5175474-9 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> 5175474-9

5175474-9: Descriptionconn champ rcpt 80pos .050 R/A; CategoryThe connector; File Size231KB，1 Pages; ManufacturerAll Sensors; Environmental Compliance

Download Datasheet Parametric Compare View All

5175474-9 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	5175474-9	-	-	View	Buy Now

5175474-9 Overview

conn champ rcpt 80pos .050 R/A

5175474-9 Parametric

Parameter Name	Attribute value
Datasheets
5175474
CHAMP Series I Appl Spec
Product Photos
5175474-9
RoHS Informati
5175474-9 Statement of Compliance
RoHS 2 Stateme
3D Model
5175474-9.pdf
5175474-9.igs
5175474-9.s
Standard Package	700
Category	Connectors, Interconnects
Family	D-Shaped Connectors - Centronics
Connector Style	Outer Shroud Contacts
Connector Type	Receptacle
Number of Positions	80
Number of Rows	2
Mounting Type	Through Hole, Right Angle
Terminati	Solde
Flange Feature	-
Type	Board to Board, High Density
Features	Board Lock
Contact Finish	Gold
Contact Finish Thickness	8µin (0.20µm)
Mating Products	5-5917593-9-ND - CONN PLUG 80POS .050 R/A5-917593-9-ND - CONN PLUG 80POS .050 R/A5-5175472-9-ND - CONN CHAMP PLUG 80POS .050 R/AA33457-ND - .050CL,CHAMP,VERT PLUG,80 POSN

Preview

Download Datasheet

View All

5175474-9 Related Products

	5175474-9	3-5175474-3	5175474-5	5-5175474-3	5175474-1	5-5175474-1	5-5175474-6	5175474-4	5175474-8
Description	conn champ rcpt 80pos .050 R/A	champ 050 B/B rec H W/leg 30p	conn champ rcpt .050 R/A	conn champ rcpt 30pos .050 R/A	conn champ rcpt 20pos .050 R/A	.050cl champ rtang rcpt 20 pos	conn recept .050 50pos R/A 30au	conn champ rcpt 36pos .050 R/A	conn champ rcpt 68pos .050 R/A
Standard Package	700	1,500	1	1,500	1,900	1,900	1,000	1,300	800
Category	Connectors, Interconnects	Connectors, Interconnects	Connectors, Interconnects	Connectors, Interconnects	Connectors, Interconnects	Connectors, Interconnects	Connectors, Interconnects	Connectors, Interconnects	Connectors, Interconnects
Family	D-Shaped Connectors - Centronics	D-Shaped Connectors - Centronics	D-Shaped Connectors - Centronics	D-Shaped Connectors - Centronics	D-Shaped Connectors - Centronics	D-Shaped Connectors - Centronics	D-Shaped Connectors - Centronics	D-Shaped Connectors - Centronics	D-Shaped Connectors - Centronics
Connector Style	Outer Shroud Contacts	Outer Shroud Contacts	Outer Shroud Contacts	Outer Shroud Contacts	Outer Shroud Contacts	Outer Shroud Contacts	Outer Shroud Contacts	Outer Shroud Contacts	Outer Shroud Contacts
Connector Type	Receptacle	Receptacle	Receptacle	Receptacle	Receptacle	Receptacle	Receptacle	Receptacle	Receptacle
Number of Positions	80	50	50	30	20	20	50	36	68
Number of Rows	2	2	2	2	2	2	2	2	2
Mounting Type	Through Hole, Right Angle	Through Hole, Right Angle	Through Hole, Right Angle	Through Hole, Right Angle	Through Hole, Right Angle	Through Hole, Right Angle	Through Hole, Right Angle	Through Hole, Right Angle	Through Hole, Right Angle
Terminati	Solde	Solde	Solde	Solde	Solde	Solde	Solde	Solde	Solde
Type	Board to Board, High Density	Board to Board, High Density	Board to Board, High Density	Board to Board, High Density	Board to Board, High Density	Board to Board, High Density	Board to Board	Board to Board, High Density	Board to Board, High Density
Features	Board Lock	Board Lock	Board Lock	Board Lock	Board Lock	Board Lock	Board Lock	Board Lock	Board Lock
Contact Finish	Gold	Gold	Gold	Gold	Gold	Gold	Gold	Gold	Gold
Contact Finish Thickness	8µin (0.20µm)	8µin (0.20µm)	8µin (0.20µm)	30µin (0.76µm)	8µin (0.20µm)	30µin (0.76µm)	30µin (0.76µm)	8µin (0.20µm)	8µin (0.20µm)
Mating Products	5-5917593-9-ND - CONN PLUG 80POS .050 R/A5-917593-9-ND - CONN PLUG 80POS .050 R/A5-5175472-9-ND - CONN CHAMP PLUG 80POS .050 R/AA33457-ND - .050CL,CHAMP,VERT PLUG,80 POSN	-	-	5-5175473-3-ND - CONN CHAMP PLUG 30POS .050 VERT5-5175472-3-ND - CONN CHAMP PLUG 30POS .050 R/A3-5175472-3-ND - CONN CHAMP PLUG 30POS .050 R/A1734100-3-ND - CONN PLUG 30POS VERT .050 T/H	5175472-1-ND - CONN CHAMP PLUG 20POS .050 R/A	A115408-ND - CONN CHAMP PLUG 20POS .050 R/A1734100-2-ND - CONN PLUG 20POS VERT .050 T/HA33453-ND - .050CL CHAMP VERT PLUG 20 POS	A101947-ND - CONN PLUG 50POS VERT .050 T/HA33462-ND - PLUG ASSY,R/A,50POSN,CHAMP 050A33455-ND - .050CL,CHAMP,VERT PLUG,50 POSN	5175472-4-ND - CONN CHAMP PLUG 36POS .050 R/A	5175473-8-ND - CONN CHAMP PLUG 68POS .050 VERT
