793DX-CTC3-CTC4
www.vishay.com
Vishay Sprague
Solid Tantalum Surface Mount Chip Capacitors
T
ANTAMOUNT
™, Molded Case, CECC Approved
FEATURES
•
CECC
30801/005 - 793DX
Available
30801/009 - CTC3
30801/011 - CTC4
Available
Terminations: 100 % matte tin standard,
tin / lead available
Molded case available in four case codes
Available
Compatible with “high volume” automatic pick
and place equipment
Optical character recognition qualified
Compliant terminations
Moisture sensitivity level 1
Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
•
•
•
LINKS TO ADDITIONAL RESOURCES
D
D
3
3
3D Models
Calculators
T
Related
Documents
Did You
Know
Technical
Notes
•
•
•
•
PERFORMANCE / ELECTRICAL
CHARACTERISTICS
www.vishay.com/doc?40192
Operating Temperature:
-55 °C to +125 °C
(above 85 °C, voltage derating is required)
Capacitance Range:
0.10 μF to 100 μF
Capacitance Tolerance:
± 10 %, ± 20 %
Voltage Rating:
4 V
DC
to 50 V
DC
Note
• For recommended voltage derating guidelines see “Typical
Performance Characteristics”
Note
*
This datasheet provides information about parts that are
RoHS-compliant and / or parts that are non RoHS-compliant. For
example, parts with lead (Pb) terminations are not RoHS-compliant.
Please see the information / tables in this datasheet for details
APPLICATIONS
• Military / aerospace
• General purpose
ORDERING INFORMATION
793DX
TYPE
CTC3
CTC4
106
CAPACITANCE
X0
CAPACITANCE
TOLERANCE
X9 = ± 10 %
X0 = ± 20 %
010
DC VOLTAGE RATING
AT +85 °C
This is expressed in V. To
complete the three-digit
block, zeros precede the
voltage rating. A decimal
point is indicated by an “R”
(6R3 = 6.3 V).
B
CASE CODE
See Ratings
and Case
Codes table.
2WE3
TERMINATION
AND PACKAGING
Matte tin
2TE3
= 7" (178 mm) reel
2WE3
= 13" (330 mm) reel
Tin / lead
8T
= 7" (178 mm) reel
8W
= 13" (330 mm) reel
This is expressed in
picofarads. The first
two digits are the
significant figures.
The third is the
number of zeros
to follow.
Note
• We reserve the right to supply higher voltage ratings and tighter capacitance tolerance capacitors in the same case size.
Voltage substitutions will be marked with the higher voltage rating
Revision: 22-Oct-2020
Document Number: 40112
1
For technical questions, contact:
tantalum@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
793DX-CTC3-CTC4
www.vishay.com
Vishay Sprague
DIMENSIONS
in inches [millimeters]
L
W
T
H
(MIN.)
Glue Pad
H
Glue Pad
P
T
W
CASE CODE
A
B
C
D
EIA SIZE
3216-18
3528-21
6032-28
7343-31
L
0.126 ± 0.008
[3.2 ± 0.20]
0.138 ± 0.008
[3.5 ± 0.20]
0.236 ± 0.012
[6.0 ± 0.30]
0.287 ± 0.012
[7.3 ± 0.30]
W
0.063 ± 0.008
[1.6 ± 0.20]
0.110 ± 0.008
[2.8 ± 0.20]
0.126 ± 0.012
[3.2 ± 0.30]
0.170 ± 0.012
[4.3 ± 0.30]
H
0.063 ± 0.008
[1.6 ± 0.20]
0.075 ± 0.008
[1.9 ± 0.20]
0.098 ± 0.012
[2.5 ± 0.30]
0.110 ± 0.012
[2.8 ± 0.30]
P
0.031 ± 0.012
[0.80 ± 0.30]
0.031 ± 0.012
[0.80 ± 0.30]
0.051 ± 0.012
[1.3 ± 0.30]
0.051 ± 0.012
[1.3 ± 0.30]
T
W
0.047 ± 0.004
[1.2 ± 0.10]
0.087 ± 0.004
[2.2 ± 0.10]
0.087 ± 0.004
[2.2 ± 0.10]
0.095 ± 0.004
[2.4 ± 0.10]
T
H
(MIN.)
