Wirewound Surface Mount Inductors
s
or
-101K
-121K
-151K
-181K
-221K
-271K
-331K
-391K
-471K
-561K
-681K
-821K
-102K
0.10
0.12
0.15
0.18
0.22
0.27
0.33
0.39
0.47
0.56
0.68
0.82
1.0
M
MU
NI
MI
SERIES 4232 PHENOLIC CORE
250
25
20
220
25
20
180
25
20
165
25
19
135
25
19
120
25
17
200
25
17
180
25
17
140
25
17
120
25
15
110
25
15
100
25
10
90
25
10
0.45
0.50
0.54
0.61
0.68
0.72
0.76
0.84
0.92
1.06
1.25
1.40
1.50
519
493
474
446
442
410
400
380
363
338
312
294
284
Temperature Stable for critical conditions
Physical Parameters
Inches
Millimeters
A
0.118 to 0.138
3.00 to 3.51
B
0.085 to 0.105
2.16 to 2.67
C
0.081 to 0.101
2.06 to 2.57
D
0.016 Min.
0.41 Min.
E
0.041 to 0.061
1.04 to 1.55
F
0.070 (Ref. only)
1.78 (Ref. only)
G
0.054 (Ref. only)
1.37 (Ref. only)
Dimensions “A” and “C” are over terminals.
Weight Max.
(Grams) 0.1
Operating Temperature
–55°C to +125°C
Current Rating at 90°C Ambient
35°C Rise
Maximum Power Dissipation at 90°C Ambient
Phenolic: 0.168 W
Iron: 0.287 W
Note
For applications requiring improved characteristics
over typical ferrite core inductors of the same size, see
1210 Series for values lower than 0.10µH.
Marking
SMD; dash number with tolerance letter; date
code (YYWWL). Note: An R before the date code indicates
a RoHS component.
Example: 4232R-562F
SMD
562F
R 0909A
Packaging
Tape & reel (8mm): 7" reel, 2000 pieces max.;
13" reel, 7000 pieces max.
Made In the U.S.A.
Optional Tolerances: J = 5% H = 3% G = 2% F = 1%
*Complete part # must include series # PLUS the dash #
For surface finish information,
refer to www.delevanfinishes.com
-122K
-152K
-182K
-222K
-272K
-332K
-392K
-472K
-562K
-682K
-822K
-103K
-123K
-153K
-183K
-223K
-273K
-333K
-393K
-473K
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10.0
12.0
15.0
18.0
22.0
27.0
33.0
39.0
47.0
SERIES 4232 IRON CORE
83
7.9
30
75
7.9
30
65
7.9
30
55
7.9
30
50
7.9
30
47
7.9
30
45
7.9
30
40
7.9
30
36
7.9
30
22
7.9
30
21
7.9
30
20
7.9
30
18
2.5
30
17
2.5
30
16
2.5
30
15
2.5
30
14
2.5
30
13
2.5
30
12
2.5
30
10
2.5
30
0.90
1.00
1.10
1.20
1.25
1.30
1.40
1.80
2.00
2.40
3.00
4.30
5.80
6.50
7.20
8.00
8.80
9.20
10.8
11.4
480
455
434
416
407
399
385
339
322
294
263
220
189
179
170
161
153
150
139
135
For more detailed graphs, contact factory
