CFF4309-0150F: DescriptionCard Edge Connector, 9 Contact(s), 1 Row(s), Female, Right Angle, Surface Mount Terminal,; CategoryThe connector The connector; File Size201KB，2 Pages; ManufacturerSMK; Websitehttps://www.smk.co.jp/

Download Datasheet Parametric View All

CFF4309-0150F Overview

Card Edge Connector, 9 Contact(s), 1 Row(s), Female, Right Angle, Surface Mount Terminal,

CFF4309-0150F Parametric

Parameter Name	Attribute value
Reach Compliance Code	unknow
Other features	LIF
Connector type	FFC/FPC CONNECTOR
Contact to complete cooperation	GOLD
Contact completed and terminated	GOLD
Contact point gender	FEMALE
DIN compliance	NO
Filter function	NO
IEC compliance	NO
JESD-609 code	e4
MIL compliance	NO
Mixed contacts	NO
Installation method	RIGHT ANGLE
Installation type	BOARD
Number of rows loaded	1
Options	GENERAL PURPOSE
Terminal pitch	1 mm
Termination type	SURFACE MOUNT
Total number of contacts	9
UL Flammability Code	94V-0
Base Number Matches	1

Preview

Download Datasheet

View All

FFC Connectors

FC-10

Series

1.0mm Pitch (SMT & DIP Type)

●

SMT Type CFF23

-0150F

No. of Pins /

極数

A

6.6

A

2.1

0.4

6.1

3.9(Inserted size)

3.2

■

Features

1. Utilization of an LIF structure allows for simple

and easy insertion.

2. Choice of versions available, such as SMT, DIP

types, and lower or upper contact type.

1.5

■

Specification

1. Rating : 0.5A, 50V AC/DC

2. Contact Resistance : 30mΩ max., initially

3. Insulation Resistance : 1000MΩ min. at 500V DC

4. Withstanding Voltage : 500V AC (for one minute)

5. Operating Temperature Range : –25˚C to +85˚C

A

A 6.0

●

DIP Type CFF51

-0150F

No. of Pins /

極数

■

Materials and Plating

●

Housing : Thermoplastic Resin,

Natural Color, 94V-0

●

Contact : Cu Alloy, Au Plating

■

Note

Please contact our local sales agent for supply

on embossed tape.

A

6.6

A

2.1

0.4

0.6

1.0

0.35

1.3

0.25

3.2

■ 特長

1. LIF構造ですので、½操½で挿入できます。

2. SMTタイプ、DIPタイプ、上接点、下接点と各種

レパートリーを取揃えています。

1. 定格電圧電流：AC/DC 50V 0.5A

2. 接触抵抗：初期30mΩ以下

3. 絶縁抵抗：DC 500V 1000MΩ以上

4. 耐電圧：AC 500V (1分間)

5. ½用温度範囲：–25℃∼+85℃

1.0

A

3.3

■ 仕様

5.5

3.9 (Inserted size)

2.0

■ 材質・表面処理

●

No. of Pins

05

06

07

08

09

10

11

12

13

14

15

16

17

5

6

7

8

9

10

11

12

13

14

15

16

17

A

4.0

5.0

6.0

7.0

8.0

9.0

10.0

11.0

12.0

13.0

14.0

15.0

16.0

18

19

20

21

22

23

24

25

26

27

28

29

30

No. of Pins

18

19

20

21

22

23

24

25

26

27

28

29

30

A

17.0

18.0

19.0

20.0

21.0

22.0

23.0

24.0

25.0

26.0

27.0

28.0

29.0

ハウジング：熱可塑性樹脂原色 94V-0

コンタクト：銅合金金めっき

■ 特記

エンボスの有無については別途ご相談下さい。

※

Please contact us about No. of pins.

対応極数については別途お問い合わせ下さい。

5.5
