The Miniature Amplified line of pressure sensors is based upon technology developed over years of development in the pressure sensor
industry. This model provides a ratiometric 4-volt output with superior output characteristics. The sensor housing has been designed
specifically to reduce package induced parasitic stress and strain. In addition the sensor utilizes a silicon, micromachined, stress concentra-
tion enhanced structure to provide a very linear output to measured pressure.
These calibrated and temperature compensated sensors give an accurate and stable output over a wide temperature range. Each sensor is
internally compensated using an ASIC compensation technique. This series is intended for use with non-corrosive, non-ionic working fluids
such as air, dry gases and the like.
The output of the device is ratiometric to the supply voltage over a supply voltage range of 4.5 to 5.5 volts.
f
408 225 2079
a
16035 Vineyard Blvd. Moragtn Hill, CA 95037
p
408 225 4314
e
www.allsensors.com
Physical Dimensions
0.50
(12.7)
B-port
A-port
Pin 1 2 3 4
0.10
Typical
(2.54)
0.080 O.D.
(2.00)
0.30
(7.6)
0.62
(15.7)
0.380
D1 version
or G verison
D2 version
Equivalent Circuit
All
Sensors
DS-0103 Rev A
all sensors
Pressure Sensor Ratings
Supply Voltage, Vs
Common-mode pressure
Lead Temperature, max
(soldering 2-4 sec.)
+4.5 to +5.5 Vdc
-10 to +10 psig
250°C
Environmental Specifications
Temperature Ranges
Compensated
Operating
Storage
Humidity Limits
5 to 50° C
-25 to 85° C
-40 to 125° C
0 to 95% RH
(non condensing)
Standard Pressure Ranges
Part Number
0.3 PSI-Dx-4V-MINI
0.3 PSI-G-4V-MINI
1 PSI-Dx-4V-MINI
1 PSI-G-4V-MINI
5 PSI-Dx-4V-MINI
5 PSI-G-4V-MINI
15 PSI-A-4V-MINI
15 PSI-Dx-4V-MINI
15 PSI-G-4V-MINI
30 PSI-A-4V-MINI
30 PSI-Dx-4V-MINI
30 PSI-G-4V-MINI
BARO-A-4V-MINI
Operating Pressure
±0.3 PSI
0 - 0.3 PSI
±1 PSI
0 - 1 PSI
± 5 PSI
0 - 5 PSI
0 - 15 PSIA
±15 PSI
0 - 15 PSI
0 - 30 PSIA
±30 PSI
0 - 30 PSI
600 - 1100 mbar
Nominal Span
4V
4V
4V
4V
4V
4V
4V
4V
4V
4V
4V
4V
4V
Proof Pressure
5 PSI
5 PSI
5 PSI
5 PSI
15 PSI
15 PSI
45 PSI
45 PSI
45 PSI
60 PSI
60 PSI
60 PSI
45 PSI
Burst Pressure
10 PSI
10 PSI
10 PSI
10 PSI
30 PSI
30 PSI
60 PSI
60 PSI
60 PSI
60 PSI
60 PSI
100 PSI
60 PSI
Performance Characteristics for 0.3 PSI-Dx-4V-MINI
Parameter, note 1
Operating Range, differential pressure
Output Span, note 5
Offset Voltage @ zero differential pressure
Offset Temperature Shift (5°C-50°C), note 2
Linearity, hysteresis error, note 4
Span Shift (5°C-50°C), note 2
±1.90
2.15
Minimum
Nominal
±0.3
±2.0
2.25
±2.10
2.35
±40
±0.5
±2
Maximum
Units
PSI
volt
volt
mvolt
%fs
%span
Specification Notes
NOTE
1: A
LL PARAMETERS ARE MEASURED AT
5.0
VOLT EXCITATION
,
FOR THE NOMINAL FULL SCALE PRESSURE AND ROOM TEMPERATURE UNLESS OTHERWISE SPECIFIED
. P
RESSURE MEASUREMENTS
ARE WITH POSITIVE PRESSURE APPLIED TO
P
ORT
B.
