series 28
HiPer-D Accessories
D-subminiature gender changer
289-057P, 289-058S
HiPer-D Gender Changers provide a convenient way to change the gender of an
interface to allow attachment of a mismatched cable. Two styles are available:
male-male and female-female. Machined metal housing protects circuits from
EMI problems. Contacts are heavy gold plated for improved durability. Available
in standard density and high density contact arrangements. Intermateable with
standard M24308-type connectors. Pin mating face has fluorosilicone rubber seal.
Choose electroless nickel or gold shell finish for avionics and space applications.
Choose cadmium for compatibility with cadmium or zinc plated M24308 connectors,
or choose nickel-PTFE for maximum corrosion protection. Other materials and
finishes available on request.
ordering Information
Sample Part Number
Shell Size - Contact Arrangements
3S25
ME
N
1
Contact Size and Qty
Shell Size-
Contact Arr.
#20
#22
Standard Density
1S9
9
2S15
15
3S25
25
4S37
37
5S50
1H15
2H26
3H44
4H62
5H78
6H104
50
High Density
15
26
44
62
78
104
289-057P
289-057P
= Male-Male with Pin
Contacts
289-058S
= Female-Female with
Socket Contacts
Basic Part Number
Shell Size-
Contact Arrangement
Contact Arrangements are shown in the
adjacent table
ME
= Electroless Nickel (RoHS)
MT
= Nickel-PTFE (RoHS)
JF
= Cadmium with Yellow Chromate
Z2
= Gold (RoHS)
Z1
= Passivated Stainless Steel (RoHS)
Omit for 289-058S. Applies to 289-057P Male-Male
adapter only.
G
= Supplied with EMI Ground Spring
N
= No Ground Spring
1
= Captive #4-40 Male Screwlocks on Both Ends
2
= #4-40 Female Jackposts on Both Ends
3
= Captive #4-40 Male Screwlocks on One End, #4-40 Fe-
male Jackposts on One End
2.000 (50.8)
MALE
SCREWLOCK
Finish
Ground Spring
Schematic
EXAMPLE WIRING DIAGRAM
3S25 INSERT ARRANGEMENT
S1
1
2
S2
1
2
Mating Hardware
FEMALE
JACKPOST
B
24
25
24
25
E
B
± 0.38
12.55
12.55
12.55
12.55
15.37
16.97
A
Shell
Size
1
2
3
4
5
6
± .015
1.213
1.541
2.088
2.729
2.635
2.729
Dimensions
A
in
mm
in
± 0.38
30.81
39.14
53.04
69.32
66.93
69.32
± .015
.494
.494
.494
.494
.605
.668
mm
E-19
© 2013 Glenair, Inc • 1211 Air Way, Glendale, CA 91201 • 818-247-6000 • www.glenair.com • U.S. CAGE code 06324
