www.angliac.com
RATING AND CHARACTERISTIC CURVES
KBPC100 SERIES
FIG 1 : MAXIMUM NON-REPETITIVE
SURGE CURRENT PER ELEMENT
50
5
PEAK FORWARD SURGE
CURRENT, AMPERES
40
8.3ms Single Half Sine Wave
T
J
= 125°C
30
20
10
AVERAGE FORWARD OUTPUT
CURRENT, AMPERES
4
3
2
1
0
FIG 2 : DERATING CURVE FOR
RECTIFIED OUTPUT CURRENT
CA
SE
AM
BIE
NT
0
1
10
NUMBER OF CYCLES AT 60Hz
100
0
50
100
150
TEMPERATURE °C
FIG 3 : TYPICAL FORWARD
CHARACTERISTICS PER ELEMENT
10
T
J
= 25°C
Pulse Width = 300µs
10
INSTANTANEOUS FORWARD
CURRENT, AMPERES
1.0
INSTANTANEOUS REVERSE
CURRENT, MICROAMPERES
50
FIG 4 : TYPICAL REVERSE
CHARACTERISTICS PER ELEMENT
T
A
= 125°C
1.0
0.1
0.1
T
A
= 25°C
.01
0.6
0.8
1.0
1.2
1.4
1.6
.01
0
20
40
60
80
100
120
140
INSTANTANEOUS FORWARD
VOLTAGE, VOLTS
PERCENT OF RATED PEAK
REVERSE VOLTAGE
