STACKED D-SUBMINIATURE
KYCON
RoHS
Documentation &
Ordering Information
Drawing
Sample
Kycon Part #
K42X Series
Stock
CofC
RFQ
Email
K42X-E15S/P-A
/
E15
P
Part Builder
K42X
E15
S
A
Center Board Jack Plating
Series Top Shell Size Bottom
Connector Shell Size Distance Lock Screws Option
Type
Connector
K42X Series Dual-Port D-Sub
Dimensions in mm
C
B
A1
Series
K42X - Dual-Port D-Subminiature Connector
K42X
2.84
D
E
E9/9
E9/9 - 9 Contacts
A15/15
A15/15 - 15 Contacts
B25/25
B25/25 - 25 Contacts
C37/37
C37/37 - 37 Contacts
E15/15
E15/15 - 15 Contacts (High Density)
Top/Bottom Shell Size
3.18±0.20
2.77
A
Top/Bottom Connector Type
P/P - (Plug/Plug)
P/P
P/S - (Plug/Receptacle)
P/S
S/S - (Receptacle/Receptacle)
S/S
S/P
S/P - (Receptacle/Plug)
8.00± 0.25
16.00± 0.25
5.9 Plug,
6.0 Socket
4-40 UNC
threaded insert
8.36
±
0.13 Plug
A
A - .750” (Standard)
B - .900" (not available with E15/15)
B
C - .625”
Center to Center Distance
7.90
±
0.13 Socket
Board Locks Option
8.08
14.84
2.84
Blank
- No Board Lock
4N - Board Locks (Standard )
4N
8.00
2.84
4-Ø3.05
1.385
Ø1.09
8.00
B
Blank
- No Jack Screws
J - 4-40 HEX Removable Jack Screws
R
R
- 4-40 Round Riveted Jack Screws
Jack Screws Option
1.16
2.84
8.08
(Top Front View)
Recommended PCB Layout
Number of
Contacts
(Shell Size)
9 (E)
15 (A)
25 (B)
37 (C)
Dimensions (Inch/
mm)
A
.643
16.33
.971
24.66
1.511
38.38
2.159
54.84
A1
.666
16.92
.994
25.25
1.534
38.96
2.181
55.42
D
.750
19.05
.900
22.86
.625
15.88
B
.984
24.99
1.312
33.32
1.852
47.04
2.500
63.50
C
1.213
30.81
1.541
39.14
2.088
53.04
2.729
69.32
E
1.244
31.60
1.394
35.41
1.119
28.42
Plating Option
Blank
- Gold Flash
Blank
15
- 15µ” Gold
15
30
- 30µ” Gold
30
Contact Kycon for HighTemp and other options
Center to Center Spacing
A
B
C
A = Exterior of Female Shell (S) A1 = Interior of Male Shell (P)
Click here for Performance Specification
2009
KYCON, Inc. • Tel: +1 408-494-0330 • US: 1-888-KYCON-22 • Fax: +1 408-494-0325 • www.Kycon.Com
