High Density Card Edge
1.00 mm [.039”] Contact Centers, 21.84 mm [.860”] Insulator Height,
Right Angle
SPECIFICATIONS
High Density Card Edge
•
•
•
•
•
•
•
Accommodates 1.57 mm ± 0.20 mm [.062” ± .008”] PC board
PA9T or PPS insulator
Molded-in key available
High reliability/high cycle hairpin bellow contacts
1 Amp current rating per contact for contacts fully energized
150 grams normal force minimum
UL Flammability Rating: 94V-0
READOUT
TERMINATION TYPE
9.40 [.370”]
15.11
[.595”]
3X 2.00 [.079”]
DUAL (D)
HA = 2.54 ± 0.64
[.100” ± .025”]
HB = 4.32 ± 0.64
[.170” ± .025”]
PCB LAYOUT
2.00 [0.079”]
1.00 [0.039”]
3X 2.00 [0.079”]
PIN A1
3.00 [0.118”]
PIN A2
F
A
Ø 1.02 [0.040”]MIN.
2X Ø 2.64 [0.104”]MIN.
FOR 'R' MOUNTING
2X Ø 3.18 [0.125”]
FOR 'S' MOUNTING
2.79 [0.110”]
PIN B1
PIN B2
D
MOUNTING STYLE
Ø 3.18 [.125”]
Ø 3.18 [.125”]
#4-40
6.35 [.250”]
4.41 [.174”]
BOARD LOCK (R)
(with no mounting ears)
SIDE MOUNTING (S)
NO MOUNTING EARS (N)
6.35 [.250”]
6.35 [.250”]
CLEARANCE HOLE (D)
THREADED INSERT (T)
10
www.sullinscorp.com
|
760-744-0125
|
toll-free 888-774-3100
|
fax 760-744-6081
|
info@sullinscorp.com
PART NUMBER OPTIONS
1.00 mm [.039”] Contact Centers
, 21.84 mm [.860”] Insulator Height,
Right Angle
G B E 50 D HA D - Sxxx
MODIFICATION CODE
(Consult Factory)
OMIT FOR STANDARD
MOUNTING STYLE (Opposite Page
)
D =
Flush Mounting
N =
No Mounting
R
=
Metal Board Lock
S
=
Side Mounting
T
=
Flush Mounting -Threaded Insert
TERMINATION TYPE (Opposite Page)
HA
= 2.54 mm [.100”] Tail Length
HB = 4.32 mm [.170”] Tail Length
READOUT (Opposite Page)
D
= Dual
High Density Card Edge
MATERIALS (INSULATOR/CONTACT)
G
=
PA9T/Phosphor Bronze
R
=
PPS/Phosphor Bronze
J =
PA9T/Beryllium Copper
A =
PPS/Beryllium Copper
Refer to Page 7 for Operating/Processing Temperatures
CONTACT FINISH - RoHS Compliant
All platings are Lead Free and have .000050” Nickel underplate
High Density Card Edge
Contact Surface
B
=
.000010” Gold
C
=
.000030” Gold
Termination
.000100” Pure Tin, Matte
.000100” Pure Tin, Matte
CONTACT CENTERS
E
= 1 mm [.039”]
NUMBER OF CONTACT POSITIONS
See Chart Below
DIMENSIONS
Dimensions in [ ] are in inches, all others are in millimeters.
PIN A1
FIRST POSITION
INDICATOR
9.40
[.370]
PIN B1
PIN B2
A
B
D
E
0.36 X 0.30 [.014 X .012] POST
REFER TO TERMINATION TYPE
4X Ø 3.18 [.125]
PIN A2
9.14[.360]
21.84
[.860]
6.35
[.250]
1.00
[.039],TYP.
F
1.90
[.075]
MAX.
6.35
[.250]
MIN.
C
7.62[.300]
PAD WIDTH
0.76[.030]
2X R 0.76
[. 030]MAX.
7.62
[.300]
MIN.
