M
www.vishay.com
Vishay Dale Thin Film
High Reliability Thick Film Resistor,
Surface Mount Chip
FEATURES
• High purity alumina substrate for high power
dissipation (2 W max.)
• Wraparound terminations featuring a thin film
Available
adhesion layer covered with a leach resistant
nickel barrier layer for + 150 °C operating
Available
conditions
• High speed laser trimming for high volume
requirements
Available
• Ruthenium based cermet thick film for
dependable performance
Available
• Fired-on glass passivation
• Tape and reel packaging standard; static-free
waffle pack available
• Active trim and 0
chips
• Sulfur resistant (per ASTM B809-95 humid vapor test)
• Material categorization: For definitions of compliance
please see
www.vishay.com/doc?99912
Note
*
This datasheet provides information about parts that are
RoHS-compliant and/or parts that are non-RoHS-compliant. For
example, parts with lead (Pb) terminations are not RoHS-compliant.
Please see the information/tables in this datasheet for details.
Actual
Size
0502
Utilizing proven expertise in thick and thin film resistors to
satisfy your manufacturing needs, Vishay provides a high rel
chip with the same reliability and stability found in military
grade resistors. These chips are available in the widest
range of sizes, values, and performance characteristics. And
manufactured on the Mil-PRF-55342 qualified controlled
production line All product is 100 % electrical tested for
tolerance and after thermal shock testing and typically meet
the requirements of group A in MIL-PRF-55342
performance.
CONSTRUCTION
Resistor
Overglaze
TYPICAL PERFORMANCE
ABSOLUTE
Alumina
Substrate
Inner Electrode
Nickel Barrier
Plated
Solder
TCR
TOL.
100
1
STANDARD ELECTRICAL SPECIFICATIONS
TEST
Material
Resistance Range
TCR: Absolute
Tolerance: Absolute
Stability: Absolute
Stability: Ratio
Voltage Coefficient
Working Voltage
Operating Temperature Range
Storage Temperature Range
Noise
Shelf Life Stability: Absolute
SPECIFICATIONS
Ruthenium
10
to 25 M
± 100 ppm/°C to ± 300 ppm/°C
± 1 % to ± 10 %
R
± 0.15 %
-
-
25 V to 200 V
- 55 °C to + 125 °C
- 55 °C to + 150 °C
< - 35 dB (typical)
-
CONDITIONS
-
-
- 55 °C to + 125 °C
-
-
-
-
-
-
-
-
-
COMPONENT RATINGS
CASE SIZE
(1)
POWER RATING (mW)
0402
100
0502
100
0504
125
0505
125
0603
150
0705
200
0805
200
1005
250
1010
500
1206
330
1505
350
2010
1000
2208
750
2512
2000
Notes
• Consult factory for nominals above 25 M
(1)
0705 and 0805 are the same (only use 0805 when ordering)
Revision: 05-Nov-13
WORKING VOLTAGE (V)
25
25
40
40
40
50
50
75
75
100
100
175
150
200
RESISTANCE RANGE ()
10 to 10M
10 to 25M
10 to 25M
10 to 25M
10 to 25M
10 to 25M
10 to 25M
10 to 25M
10 to 25M
10 to 25M
10 to 25M
10 to 25M
10 to 25M
10 to 25M
Document Number: 60031
1
