538-014D9.0-35 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> capacitor> 538-014D9.0-35

538-014D9.0-35: DescriptionVariable Capacitor, Ceramic, 200V, 9pF Min, 35pF Max, Vertical Adjuster, Chassis Mount,; CategoryPassive components capacitor; File Size32KB，1 Pages; ManufacturerCTS

Download Datasheet Parametric View All

538-014D9.0-35 Overview

Variable Capacitor, Ceramic, 200V, 9pF Min, 35pF Max, Vertical Adjuster, Chassis Mount,

538-014D9.0-35 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Objectid	4000178546
package instruction	,
Reach Compliance Code	compliant
Regulator direction	VERTICAL
Maximum capacitance	35 pF
Minimum capacitance	9 pF
Capacitor type	VARIABLE CAPACITOR
dielectric materials	CERAMIC
Installation features	CHASSIS MOUNT
multiple turns
Maximum operating temperature	85 °C
Minimum operating temperature	-55 °C
Rated (DC) voltage (URdc)	200 V
surface mount	NO
Terminal shape	LUG

Preview

Download Datasheet

View All
