Last Update:
6-11-10
Dimensions: mm (in.)
Ref. #:
MS-101037
8.70
(.343)
1.78
(.07)
23
2.03
(.08)
1.02
(.04)
POS.1
POS.2
POS.3
(ON)
2-3
3.81
(.15)
2 Comm.
3
1
OFF
OPEN
(ON)
2-1
1
2 Comm.
3
1.02
(.04)
3.25
(.128)
P.C. Mounting
1
Switch Function
4.35
(.171)
8.13
(.32)
6.20
(.244)
1.70
(.067)
7.64
(.30)
10.16
(.40)
Epoxy Seal
3.15
(.124)
8.23
(.325)
2.67
(.105)
10.41
(.41) max.
.51
(.02)
.76
(.03)
1
2
5.08
(.20)
3
Mechanical Specifications:
•
Mechanical Life: 50,000 make-and-break cycles
•
Operating Temperature: -30°C to 85°C
Electrical Specifications:
•
Rating: 0.4VA Max./20V AC or DC Max.
•
Contact Resistance: 20mΩ max. initial @ 2-4VDC 100mA
•
Insulation Resistance: 1,000MΩ min.
•
Dieletric Strength: 1,000 V RMS@sea level
260±5°C Duration of solder immersion: 5±1 seconds
Note:
•
RoHS Compliant by Exemption
Soldering Process:
•
Wave soldering: Recommended soldering temperature:
(PCB is 1.6mm in thickness)
Sealed Sub-Miniature Toggle Switch
108-2BS4T1T48-EVX
Available from Mouser Electronics
www.mouser.com
1-800-346-6873
Specifications are subject to change without notice. No liability or warranty implied by this information. Environmental compliance based on producer documentation.
