F-212 SUPPLEMENT
TM
SCP2, SCR2 SERIES
SCP2–17–32–F–03.00–T–T
SCR2–17–32–F–00.50–S–S1
IP68 SEALED HIGH DENSITY SYSTEM
Mates with:
SCR2
SCP2
SIZE
NO. OF
PINS
PLATING
WIRE
LENGTH
END 1
OPTION
END 2
OPTION
SPECIFICATIONS
For complete specifications
see www.samtec.com?SCP2
Insulator Material:
PBT
Terminal Material:
FILE NO. E337115
Brass Alloy
Wire:
24 AWG
Sealed Overmold:
PA66
RoHS Compliant:
Yes
–10
–10, –17
= 10 Pins
(Size –10 only)
–F
= Gold
Flash
–02.00
= (2m) 78.74”
–S
= Socket
–S
= Socket
–32
(28,00)
1.102
–03.00
= (3m) 118.11”
–T
= Terminal
–T
= Terminal
= 32 Pins
(Size –17 only)
–05.00
= (5m) 196.85”
Assembled Length = Wire Length + (24,62) .969
(9,50) .374 DIA
–BC
= Blunt Cut
ALSO AVAILABLE
Single ended and custom
wire lengths available.
Other applications:
Ethernet: See SCPE Series
USB: See SCPU Series
Power: See SCP1 Series
Tiger Eye
™
: See SCP3 Series
Note:
Some lengths,
styles and options are
non-standard, non-returnable.
(1,02)
.040
DIA
–SE
= Socket
Extension
–10
(42,00)
1.65
–17
CURRENT RATING
AMBIENT
SCP2/SCR2/IPL1
TEMP
20°C
5A
40°C
4.2A
60°C
3.5A
75°C
2.8A
6 POSITIONS (2x3) POWERED
Mates with:
SCP2, IPL1
SCR2
SIZE
NO. OF
PINS
PLATING
WIRE
LENGTH
END 1
OPTION
END 2
OPTION
SPECIFICATIONS
For complete specifications and
recommended panel hole layout
see www.samtec.com?SCR2
Insulator Material:
PBT
Panel Contacts:
FILE NO. E337115
Phosphor Bronze
Board Contacts:
Phosphor Bronze
Wire:
24 AWG
RoHS Compliant:
Yes
–10
–10, –17
™
= 10 Pins
(Size –10 only)
–F
= Gold
Flash
–00.25
= (0.25m) 9.84”
–S
= Socket
–S1
= Plastic
Latch
Mini Mate
®
Socket
–32
= 32 Pins
(Size –17 only)
SIZE
A
(9,5) .374
(12,7) .50
–00.50
= (0.50m) 19.69”
–T
= Terminal
–10
–17
–S2
= Metal
Latch
Mini Mate
®
Socket
(31,80)
1.252
Assembled Length = Wire Length + (19,16) .754
See IPD1
& MMSD Series
(39,90)
1.571
DIA
APPLICATION
SPECIFIC OPTION
• Single ended and custom
wire lengths available.
• Without keyed polarization.
Call Samtec.
–10
–BC
= Blunt Cut
ALSO AVAILABLE
A
DUST CAPS
SIZE SCPX
SCRX
PANEL PLUGS
SIZE
SCRX
(48,45) 1.907
–10
–17
DCA-10-02 DCA-10-01
DCA-17-02 DCA-17-01
–10
–17
SCPPA-10-01
SCPPA-17-01
Note:
This Series is
non-standard, non-returnable.
–17
Cable shipped with panel mount hardware but not assembled.
