M254FCN8.0000MHZ

Description
HCMOS Output Clock Oscillator, 8MHz Nom, ROHS COMPLIANT, LEADLESS, CERAMIC PACKAGE-4
CategoryPassive components    oscillator
File Size356KB,2 Pages
ManufacturerMtronPTI
Websitehttp://www.mtronpti.com
Environmental Compliance
Download Datasheet Parametric View All

M254FCN8.0000MHZ Overview

HCMOS Output Clock Oscillator, 8MHz Nom, ROHS COMPLIANT, LEADLESS, CERAMIC PACKAGE-4

M254FCN8.0000MHZ Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
Objectid2038493960
Reach Compliance Codeunknown
maximum descent time6 ns
Frequency Adjustment - MechanicalNO
frequency stability50%
JESD-609 codee4
Installation featuresSURFACE MOUNT
Number of terminals4
Nominal operating frequency8 MHz
Maximum operating temperature85 °C
Minimum operating temperature-10 °C
Oscillator typeHCMOS
Output load2 TTL, 15 pF
physical size7.0mm x 5.0mm x 1.9mm
longest rise time6 ns
Maximum supply voltage3.6 V
Minimum supply voltage3 V
Nominal supply voltage3.3 V
surface mountYES
maximum symmetry45/55 %
Terminal surfaceNickel/Gold (Ni/Au)
M2 Series
5x7 mm, 3.3 Volt, HCMOS/TTL Compatible Output, Clock Oscillator
DENOTES PIN 1
PARAMETER
Frequency Range
Operating Temperature
Storage Temperature
Frequency Stability
Aging
st
1 Year
Thereafter (per year)
Input Voltage
Input Current
Electrical Specifications
Symbol
F
T
A
T
S
F/F
Min.
Typ.
Max.
1.0
135
(See ordering information)
-55
+125
(See ordering information)
±3
±2
3.3
Units
MHz
°C
Condition/Notes
See Note 1
Vdd
Idd
3.0
Standby Current
Output Type
Load
Symmetry (Duty Cycle)
Logic “1” Level
Logic “0” Level
Output Current
Rise/Fall Time
3.6
10
20
30
55
10
ppm
ppm
V
mA
mA
mA
mA
µA
Voh
Vol
NOTE:
A capacitor of value 0.01
µF or greater between Vdd and
Ground is recommended.
2 TTL or 15 pF
(See ordering information)
90% Vdd
Vdd -0.5
10% Vdd
0.5
±4
V
V
V
V
mA
1.000 to 20.000 MHz
20.001 to 50.000 MHz
50.001 to 67.000
67.001 to 135.000 MHz
“Q” Output Type
HCMOS/TTL Compatible
See Note 2
½ Vdd
HCMOS Load
TTL Load
HCMOS Load
TTL Load
Standby/Tristate Function
Pin Connections
Environmental
Start up Time
Random Jitter
Mechanical Shock
Vibration
Hermeticity
Thermal Cycle
Solderability
Soldering Conditions
See Note 3
6
ns
1.500 to 50.000 MHz
4
ns
50.001 to 80.000 MHz
2
ns
80.001 to 135.000 MHz
Input Logic “1” or floating: output active
Input Logic “0”; output disables to high-Z
10
ms
Rj
4
10
ps RMS
1-Sigma
Per MIL-STD-202, Method 213, Condition C (100 g’s, 6 mS duration, ½ sinewave)
Per MIL-STD-202, Method 201 & 204 (10 g’s from 10-2000 Hz)
-8
Per MIL-STD-202, Method 112, (1x10 atm. cc/s of Helium)
Per MIL-STD-883, Method 1010, Condition B (-55°C to +125°C, 15 min. dwell, 10 cycles)
Per EIAJ-STD-002
See solder profile, Figure 1
Tr/Tf
1. Consult factory for availability of higher frequencies.
2. HCMOS Load - See Load circuit diagram #2. Consult factory with nonstandard output load requirements.
3. Rise/Fall times are measured between 0.5 V and 2.4 V with TTL load, and between 10% Vdd and 90% Vdd with
HCMOS load.
MtronPTI reserves the right to make changes to the product(s) and service(s) described herein without notice. No liability is assumed as a result of their use or application.
Please see
www.mtronpti.com
for our complete offering and detailed datasheets. Contact us for your application specific requirements: MtronPTI
1-800-762-8800.
Revision:6-18-10
