KSD5701
KSD5701
High Voltage Color Display Horizontal
Deflection Output
(Damper Diode Built In)
• High Collector-Base Voltage : V
CBO
=1500V
• High Switching Speed : t
F
= 0.4µs (Max.)
• For Color TV
B
Equivalent Circuit
C
1
50Ω typ.
E
TO-3PF
2.Collector
3.Emitter
1.Base
NPN Triple Diffused Planar Silicon Transistor
Absolute Maximum Ratings
T
C
=25°C unless otherwise noted
Symbol
V
CBO
V
CEO
V
EBO
I
C
I
CP
P
C
T
J
T
STG
Collector-Base Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
Collector Current (DC)
Collector Current (Pulse)
Collector Dissipation (T
C
=25°C)
Junction Temperature
Storage Temperature
Parameter
Value
1500
800
6
3.5
10
50
150
- 55 ~ 150
Units
V
V
V
A
A
W
°C
°C
Electrical Characteristics
T
C
=25°C unless otherwise noted
Symbol
I
CBO
I
EBO
h
FE1
h
FE2
V
CE
(sat)
V
BE
(sat)
f
T
V
F
t
F
Parameter
Collector Cut-off Current
Emitter Cut-off Current
DC Current Gain
Collector-Emitter Saturation Voltage
Base-Emitter Saturation Voltage
Current Gain Bandwidth Product
Damper Diode Turn On Voltage
Fall Time
Test Condition
V
CB
= 800V, I
E
= 0
V
EB
= 4V, I
C
= 0
V
CE
= 5V, I
C
= 0.5A
V
CE
= 5V, I
C
= 2.5A
I
C
= 2.5A, I
B
= 0.8A
I
C
= 2.5A, I
B
= 0.8A
V
CE
= 10V, I
C
= 0.5A
I
F
= 3.5A
V
CC
= 200V, I
C
= 3A
I
B1
= 0.8A, I
B2
= - 1.6A
R
L
= 66.7Ω
3
2
0.4
Min.
40
10
2.5
Typ.
Max.
10
250
30
5
1.5
V
V
MHz
V
µs
Units
µA
mA
©2000 Fairchild Semiconductor International
Rev. A, February 2000
KSD5701
Typical Characteristics
8
100
V
CE
= 5V
7
I
C
[A], COLLECTOR CURRENT
5
4
3
I
B
= 2.0A
I
B
= 1.8A
I
B
= 1.6A
I
B
= 1.4A
I
B
= 1.2A
I
B
= 1.0A
I
B
= 0.8A
I
B
= 0.6A
I
B
= 0.4A
I
B
= 0.2A
h
FE
, DC CURRENT GAIN
6
10
2
1
0
0
1
2
3
4
5
6
7
8
9
10
1
0.1
1
10
V
CE
[V], COLLECTOR-EMITTER VOLTAGE
I
C
[A], COLLECTOR CURRENT
Figure 1. Static Characteristic
Figure 2. DC current Gain
100
8
V
CE
(sat)[V], SATURATION VOLTAGE
V
CE
= 5V
7
I
C
[A], COLLECTOR CURRENT
10
I
C
= 5 I
B
10
6
5
1
4
I
C
= 3 I
B
3
0.1
2
1
0.01
0.1
1
0
0.0
0.2
0.4
0.6
0.8
1.0
1.2
1.4
1.6
I
C
[A], COLLECTOR CURRENT
V
BE
[V], BASE-EMITTER VOLTAGE
Figure 3. Collector-Emitter Saturation Voltage
Figure 4. Base-Emitter On Voltage
t
F
[
µ
S], COLLECTOR CURRENT FALL TIME
1.0
10
0.8
t
STG
[
µ
S], STORAGE TIME
8
6
0.6
I
C
= 1.5A
4
I
C
= 2.5A
I
C
= 2.0A
0.4
I
C
= 2.5A
I
C
= 2.0A
I
C
= 1.5A
2
0.2
0.0
0.2
0.4
0.6
0.8
1.0
1.2
1.4
0
0.0
0.2
0.4
0.6
0.8
1.0
1.2
1.4
dI
B
/dt[A/
µ
S], BASE CURRETN GRADIENT
dI
B
/dt[A/
µ
S], BASE CURRETN GRADIENT
Figure 5. Switching Characteristic 1
Figure 6. Switching Characteristic 2
©2000 Fairchild Semiconductor International
Rev. A, February 2000