1.00[.039]
A
(B - 0.36 [.014])
±0.13[.005]
0.51
[.020]
60°
1.57 ± 0.20
[.062 ± .008]
(S) MOUNTING SHOWN
POSITIONS/
CONTACTS
02/04*
03/06*
04/08*
05/10
06/12*
07/14*
08/16*
09/18*
10/20
11/22*
12/24
13/26*
14/28*
15/30
16/32
17/34*
18/36*
19/38*
20/40
21/42*
22/44*
23/46*
24/48*
25/50
26/52*
27/54*
28/56*
29/58*
30/60
31/62*
32/64*
33/66*
34/68*
35/70
36/72*
37/74*
38/76*
39/78*
40/80
41/82*
42/84*
43/86*
44/88*
45/90
46/92*
47/94*
48/96*
49/98*
50/100
MILLIMETERS
A±0.13
1.00
2.00
3.00
4.00
5.00
6.00
7.00
8.00
9.00
10.00
11.00
12.00
13.00
14.00
15.00
16.00
17.00
18.00
19.00
20.00
21.00
22.00
23.00
24.00
25.00
26.00
27.00
28.00
29.00
30.00
31.00
32.00
33.00
34.00
35.00
36.00
37.00
38.00
39.00
40.00
41.00
42.00
43.00
44.00
45.00
46.00
47.00
48.00
49.00
INCHES
E±0.51
25.13
26.13
27.13
28.13
29.13
30.13
31.13
32.13
33.13
34.13
35.13
36.13
37.13
38.13
39.13
40.13
41.13
42.13
43.13
44.13
45.13
46.13
47.13
48.13
49.13
50.13
51.13
52.13
53.13
54.13
55.13
56.13
57.13
58.13
59.13
60.13
61.13
62.13
63.13
64.13
65.13
66.13
67.13
68.13
69.13
70.13
71.13
72.13
73.13
B±0.13
4.32
5.32
6.32
7.32
8.32
9.32
10.32
11.32
12.32
13.32
14.32
15.32
16.32
17.32
18.32
19.32
20.32
21.32
22.32
23.32
24.32
25.32
26.32
27.32
28.32
29.32
30.32
31.32
32.32
33.32
34.32
35.32
36.32
37.32
38.32
39.32
40.32
41.32
42.32
43.32
44.32
45.32
46.32
47.32
48.32
49.32
50.32
51.32
52.32
C±0.38
9.89
10.89
11.89
12.89
13.89
14.89
15.89
16.89
17.89
18.89
19.89
20.89
21.89
22.89
23.89
24.89
25.89
26.89
27.89
28.89
29.89
30.89
31.89
32.89
33.89
34.89
35.89
36.89
37.89
38.89
39.89
40.89
41.89
42.89
43.89
44.89
45.89
46.89
47.89
48.89
49.89
50.89
51.89
52.89
53.89
54.89
55.89
56.89
57.89
D±0.25
17.15
18.15
19.15
20.15
21.15
22.15
23.15
24.15
25.15
26.15
27.15
28.15
29.15
30.15
31.15
32.15
33.15
34.15
35.15
36.15
37.15
38.15
39.15
40.15
41.15
42.15
43.15
44.15
45.15
46.15
47.15
48.15
49.15
50.15
51.15
52.15
53.15
54.15
55.15
56.15
57.15
58.15
59.15
60.15
61.15
62.15
63.15
64.15
65.15
F±0.25
5.25
6.25
7.25
8.25
9.25
10.25
11.25
12.25
13.25
14.25
15.25
16.25
17.25
18.25
19.25
20.25
21.25
22.25
23.25
24.25
25.25
26.25
27.25
28.25
29.25
30.25
31.25
32.25
33.25
34.25
35.25
36.25
37.25
38.25
39.25
40.25
41.25
42.25
43.25
44.25
45.25
46.25
47.25
48.25
49.25
50.25
51.25
52.25
53.25
A±.005
0.039
0.079
0.118
0.157
0.197
0.236
0.276
0.315
0.354
0.394
0.433
0.472
0.512
0.551
0.591
0.630
0.669
0.709
0.748
0.787
0.827
0.866
0.906
0.945
0.984
1.024
1.063
1.102
1.142
1.181
1.220
1.260
1.299
1.339
1.378
1.417
1.457
1.496
1.535
1.575
1.614
1.654
1.693
1.732
1.772
1.811
1.850
1.890
1.929
B±.005
0.170
0.210
0.249
0.288
0.328
0.367
0.407
0.446
0.485
0.525
0.564
0.603
0.643
0.682
0.722
0.761
0.800
0.840
0.879
0.918
0.958
0.997
1.037
1.076
1.115
1.155
1.194
1.233
1.273
1.312
1.351
1.391
1.430
1.470
1.509
1.548
1.588
1.627
1.666
1.706
1.745
1.785
1.824
1.863
1.903
1.942
1.981
2.021
2.060
C±.015
0.389
0.429
0.468
0.507
0.547
0.586
0.626
0.665
0.704
0.744
0.783
0.822
0.862
0.901
0.941
0.980
1.019
1.059
1.098
1.137
1.177
1.216
1.256
1.295
1.334
1.374
1.413
1.452
1.492
1.531
1.570
1.610
1.649
1.689
1.728
1.767
1.807
1.846
1.885
1.925
1.964
2.004
2.043
2.082
2.122
2.161
2.200
2.240
2.279
D±.010
0.675
0.715
0.754
0.793
0.833
0.872
0.912
0.951
0.990
1.030
1.069
1.108
1.148
1.187
1.227
1.266
1.305
1.345
1.384
1.423
1.463
1.502
1.542
1.581
1.620
1.660
1.699
1.738
1.778
1.817
1.856
1.896
1.935
1.975
2.014
2.053
2.093
2.132
2.171
2.211
2.250
2.290
2.329
2.368
2.408
2.447
2.486
2.526
2.565
E±.020
0.989
1.029
1.068
1.107
1.147
1.186
1.226
1.265
1.304
1.344
1.383
1.422
1.462
1.501
1.541
1.580
1.619
1.659
1.698
1.737
1.777
1.816
1.856
1.895
1.934
1.974
2.013
2.052
2.092
2.131
2.170
2.210
2.249
2.289
2.328
2.367
2.407
2.446
2.485
2.525
2.564
2.604
2.643
2.682
2.722
2.761
2.800
2.840
2.879
F±.010
0.207
0.246
0.285
0.325
0.364
0.404
0.443
0.482
0.522
0.561
0.600
0.640
0.679
0.719
0.758
0.797
0.837
0.876
0.915
0.955
0.994
1.033
1.073
1.112
1.152
1.191
1.230
1.270
1.309
1.348
1.388
1.427
1.467
1.506
1.545
1.585
1.624
1.663
1.703
1.742
1.781
1.821
1.860
1.900
1.939
1.978
2.018
2.057
2.096
* Consult factory for availability.