NOTE
2: S
HIFT IS RELATIVE TO
25°C.
NOTE
3: S
HIFT IS WITHIN THE FIRST HOUR OF EXCITATION APPLIED TO THE DEVICE
.
NOTE
4: M
EASURED AT ONE
-
HALF FULL SCALE RATED PRESSURE USING BEST STRAIGHT LINE CURVE FIT
.
NOTE
5: T
HE VOLTAGE ADDED TO THE OFFSET VOLTAGE AT FULL SCALE PRESSURE
. N
OMINALLY THE OUTPUT VOLTAGE RANGE IS
0.25
TO
4.25
VOLTS FOR MINUS TO PLUS FULL SCALE PRESSURE
.
M ii u e Amplified Output Medium Pressure Sensor
nat r
Performance Characteristics for 0.3 PSI-G-4V-MINI
Parameter, note 1
Operating Range, gage pressure
Output Span, note 5
Offset Voltage @ zero pressure
Offset Temperature Shift (5°C-50°C), note 2
Linearity, hysteresis error, note 4
Span Shift (5°C-50°C), note 2
3.90
0.15
Minimum
Nominal
0.3
4.0
0.25
4.10
0.35
±40
±0.5
±2
Maximum
Units
PSI
volt
volt
%fs
%span
Performance Characteristics for 1 PSI-D-4V-MINI
Parameter, note 1
Operating Range, differential pressure
Output Span, note 5
Offset Voltage @ zero differential pressure
Offset Temperature Shift (5°C to 50°C), note 2
Linearity, hysteresis error, note 4
Span Shift (5°C to 50°C), note 2
±1.90
2.15
Minimum
Nominal
±1.0
±2.0
2.25
±2.10
2.35
±40
±0.5
±1
Maximum
Units
PSI
volt
volt
mvolt
%fs
%span
Performance Characteristics for: 1 PSI-G-4V-MINI
Parameter,
NOTE
1
Operating Range, gage pressure
Output Span,
NOTE
Minimum
Nominal
1.0
Maximum
Units
PSI
Offset Voltage @ zero pressure
Offset Temperature Shift (5°C to 50°C), note 2
Linearity, hysteresis error, note 4
Span Shift (5°C to 50°C), note 2
0.15
0.25
0.35
±40
±0.5
±1
volt
mvolt
%fs
%span
Performance Characteristics for: 5 PSI-D-4V-MINI
Parameter,
NOTE
1
Operating Range, differential pressure
Output Span,
NOTE
5
Offset Voltage @ zero differential pressure
Offset Temperature Shift (5°C to 50°C), note 2
Linearity, hysteresis error, note 4
Span Shift (5°C to 50°C), note 2
±1.90
2.15
Minimum
Nominal
±5.0
±2.0
2.25
±2.10
2.35
±20
±0.5
±1
Maximum
Units
PSI
volt
volt
mvolt
%fs
%span
All
Sensors
DS-0103 Rev A
a
16035 Vineyard Blvd. Moragtn Hill, CA 95037
p
408 225 4314
5
3.90
4.0
4.10
volt
f
408 225 2079
e
www.allsensors.com
all sensors
mvolt
Performance Characteristics for: 5 PSI-G-4V-MINI
Parameter,
NOTE
1
Operating Range, gage pressure
Output Span,
NOTE
Minimum
Nominal
5.0
Maximum
Units
PSI
5
3.90
0.15
4.0
0.25
4.10
0.35
±20
±0.5
±1
volt
volt
mvolt
%fs
%span
Offset Voltage @ zero pressure
Offset Temperature Shift (5°C to 50°C), note 2
Linearity, hysteresis error, note 4
Span Shift (5°C to 50°C), note 2
Performance Characteristics for 15 PSI-A-4V-MINI
Parameter, note 1
Operating Range, absolute pressure
Output Span, note 5
Offset Voltage @ zero pressure
Offset Temperature Shift (5°C to 50°C), note 2
Linearity, hysteresis error, note 4
Span Shift (5°C to 50°C), note 2
Minimum
0
3.90
0.15
4.0
0.25
Nominal
Maximum
15
4.10
0.35
±20
±0.5
±1
Units
psia
volt
volt
mvolt
%fs
%span
Performance Characteristics for 15 PSI-Dx-4V-MINI