0.028
[0.70]
0.028
[0.70]
0.039
[1.0]
0.039
[1.0]
Note
• Glue pad (non-conductive, part of molded case) is dedicated for glue attachment (as user option)
RATINGS AND CASE CODES
RATED VOLTAGE U
R
(V) (+85 °C)
C
R
(μF)
4V
6.3 V
10 V
16 V
20 V
25 V
35 V
50 V
CATEGORY VOLTAGE U
C
(V) (+125 °C)
2.7 V
4V
7V
10 V
13 V
17 V
23 V
A
A
A
A
A
A
A
A
A
A
B
B
B
C
C
C
D
D
D
D
D
D
D
D
C
D
D
C
D
D
B
C
B
B
B
B
B
C
C
C
D
D
D
33 V
A
B
B
B
B
C
C
D
D
D
D
0.10
0.15
0.22
0.33
0.47
0.68
1.0
1.5
2.2
3.3
4.7
6.8
10
15
22
33
47
68
100
Revision: 22-Oct-2020
Document Number: 40112
2
For technical questions, contact:
tantalum@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
793DX-CTC3-CTC4
www.vishay.com
Vishay Sprague
MARKING
“A” CASE VOLTAGE CODE
Capacitance code,
pF
Date code
designation
Indicates
lead (Pb)-free
VOLTS
4.0
6.3
10
16
20
CODE
G
J
A
C
D
E
V
T
Polarity
band (+)
Voltage
Capacitance
μF
Indicates
lead (Pb)-free
V 104L
22
XX
Data code
10L
2
Vishay marking
Polarity
band (+)
Voltage
code
25
35
50
A Case
B, C, D Case
Marking:
Capacitor marking includes an anode (+) polarity band, capacitance in microfarads and the voltage rating. “A” case size capacitors use a
letter code for the voltage and EIA capacitance code.
The Vishay identification is shown if space permits. Capacitors rated at 6.3 V shall be marked 6 V.
Uppercase letter “L” indicates lead (Pb)-free capacitors.
A manufacturing date code is marked on all capacitors, for details see FAQ:
www.vishay.com/doc?40110.
Call the factory for further explanation.
STANDARD RATINGS
CAPACITANCE
(μF)
CASE
CODE
MAX. DC
MAX. DF
MAX. ESR
LEAKAGE
AT +25 °C
AT +25 °C
PART NUMBER
AT +25 °C
(%)
100 kHz ()
(μA)
4 V
DC
AT +85 °C; 2.7 V
DC
AT +125 °C
793DX335(1)004A(2)
0.5
6
7.6
CTC3335(1)004A(2)
0.5
6
7.6
CTC4335(1)004A(2)
0.5
6
7.6
793DX106(1)004B(2)
0.5
6
3.5
CTC3106(1)004B(2)
0.5
6
3.5
CTC4106(1)004B(2)
0.5
6
3.5
793DX336(1)004C(2)
1.3
6
1.8
CTC3336(1)004C(2)
1.3
6
1.8
CTC4336(1)004C(2)
1.3
6
1.8
793DX686(1)004D(2)
2.7
6
0.8
CTC3686(1)004D(2)
2.7
6
0.8
CTC4686(1)004D(2)
2.7
6
0.8
793DX107(1)004D(2)
4.0
6
0.7
CTC3107(1)004D(2)
4.0
6
0.7
CTC4107(1)004D(2)
4.0
6
0.7
6.3 V
DC
AT +85 °C; 4 V
DC
AT +125 °C
793DX225(1)6R3A(2)
0.5
6
7.6
CTC3225(1)6R3A(2)
0.5
6
7.6
CTC4225(1)6R3A(2)
0.5
6
7.6
793DX685(1)6R3B(2)
0.5
6
3.4
CTC3685(1)6R3B(2)
0.5
6
3.4
CTC4685(1)6R3B(2)
0.5
6
3.4
793DX226(1)6R3C(2)
1.3
6
1.8
CTC3226(1)6R3C(2)
1.3
6
1.8
CTC4226(1)6R3C(2)
1.3
6
1.8
793DX476(1)6R3D(2)
2.8
6
0.8
CTC3476(1)6R3D(2)
2.8
6
0.8
CTC4476(1)6R3D(2)
2.8
6
0.8
793DX686(1)6R3D(2)
4.1
6
0.7
CTC3686(1)6R3D(2)
4.1
6
0.7
CTC4686(1)6R3D(2)
4.1
6
0.7
IMPEDANCE (Z)
AT +25 °C
100 kHz
()
9.0
9.0
9.0
4.5
4.5
4.5
2.4
2.4
2.4
1.3
1.3
1.3
1.0
1.0
1.0
10.0
10.0
10.0
4.5
4.5
4.5
2.4
2.4
2.4
1.3
1.3
1.3
1.0
1.0
1.0
MAX. RIPPLE
100 kHz
I
RMS
(A)
0.10
0.10
0.10
0.12
0.12
0.12
0.25
0.25
0.25
0.43
0.43
0.43
0.46
0.46
0.46
0.10
0.10
0.10
0.16
0.16
0.16
0.25
0.25
0.25
0.43
0.43
0.43
0.46
0.46
0.46
3.3
3.3
3.3
10
10
10
33
33
33
68
68
68
100
100
100
2.2
2.2
2.2
6.8
6.8
6.8
22
22
22
47
47
47
68
68
68
A
A
A
B
B
B
C
C
C
D
D
D
D
D
D
A
A
A
B
B
B
C
C
C
D
D
D
D
D
D
Note
• Part number definitions:
(1) Tolerance: X0, X9
(2) Terminations and packaging: 2TE3, 2WE3, 8T, 8W
Revision: 22-Oct-2020
Document Number: 40112
3
For technical questions, contact:
tantalum@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
