LSM OSCILLATOR
30 kHz to 200 kHz
TM
Low Power Surface Mount Crystal Oscillator
DESCRIPTION
actual size
The LSM oscillator has the highest accuracy, stability and
lowest current of all STATEK surface mount oscillators.
The design consists of a hermetically-sealed CX-4
STATEK crystal, and a CMOS-compatible integrated
circuit. The hybrid design is hermetically-sealed with a
kovar lid in a surface mount ceramic package. Permanent
precision tuning of the oscillator is accomplished by laser
trimming the crystal.
side view
PACKAGE DIMENSIONS
2
FEATURES
3
Low power consumption
Low aging
CMOS compatible
Double hermetically sealed package
Full military testing available
3.3 Volt operation available
Optional Tri-State
Low harmonic noise
APPLICATIONS
1
4
F
TYP.
DIM
A
B
C*
D
E
F
G
INCHES
.400
.180
.071
.200
.080
.050
.055
mm
10.16
4.57
1.80
5.08
2.03
1.27
1.40
.405
.185
.079
.205
.085
.058
.063
MAX.
INCHES
mm
10.29
4.70
2.00
5.21
2.16
1.47
1.60
Industrial, Computer & Communications
General purpose clock oscillator
Data logger
Remote sensor
Real Time Clock
Medical test and diagnostics
Military
Portable field communication
Military high speed modem
Flight recorder
.068 [1.73]
.064 [1.63]
Termination material is Au over Ni (SM1), solder dip
(SM3) also available.
*SM1 Termination; SM3 = .084 in. (2.13mm) Max.
SUGGESTED LAND PATTERN
.075 [1.91]
GRID
PLACEMENT
COURTYARD
.132 [3.35]
INCHES[mm]
.200 [5.08]
10151 - Rev B
STATEK CORPORATION 512 N. MAIN ST., ORANGE, CA 92868 714-639-7810 FAX: 714-997-1256 www.statek.com
SPECIFICATIONS: LSM 32.768 kHz****
ABSOLUTE MAXIMUM RATINGS
Specifications are typical at 25oC unless otherwise noted.
Specifications are subject to change without notice.
Supply Voltage*
Calibration Tolerance**
5V
A:
B:
C:
Frequency Stability***
0
O
C to +50
O
C
-20 C to+70 C
Voltage Coefficient
Aging
Shock
Vibration
Frequency Change vs
10%Output Load Change
O
O
Supply Voltage V
DD
Storage Temperature
Process Temperature
-0.3V to 7V
-55
O
C to +125
O
C
260
O
C 20 sec.
+
_
+
_
+
_
+
_
10% (3.3V available)
.001% (10ppm)
.0025%
.01%
Typ.
MAX.
Typ.
MAX.
25ppm
40ppm
+
_
70ppm
+
_
100ppm
+
_
+
_
ELECTRICAL CHARACTERISTICS
LSM 32.768 kHz
All parameters are measured at ambient temperature
with a 10M and 10pF load at 5V.
SYMBOL PARAMETER
V
OH
V
OL
t
r
t
f
SYM
I
DD
Output Voltage Hi
Output Voltage Lo
Rise Time (10%-90%)
Fall Time (10%-90%)
Duty Cycle
Supply Current
V
DD
=5V
V
DD
=3.3V
PIN CONNECTIONS
0.0025%
+
_
0.004%
+
_
0.007%
+
_
0.01%
+
_
+
_
MIN.
4.8
TYP. MAX. UNIT
4.95
0.05 0.2
12
12
50
8.3
5.5
25
25
60
15
10
V
V
nsec.
nsec.
%
A
A
1 ppm/V Typ.
+
_
3 ppm/V MAX.
+
_
1 ppm/year Typ.
+
_
3 ppm/year MAX.
1000g, 1msec.,1/2 sine
+
_
3 ppm MAX.
10g rms, 10 - 2000 Hz
+
_
3 ppm MAX.
+
_
40
Pin
Connection
Output Enable or NC
Ground
Output
V
DD
1 ppm MAX.
1
2
3
4
Operating Temperature -10
O
C to +70
O
C Commercial
-40
O
C to +85
O
C Industrial
-55
O
C to +125
O
C Military
* Contact the factory for lower voltage.
** Tighter tolerances available.
*** Does not include calibration tolerance. Positive variations small compared
to negative variations (See data sheet 10103).
**** Contact the factory for other frequencies.
PACKAGING
LSM
-Tray Pack (Standard)
-16mm tape, 7” or 13” reels (Optional)
Per EIA 481 (see data sheet 10109)
TYPICAL CURRENT CONSUMPTION,
LSM-32.768 kHz
OUTPUT WAVE FORM
CURRENT (uA)
12
10
8
6
4
2
3
4
V (Volts)
DD
V
DD
V
OH
90%*
10%*
5
6
7
V
OL
0
* Of
V
DD
t
r
t
f
HOW TO ORDER LSM SURFACE MOUNT CRYSTAL OSCILLATORS
LSM
3
S
T
SM3
32.768 kHz
(
A
/
I
)
3=3.3V
Blank=5V (Std.)
“S” if special
or custom
design.
Blank if Std.
*T = Tri-State
Blank = Pin 1
no connection
Frequency
Blank= SM1 (Std.)
SM1 = Gold Plated
SM3 = Solder Dipped
*Tri-state not available 100 kHz to 200 kHz
**Other calibration fill in ppm
Frequencies other than 32.768 kHz
_
A:
+
0.01%
_
B:
+
0.03%
+
0.1%
C:
_
**Calibration
Tolerance
@ 25
O
C
(A)
(B)
(C)
Temp. Range:
C = Commercial
I = Industrial
M = Military
S = Specify
10151 - Rev B
STATEK CORPORATION 512 N. MAIN ST., ORANGE, CA 92868 714-639-7810 FAX: 714-997-1256 www.statek.com
