BC184_L34Z datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > semiconductor> Discrete semiconductor> BC184_L34Z

BC184_L34Z: Descriptiontransistor npn 30v 500ma TO-92; Categorysemiconductor Discrete semiconductor; File Size99KB，3 Pages; ManufacturerFairchild; Websitehttp://www.fairchildsemi.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

BC184_L34Z Overview

transistor npn 30v 500ma TO-92

BC184_L34Z Parametric

Parameter Name	Attribute value
Datasheets
BC184
Product Photos
TO-92-3(StandardBody),TO-226_straightlead
Standard Package	2,000
Category	Discrete Semiconductor Products
Family	Transistors (BJT) - Single
Packaging	Bulk
Transistor Type	NPN
Current - Collector (Ic) (Max)	100mA
Voltage - Collector Emitter Breakdown (Max)	30V
Vce Saturation (Max) @ Ib, Ic	600mV @ 5mA, 100mA
Current - Collector Cutoff (Max)	-
DC Current Gain (hFE) (Min) @ Ic, Vce	130 @ 100mA, 5V
Power - Max	350mW
Frequency - Transiti	150MHz
Mounting Type	Through Hole
Package / Case	TO-226-3, TO-92-3 (TO-226AA)
Supplier Device Package	TO-92-3

Preview

Download Datasheet

View All

BC184 — Silicon NPN Small Signal Transistor

September 2007

BC184

Silicon NPN Small Signal Transistor

• BV

CEO

= 30V (Min.)

• h

= 130 (Min.) @V

= 5.0V, I

= 100mA

TO-92

1. Collector 2. Base 3. Emitter

Absolute Maximum Ratings

=25°C unless otherwise noted

Symbol

CEO

CBO

EBO

, T

STG

Collector-Emitter Voltage

Collector-Base Voltage

Emitter-Base Voltage

Collector Current (DC)

Operating and Storage Junction Temperature Range

Parameter

Value

100

-55 ~ +150

Units

°C

* These ratings are limiting values above which the serviceability of any semiconductor device may be impaired.

NOTES:

1) These ratings are based on a maximum junction temperature of 150 degrees C.

2) These are steady state limits. The factory should be consulted on applications involving pulsed or low duty cycle operations.

Thermal Characteristics

Symbol

θJC

θJA

=25°C unless otherwise noted

Parameter

Total Device Dissipation

Derate above 25°C

Thermal Resistance, Junction to Case

Thermal Resistance, Junction to Ambient

Max.

350

2.8

125

357

Units

mW/°C

°C/W

*Device mounted on FR-4 PCB 1.6” X 1.6” X 0.06”.

BC184 Rev. 1.0.0

www.fairchildsemi.com

BC184_L34Z Related Products

	BC184_L34Z	BC184_J35Z	BC184_D27Z	BC184-D27Z
Description	transistor npn 30v 500ma TO-92	trans SS npn 30v 100ma TO-92	transistor npn 30v 500ma TO-92	Transistor
Standard Package	2,000	2,000	2,000	-
Category	Discrete Semiconductor Products	Discrete Semiconductor Products	Discrete Semiconductor Products	-
Family	Transistors (BJT) - Single	Transistors (BJT) - Single	Transistors (BJT) - Single	-
Packaging	Bulk	Bulk	Tape & Reel (TR)	-
Transistor Type	NPN	NPN	NPN	-
Current - Collector (Ic) (Max)	100mA	100mA	100mA	-
Voltage - Collector Emitter Breakdown (Max)	30V	30V	30V	-
Vce Saturation (Max) @ Ib, Ic	600mV @ 5mA, 100mA	600mV @ 5mA, 100mA	600mV @ 5mA, 100mA	-
DC Current Gain (hFE) (Min) @ Ic, Vce	130 @ 100mA, 5V	130 @ 100mA, 5V	130 @ 100mA, 5V	-
Power - Max	350mW	350mW	350mW	-
Frequency - Transiti	150MHz	150MHz	150MHz	-
Mounting Type	Through Hole	Through Hole	Through Hole	-
Package / Case	TO-226-3, TO-92-3 (TO-226AA)	TO-226-3, TO-92-3 (TO-226AA)	TO-226-3, TO-92-3 (TO-226AA) Formed Leads	-
Supplier Device Package	TO-92-3	TO-92-3	TO-92-3	-