Parameter, note 1
Operating Range, differential pressure
Output Span, note 5
Offset Voltage @ zero differential pressure
Offset Temperature Shift (5°C to 50°C), note 2
Linearity, hysteresis error, note 4
Span Shift (5°C to 50°C), note 2
±1.90
2.15
Minimum
Nominal
±15.0
±2.0
2.25
±2.10
2.35
±20
±0.5
±1
Maximum
Units
PSI
volt
volt
mvolt
%fs
%span
Performance Characteristics for BARO-A-4V-MINI
Parameter, note 1
Operating Range, absolute pressure
Output Span, note 5
Offset Voltage @ zero pressure
Offset Temperature Shift (5°C to 50°C), note 2
Linearity, hysteresis error, note 4
Span Shift (5°C to 50°C), note 2
Minimum
600
3.90
0.15
4.0
0.25
Nominal
Maximum
1100
4.10
0.35
±20
±0.5
±1
Units
mBar
volt
volt
mvolt
%fs
%span
Pressure Response: for any pressure applied the response time to get to 90% of pressure applied is typically less than 100 useconds.
All Sensors reserves the right to make changes to any products herein. All Sensors does not assume any liability arising out of the application or use of any product or circuit described
herein, neither does it convey any license under its patent rights nor the rights of others.
M ii u e Amplified Output Medium Pressure Sensor
nat r
Performance Characteristics for 15 PSI-G-4V-MINI
Parameter, note 1
Operating Range, gage pressure
Output Span, note 5
Offset Voltage @ zero pressure
Offset Temperature Shift (5°C to 50°C), note 2
Linearity, hysteresis error, note 4
Span Shift (5°C to 50°C), note 2
3.90
0.15
Minimum
Nominal
15.0
4.0
0.25
4.10
0.35
±20
±0.5
±1
Maximum
Units
PSI
volt
volt
mvolt
%fs
%span
Performance Characteristics for 30 PSI-Dx-4V-MINI
Parameter, note 1
Operating Range, differential pressure
Output Span, note 5
Offset Voltage @ zero differential pressure
Offset Temperature Shift (5°C to 50°C), note 2
Linearity, hysteresis error, note 4
Span Shift (5°C to 50°C), note 2
±1.90
2.15
Minimum
Nominal
±30.0
±2.0
2.25
±2.10
2.35
±20
±0.5
±1
Maximum
Units
PSI
volt
volt
mvolt
%fs
%span
Performance Characteristics for 30 PSI-G-4V-MINI
Parameter, note 1
Operating Range, gage pressure
Output Span, note 5
Offset Voltage @ zero pressure
Offset Temperature Shift (5°C to 50°C), note 2
Linearity, hysteresis error, note 4
Span Shift (5°C to 50°C), note 2
3.90
0.15
Minimum
Nominal
30.0
4.0
0.25
4.10
0.35
±20
±0.5
±1
Maximum
Units
PSI
volt
volt
mvolt
%fs
%span
Performance Characteristics for 30 PSI-A-4V-MINI
Parameter, note 1
Operating Range, absolute pressure
Output Span, note 5
Offset Voltage @ zero pressure
Offset Temperature Shift (5°C to 50°C), note 2
Linearity, hysteresis error, note 4
Span Shift (5°C to 50°C), note 2
Specification Notes
NOTE
Minimum
Nominal
30.0
Maximum
Units
PSI
3.90
0.15
4.0
0.25
4.10
0.35
±20
±0.5
±1
volt
volt
mvolt
%fs
%span
1: A
LL
2:
3:
4:
5:
PARAMETERS ARE MEASURED AT
5.0
VOLT EXCITATION
,
FOR THE NOMINAL FULL SCALE PRESSURE AND ROOM TEMPERATURE UNLESS OTHERWISE SPECIFIED
.
