ALUMINUM ELECTROLYTIC CAPACITORS
ZG
3.95mmL MAX. Chip Type,
Wide Temperature Range
series
Chip type with 3.95mmLMAX height. Operating over wide
temperature range of – 40
~ +105°C.
Designed for surface mounting on high density PC board.
Applicable to automatic mounting machine using carrier tape.
ZT
Smaller
ZG
Specifications
Item
Category Temperature Range
Rated Voltage Range
Performance Characteristics
– 40 ~ +105°C
6.3 ~ 50V
± 20% at 120Hz, 20°C
After 2 minutes' application of rated voltage, leakage current is not more than 0.01 CV or 3 (µA) , whichever is greater.
Rated voltage (V)
tan
δ
(MAX.)
Rated voltage (V)
Impedance ratio Z–25°C / Z+20°C
ZT / Z20 (MAX.) Z–40°C / Z+20°C
6.3
0.38
6.3
6
10
10
0.32
10
5
10
16
0.20
16
3
6
25
0.16
25
3
6
35
0.14
35
3
4
50
0.14
50
3
4
Within ±30% of initial value
300% or less of initial specified value
Initial specified value or less
Rated Capacitance Range
0.1 ~ 100µF
Capacitance Tolerance
Leakage Current
tan
δ
120Hz
20°C
120Hz
Stability at Low
Temperature
Endurance
Shelf Life
Resistance to
soldering heat
Marking
After 1000 hours' application of rated voltage at 105°C,
capacitors meet the characteristic requirements listed at right.
Capacitance change
tan
δ
Leakage current
After leaving capacitors under no load at 105°C for 1000 hours, they meet the specified value for endurance characteristics listed above.
The capacitors shall be kept on the hot plate maintained at 250°C for 30
seconds. After removing from the hot plate and restored at room temperature,
they meet the characteristic requirements listed at right.
Black print on the case top.
Capacitance change
tan
δ
Leakage current
Within ±10% of initial value
Initial specified value or less
Initial specified value or less
Chip Type
Positive
0.5 MAX.
Voltage
Lot No.
Series
Plastic platform
0.3 MAX.
Type numbering system (Example : 16V 10
µ
F)
1
(mm)
6.3
2.4
6.6
6.6
2.2
2
3
4
5
6
7
8
9 10 11 12 13 14
C±0.2
U ZG 1 C 1 0 0 MCR 1 GB
A±0.2 A±0.2
φD
A
B
C
E
4
1.8
4.3
4.3
1.0
5
2.1
5.3
5.3
1.3
Taping code
Configuration
Capacitance tolerance (±20%)
Rated Capacitance (10µF)
Rated voltage (16V)
Series name
Type
X2
10C
ZG
φD±0.5
B±0.2
Capacitance
3.90
+0.05
–0.2
Voltage
V
Code
6.3
j
10
A
16
C
25
E
35
V
50
H
0.5 ~ 0.8
Dimensions
V
Cap. (µF)
Code
6.3
0J
10
1A
E
Negative
16
1C
25
1E
35
1V
4
4
4
4
4
4
4
5
6.3
50
1H
0.9
2.2
2.8
3.3
5.4
9.6
12.
16.
26.
0.1
0.22
0.33
0.47
1
2.2
3.3
4.7
10
22
33
47
100
0R1
R22
R33
R47
010
2R2
3R3
4R7
100
220
330
470
101
4
5
5
6.3
19
26
32
52
5
5
6.3
24
30
40
4
5
6.3
6.3
16
26
35
44
4
5
6.3
6.3
11
20
33
42
4
5
6.3
13
22
36
Case size
φ
D (mm)
Rated
ripple
Rated Ripple (mA rms) at 105°C 120Hz
Frequency coefficient of rated ripple current
Frequency
Coefficient
50 Hz
0.70
120 Hz
1.00
300 Hz
1.17
1 kHz
1.36
10 kHz~
1.50
Taping specifications are given in page 22.
Recommended land size are given in page 23
Please refer to page 3 for the minimum order quantity.
CAT.8100T
