5120527-2 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> 5120527-2

5120527-2: Descriptionconn plug 84pos 1mm FH vert; CategoryThe connector; File Size141KB，1 Pages; ManufacturerAll Sensors; Environmental Compliance

Download Datasheet Parametric Compare View All

5120527-2 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	5120527-2	-	-	View	Buy Now

5120527-2 Overview

conn plug 84pos 1mm FH vert

5120527-2 Parametric

Parameter Name	Attribute value
Datasheets
5120527
Product Photos
51205xx-2
RoHS Informati
5120527-2 Statement of Compliance
RoHS 2 Stateme
Featured Produc
TE Connectivity - Free Height Connectors for Parallel Board Stacking Applications
3D Model
5120527-2.pdf
Standard Package	800
Category	Connectors, Interconnects
Family	Rectangular - Board to Board Connectors - Arrays, Edge Type, Mezzanine
Packaging	Tape & Reel (TR)
Connector Type	Plug, Center Strip Contacts
Number of Positions	84
Pitch	0.039" (1.00mm)
Number of Rows	2
Mounting Type	Surface Mou
Features	Board Guide
Contact Finish	Gold
Contact Finish Thickness	30µin (0.76µm)
Mated Stacking Heights	10mm, 12mm, 13mm, 15mm
Height Above Board	0.329" (8.35mm)
Mating Products	A116268TR-ND - CONN RCPT 84POS 1MM FH VERTA111222TR-ND - CONN RCPT 84POS DUAL 1.0MM VERTA111221TR-ND - CONN RCPT 84POS DUAL 1.0MM VERT5146896-2-ND - CONN RCPT 84POS 1MM FH VERT5146895-2-ND - CONN RCPT 84POS 1MM FH VERT5146894-2-ND - CONN RCPT 84POS 1MM FH VERT5146893-2-ND - CONN RCPT 84POS 1MM FH VERTA111230TR-ND - CONN RCPT 84POS 1MM FH VERT5120530-2-ND - CONN RCPT 84POS 1MM FH VERT5120529-2-ND - CONN RCPT 84POS 1MM FH VERTA111227TR-ND - CONN RCPT 84POS 1MM FH VERT
Other Names	5120527-2-NDA111225TR

Preview

Download Datasheet

View All

5120527-2 Related Products

	5120527-2	1-5120527-1	2-5120527-2	1-5120527-2
Description	conn plug 84pos 1mm FH vert	conn plug 64pos 1mm FH vert	conn recpt 84pos	conn plug 84pos 1mm FH vert
Standard Package	800	800	800	800
Category	Connectors, Interconnects	Connectors, Interconnects	Connectors, Interconnects	Connectors, Interconnects
Family	Rectangular - Board to Board Connectors - Arrays, Edge Type, Mezzanine	Rectangular - Board to Board Connectors - Arrays, Edge Type, Mezzanine	Rectangular - Board to Board Connectors - Arrays, Edge Type, Mezzanine	Rectangular - Board to Board Connectors - Arrays, Edge Type, Mezzanine
Packaging	Tape & Reel (TR)	Tape & Reel (TR)	Tape & Reel (TR)	Tape & Reel (TR)
Connector Type	Plug, Center Strip Contacts	Plug, Center Strip Contacts	Plug, Center Strip Contacts	Plug, Center Strip Contacts
Number of Positions	84	64	84	84
Pitch	0.039" (1.00mm)	0.039" (1.00mm)	0.039" (1.00mm)	0.039" (1.00mm)
Number of Rows	2	2	2	2
Mounting Type	Surface Mou	Surface Mou	Surface Mou	Surface Mou
Features	Board Guide	Board Guide	Board Guide	Board Guide
Contact Finish	Gold	Gold	Gold	Gold
Contact Finish Thickness	30µin (0.76µm)	30µin (0.76µm)	30µin (0.76µm)	30µin (0.76µm)
Mated Stacking Heights	10mm, 12mm, 13mm, 15mm	10mm, 12mm, 13mm, 15mm	10mm, 12mm, 13mm, 15mm	10mm, 12mm, 13mm, 15mm
Height Above Board	0.329" (8.35mm)	0.329" (8.35mm)	0.329" (8.35mm)	0.329" (8.35mm)