P
RESSURE
P
ORT
B.
S
HIFT IS RELATIVE TO
25°C.
NOTE
S
HIFT IS WITHIN THE FIRST HOUR OF EXCITATION APPLIED TO THE DEVICE
.
NOTE
M
EASURED AT ONE
-
HALF FULL SCALE RATED PRESSURE USING BEST STRAIGHT LINE CURVE FIT
.
NOTE
T
HE VOLTAGE ADDED TO THE OFFSET VOLTAGE AT FULL SCALE PRESSURE
. N
OMINALLY THE OUTPUT
SCALE PRESSURE
.
MEASUREMENTS ARE WITH POSITIVE PRESSURE APPLIED TO
There are temperature measurement solutions on the Internet, but the receiving end is mostly positioned in the application of mobile phones or tablets. This proposal is positioned to use a single-chip...
[color=#000][size=14px]2017 National College Student Electronic Design Competition[/size][/color] [color=#000][size=14px]List of instruments and main components[/size][/color] [color=#000][size=14px][...
Is there any engineer or company that has the ability, experience and time to make Bluetooth controlled stepper motor driver hardware and firmware? Mobile phone APP controls the motor via Bluetooth. C...
[p=28, 2, left][font=宋体][color=#000000]The design of analog circuits is the most troublesome but also the most fatal design part for engineers. Although the development of digital circuits and large-s...
In PCB design, especially in high-frequency circuits, we often encounter some irregular and abnormal phenomena caused by ground interference. This article analyzes the causes of ground interference, i...
With the booming electronics industry, vision systems have become a leader in the electronics automation sector. However, the delicate nature of electronic products often affects product yields due...[Details]
There are many different ways of human-computer interaction. The more common ones are listed below:
Mouse interaction: Using a mouse to operate a computer and interact was the most common human...[Details]
Most of the houses we live in now are elevator buildings, mainly because it is more convenient to go up and down the stairs! It can also make life more comfortable. It even helps to increase the ad...[Details]
On August 24th, media outlets reported, citing sources, that NavInfo, a listed company on the A-share market, is nearing completion in its acquisition of the intelligent driving c...[Details]
1. Introduction
Electronic scales are gradually replacing traditional measuring tools like springs and balances in everyday life, such as electronic price computing scales and electronic weigh...[Details]
Zos Automotive Research Institute released the "2025
Smart Cockpit
Tier 1 Research Report (Domestic Edition)."
This report analyzes the operating conditions of more than a dozen ...[Details]
On August 22, according to the Ministry of Industry and Information Technology's official website, my country's first mandatory national standard for the control of hazardous substances in electric...[Details]
As the scale and business applications of national e-government networks continue to expand, the data and services transmitted over them are becoming increasingly sensitive and critical. To protect...[Details]
Tires are a very important component for cars. They are related to the driving experience of the vehicle. We are almost inseparable from cars in our daily lives. For tires, according to the role of...[Details]
The complexity of the integrated circuits (ICs) used in electronic systems in vehicles is increasing. They aim to execute artificial intelligence (AI) algorithms to control autonomous driving funct...[Details]
Normally, we determine our location and where we want to go by comparing our surroundings with observation and simple GPS tools. However, this kind of reasoning is very difficult for self-driving c...[Details]
According to Nikkei, Japan has performed poorly in responding to China's power semiconductor challenges.
There are five major companies in Japan's power chip market: Mitsubishi Electric,...[Details]
Electric vehicles will revolutionize transportation, changing fuel consumption, carbon emissions, costs, maintenance, and driving habits. Currently, a major selling point for electric vehicles is t...[Details]
introduction
With the development of society, people's requirements for the quality of refrigerated and frozen foods are constantly improving. The changes in food appearance and nutritional co...[Details]
AI distributed rendering architecture improves mobile phone rendering capabilities, and game performance tests can check frame generation indicators in real time
Shanghai, China, Aug...[Details]
Wireless Connectivity
京公网安备 11010802033920号
EEWORLD
