PLB2800 Overview

Configurable Ethernet Switch-on-a-Chip

Preview

Download Datasheet

View All

RODUCT

RIEF

Infineon's Purple (PLB 2800) is a highly integrated

and configurable Layer 2+ SoC (Switch-on-a-Chip).

It extends Infineon's Layer 2 Ethernet switch family

of products for higher integration, and more

advanced traffic management. The Purple’s versa-

tile configuration and stacking options permit a

variety of system topologies designed to increase

the deployment of Ethernet access applications.

The Purple features a large on-chip packet buffer

and address tables. With the addition of an on-chip

64-bit MIPS CPU, the need for an external memory

and controller is eliminated.

Advanced security and Quality of Service (QoS)

features are guaranteed using extensive VLAN

management capabilities and port-based security

for guarded and secure handling of traffic flows.

The Purple supports seven different configura-

tions, ranging from eight GbE ports up to

48FE + 2GbE.

Applications

■

Ethernet access switch for

IP-DSLAM/DLC/MDU/MTU

■

High port count workgroup switch

■

GbE aggregator Ethernet Switch

■

Cellular base stations

■

Packet over SONET/SDH

systems

Features

■

21 Gbit/s 12 million packets/

second switching engine for solid

L2+ wirespeed switching

performance

■

Embedded 64-bit MIPS 5Kc CPU

■

On-chip DRAM, SRAM

■

Stackable with up to 16 Purple

switches with complete stack

management

■

Four Class of Service (CoS)

queues per port

■

Strict priority and Weighted-Fair-

Queuing (WFQ) packet

scheduling

Advanced buffer control

Broadcast and multicast storm

control

Multicast support for up to

256 multicast groups

Port based flow control

Per-flow token bucket policing

Per-queue rate shaping

Port, tag and flow-based VLANs

Stacked VLAN support

Port-based security

Intrusion detection

eCPU switch management with

Bus mastering capabilities, flow-

based accounting and RMON

support

Hardware assistance for protocols

such as STP, GVRP and IGMP

and Snooping

Interfaces

■

SMII V1.2/V2.1 for FE ports

■

(R)GMII/TBI/MII for GE ports

■

32-Bit, 66 MHz PCI or generic

host bus with DMA support

■

I C Interface for configuration

EEPROM, optional low-cost CPU

■

PC-133 SDRAM interface for

external CPU DRAM

■

EJTAG Interface for testing

■

General purpose timer and I/Os

Standards Supported

■

Supports a wide variety of IEEE

802.xx protocols

■

IETF RFCs 1155–1157 SNMP

■

IETF RFCs 1213, 1643, 1493

■

IETF RFC 1757 RMON

Physical Characteristics

■

P-BGA-388-2 package

■

Core logic operates at 1.8 V

Purple

48FE+2GbE/8GbE L2+

Configurable Ethernet

Switch-on-a-Chip

PLB 2800

N e v e r

s t o p

t h i n k i n g .
