YAGeo CorPorATIoN
INDUCTORS / BEADS
NLV Series
APPLICATIONS
Microtelevisions, liquid crystal televisions, video cameras, portable VCrs, car radios, car stereos, thin tape
radios, television tuners, mobile telephones, radios and other electronic devices.
SMD Wire Wound
Chip Inductors
OUTLINE
These revolutionary, highly reliable wound chip inductors for automatic mounting have been developed
in response to the trend toward high density in electronic equipment.
With metal terminals and a body of heat resistant resin, NL Series (molded type) offers many superior
features.
PRODUCT IDENTIFICATION
NLV
☐☐☐☐☐☐
T
☐☐☐☐
-
☐
FEATURES
Very strong solderability by flow soldering, soldering iron or wave soldering.
Highly accurate dimensions can be mounted automatically.
Terminals are highly resistant to pull forces.
Highly resistant to mechanical shocks and pressure.
Highly reliable in environments of sudden temperature change and humidity.
Super Q characteristics.
■
Packaging: T = Tape and reel, B = Bulk
■
Internal No.: N = Lead-Free
Internal No.
Tolerance
Inductance
Packaging Style
Dimensions
Product Symbol
SHAPES AND DIMENSIONS
Unit: mm
XXX
B
F
C
TYPE
A
B
C
D
E
Ref.
F
Ref.
1.8
A
E
D
NLV322522
3.2 ± 0.2
2.5 ± 0.2
2.2 ± 0.2
1.7 ± 0.2
0.7
52
ELECTRICAL CHARACTERISTICS
PART NO.
IMPEDANCE
(µH)
NLV322522T-10N□-N
NLV322522T-12N□-N
NLV322522T-15N□-N
NLV322522T-18N□-N
NLV322522T-22N□-N
NLV322522T-27N□-N
NLV322522T-33N□-N
NLV322522T-39N□-N
NLV322522T-47N□-N
NLV322522T-56N□-N
NLV322522T-68N□-N
NLV322522T-82N□-N
NLV322522T-r10□-N
NLV322522T-r12□-N
NLV322522T-r15□-N
NLV322522T-r18□-N
NLV322522T-r22□-N
NLV322522T-r27□-N
NLV322522T-r33□-N
NLV322522T-r39□-N
NLV322522T-r47□-N
NLV322522T-r56□-N
NLV322522T-r68□-N
NLV322522T-r82□-N
NLV322522T-1r0□-N
NLV322522T-1r2□-N
NLV322522T-1r5□-N
NLV322522T-1r8□-N
NLV322522T-2r2□-N
NLV322522T-2r7□-N
NLV322522T-3r3□-N
NLV322522T-3r9□-N
NLV322522T-4r7□-N
NLV322522T-5r6□-N
NLV322522T-6r8□-N
NLV322522T-8r2□-N
0.010
0.012
0.015
0.018
0.022
0.027
0.033
0.039
0.047
0.056
0.068
0.082
0.10
0.12
0.15
0.18
0.22
0.27
0.33
0.39
0.47
0.56
0.68
0.82
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
TOLERANCE
(±%)
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
Q
Min.
15
17
19
21
23
23
25
25
26
26
27
27
28
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
TEST
FREQUENCY
(MHz)
100
100
100
100
100
100
100
100
100
100
100
100
100
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
SRF
(MHz)
Min.
2,500
2,300
2,100
1,900
1,700
1,500
1,400
1,300
1,200
1,100
1,000
900
700
500
450
400
350
320
300
250
220
180
160
140
120
100
85
80
75
70
60
55
50
45
40
35
DC
RESISTANCE
(Ω) Max.
0.13
0.14
0.16
0.18
0.20
0.22
0.24
0.27
0.30
0.33
0.36
0.40
0.44
0.22
0.25
0.28
0.32
0.36
0.40
0.45
0.50
0.55
0.60
0.65
0.70
0.75
0.85
0.90
1.00
1.10
1.20
1.30
1.50
1.60
1.80
2.00
RATED
CURRENT
(mA) Max.
450
450
450
450
450
450
450
450
450
450
450
450
450
450
450
450
450
450
450
450
450
450
450
450
400
390
370
350
320
290
260
250
220
200
180
170
Note:
Tolerance: J = ± 5%, K = ± 10%
Test Instruments: L/Q- HP4285A
SrF- HP4291A
rDC- CH502BC
IDC- Ho4284A+HP42841A
53
ELECTRICAL CHARACTERISTICS
PART NO.
IMPEDANCE
(µH)
TOLERANCE
(±%)
Q
Min.
TEST
FREQUENCY
(MHz)
NLV322522T-100□-N
NLV322522T-120□-N
NLV322522T-150□-N
NLV322522T-180□-N
NLV322522T-220□-N
NLV322522T-270□-N
NLV322522T-330□-N
NLV322522T-390□-N
NLV322522T-470□-N
NLV322522T-560□-N
NLV322522T-680□-N
NLV322522T-820□-N
NLV322522T-101□-N
NLV322522T-121□-N
NLV322522T-151□-N
NLV322522T-181□-N
NLV322522T-221□-N
NLV322522T-271□-N
NLV322522T-331□-N
NLV322522T-391□-N
NLV322522T-471□-N
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
5 / 10
30
30
30
30
30
30
30
30
30
30
30
30
20
20
20
20
20
20
20
20
20
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
SRF
(MHz)
Min.
30
20
20
20
20
20
17
16
15
13
12
11
10
10
8
7
7
6
5
5
4
DC
RESISTANCE
(Ω) Max.
2.10
2.50
2.80
3.30
3.70
5.00
5.60
6.40
7
8
9
10
10
11
15
17
21
28
34
36
40
RATED
CURRENT
(mA) Max.
150
140
130
120
110
80
70
65
60
55
50
45
40
70
65
60
50
45
40
35
25
Note:
Tolerance: J = ± 5%, K = ± 10%
Test Instruments: L/Q- HP4285A
SrF- HP4291A
rDC- CH502BC
IDC- Ho4284A+HP42841A
