8
THIS DRAWING IS UNPUBLISHED.
RELEASED FOR PUBLICATION
-
ALL RIGHTS RESERVED.
7
20
6
5
4
3
2
LOC
DIST
1
C
COPYRIGHT
20
CM
00
REVISIONS
P
LTR
DESCRIPTION
DATE
DWN
APVD
R1
REVISED PER ECR-18-004355
18JUN2018
BDA
SG
G
W
1
2
POST WITHSTAND 13 NEWTONS (3 LBS) MIN AXIAL FORCE
IN DIRECTION SHOWN WITHOUT DISLODGING.
MEASURED AT
-A- .
D
D
2.87
[ .113 ]
2
3. PARTS COMPLY WITH SOLDERABILITY SPEC 109-11-2.
4
MATERIAL:
HOUSING: NYLON, 4/6, HIGH TEMP, BLACK..
POST - COPPER ALLOY (SEE TABLE FOR PLATING).
COORDINATE DIMENSION APPLIES FROM CENTER OF ACTUAL FEATURE.
POSTS TO BE MEASURED WHEN STRIP HELD FLAT.
5
6
7. DIMENSIONS IN BRACKETS ARE IN INCHES.
R 0.038[.015]
1.4
[ .055 ]
8
(L)
12
6.35
[ .250 ]
PLATING: GOLD PLATE AREA, 0.00038 [.000015] GOLD OR
0.00008 [.000003] MIN GOLD FLASH OVER 0.00030 [.000012]
PALLADIUM NICKEL, PER TE CONNECTIVITY'S DISCRETION,
ALL SIDES, OVER NICKEL UNDERPLATE, 0.00127 [.000050] MIN,
ALL SIDES AND ENTIRE LENGTH OF POST.
BRIGHT TIN/LEAD (93/7) PLATE AREA,0.00381-0.00889
[.000150-.000350] THICK, ALL FOUR SIDES, 3.56[.140] MIN.
TOLERANCES APPLY TO SOLDER SIDE OF BOARD.
ONE HOLE MAY BE UNDERSIZED 0.81-0.90 [.032-.035] DIAMETER
FOR ASSEMBLY RETENTION DURING PROCESSING.
TE LOGO,UL,AND CSA TRADEMARKS TO APPEAR ON THIS SURFACE.
MATTE TIN PLATE AREA,0.00381-0.00889
[.000150-.000350] THICK, ALL FOUR SIDES, 3.56[.140] MIN.
OBSOLETE PARTS: OBSOLETE CIS STREAMLINING PER D.RENAUD/D.SINISI
TYPICAL END VIEW
FOR -2 THRU -7
9
10
11
12
13
ALL POSTS
14
0.25 [.010] m
C
A
0.64-1.02
[.025-.040]
C
ALL POSTS
1
TYP
8
7.49±0.25
[.295±.010]
8.81 0.25
[ .347 .010 ]
-A-
13.97
[ .550
0.25
.010 ]
3.18
[ .125 ]
0.64 # 0.03
[.025 # .001]
SQUARE TYP
B
6
2
6
1
TYP
2.54
[ .100 ]
TYP
5
1.27
[ .050 ]
( 3.43
)
[ .135 ]
B
9
13
2.54
TYP
[ .100 ]
0.20[.008] MIN. THK.
SOLDER PASTE IN
AREA SHOWN
7.62 [.300]
-
-
-
-
8
13
12.70 [.500]
10.16 [.400]
7.62 [.300]
5.08 [.200]
2.54 [.100]
-
-
-
-
-
-
30.48
27.94
25.40
22.86
20.32
17.78
15.24
12.70
10.16
[ 1.200 ]
[ 1.100 ]
[ 1.000 ]
[ .900 ]
[ .800 ]
[ .700 ]
[ .600 ]
[ .500 ]
[ .400 ]
12
11
10
9
8
7
6
5
4
3
2
4-647078-2
4-647078-1
4-647078-0
3-647078-9
3-647078-8
3-647078-7
3-647078-6
3-647078-5
3-647078-4
3-647078-3
1.52
[ .060 ]
PRE-TINNED LAND
BOTH SIDES TYP
-
-
-
-
-
-
1.02 0.07
[ .040 .003 ]
PRE-TINNED PLATED
THRU HOLE TYP
11
7.62
[ .300 ]
14
14
7.62 [ .300 ]
5.08 [ .200 ]
SUPERCEDED BY 4-647078-2
SUPERCEDED BY 4-647078-1
SUPERCEDED BY 4-647078-0
SUPERCEDED BY 3-647078-9
SUPERCEDED BY 3-647078-8
SUPERCEDED BY 3-647078-7
SUPERCEDED BY 3-647078-6
8
9
7.62 [.300]
-
-
12.70 [.500]
10.16 [.400]
5.08 [.200]
2.54 [.100]
-
-
-
-
-
7.62 [.300]
30.48
27.94
25.40
[ 1.200 ]
[ 1.100 ]
[ 1.000 ]
[ .900 ]
[ .800 ]
[ .700 ]
[ .600 ]
[ .500 ]
[ .400 ]
12
11
10
9
8
7
6
5
4
3
2
3-647078-2
1-647078-2
1-647078-1
1-647078-0
647078-9
647078-8
647078-7
647078-6
647078-5
647078-4
647078-3
PART NO
A
3.81
[ .150 ]
14
14
14
14
14
-
-
-
-
-
-
22.86
20.32
17.78
15.24
12.70
10.16
A
14
14
SUPERCEDED BY 3-647078-3
SUPERCEDED BY 3-647078-2
POST
FINISH
-
-
W
-
G
7.62 [ .300 ]
L
5.08 [ .200 ]
0.826
[ .0325 ]
1.65
[ .065 ]
RECOMMENDED MOUNTING HOLE PATTERN
FOR 1.57 # 0.20[.062 # .008] THICK P.C. BOARD
10
NO OF
POSN
647078-2
THIS DRAWING IS A CONTROLLED DOCUMENT.
DIMENSIONS:
TOLERANCES UNLESS
OTHERWISE SPECIFIED:
mm[INCHES]
MATERIAL
-
0 PLC
1 PLC
2 PLC
3 PLC
4 PLC
ANGLES
FINISH
4
-
-
-
0.38[.015]
-
-
0 $ 30'
01NOV2001
K. WHITAKER
CHK
01NOV2001
D. BOSSI
APVD
01NOV2001
D. BOSSI
DWN
PRODUCT SPEC
APPLICATION SPEC
TE Connectivity
-
-
MTA-100 HEADER ASSY,HIGH TEMPERATURE
FRICTION LOCK,.025 SQUARE,
STRAIGHT POST,.000015 GOLD
NAME
4
WEIGHT
-
CUSTOMER DRAWING
A0
SIZE
CAGE CODE
DRAWING NO
RESTRICTED TO
00779
647078
SCALE
4806 (3/11)
10:1
SHEET
1
OF
1
REV
R1
