EURO
QUARTZ
7.0 x 5.0 x 1.8mm 6 pad SMD
Industry-standard 7 x 5mm 6 pad SMD package
Frequency range 625kHz to 50.0MHz
CMOS/TTL Output
Supply Voltage 1.8, 2.5, 3.3 or 5.0VDC
Integrated Phase Jitter 1ps maximum
G576 VCXO
625.0kHz ~ 50.0MHz
Page 1 of 2
DESCRIPTION & APPLICATIONS
G576 VCXOs are packaged in the industry-standard 7 x 5 x1.8mm 6
pad SMD package. G series VCXOs use fundamental mode crystal
oscillators for low phase noise. Applications include phase lock loop,
SONET/ATM, set-top boxes, MPEG , audio/video modulation, video
game consoles, Fibre Channel, FPGAs, Data Acquisition and HDTV.
SUPPLY VOLTAGE-DEPENDENT SPECIFICATION
Input Voltage (Vdd):
Frequency Range*:
Output Waveform:
Initial Frequency Accuracy:
TTL:
Output Logic HIGH '1'
CMOS:
TTL:
Output Logic LOW '0'
Frequency Deviation Range:
Control Voltage Centre
Control Voltage Range:
GENERAL SPECIFICATION
Frequency Stability:
Frequency Change
vs. Input Voltage:
Input Voltage:
Output Load
TTL:
CMOS:
Rise/Fall Time
TTL:
CMOS:
Duty Cycle:
Integrated Phase Jitter:
Period Jitter RMS:
Period Jitter Peak to Peak:
Start-up time:
Current Consumption:
6ns max, 4ns typ. (0.4V to 2.4V)
6ns max, 4ns typ. (20%~80% Vdd)
50±10% standard, 50±5% option
1ps maximum (12kHz to 20MHz)
2.0ps typical
14ps
10ms max., 3ms typical
10 to 45mA, frequency dependant
(27MHz: 10mA typical at 3.3V,
20mA typical at 5.0VDC)
6% typical, 10% maximum
10kHz min., measured at Vcont =
1.65V or2.5V.
1MΩ typical
Monotonic and Positive, increasing
control voltage increases output
frequency.
±3ppm per year maximum
RoHS Compliant and lead (Pb) free
No connection to Tris-State pad or
Vdd -0.5V min. is applied.
Tri-State pad grounded or +0.5V
max. is applied.
2TTL gates
15pF
OUTLINE & DIMENSIONS
±5ppm max. (V
DD
±5%)
+1.8V±5%, +2.5V±5%,
+3.3V±5% or 5.0V±10%
CMOS:
Vdd = +1.8VDC ±5% Vdd = +2.5VDC ±5% Vdd = +3.3VDC ±5% Vdd = +5.0VDC ±10%
16.0MHz ~ 50.0MHz
TTL/CMOS
To tune to nominal fr.
with Vc=0.9±0.15V
----
1.62V (min.)
----
0.183V (max.)
Standard: ±80ppm
(min.)
0.9VDC
0V to 1.8V
0.625MHz ~ 50.0MHz
TTL/CMOS
To tune to nominal fr.
with Vc=1.25±0.2V
----
2.25V (min.)
----
0.25V (max.)
Standard: ±80ppm
(min.)
1.25VDC
0.25V to 2.25V
0.625MHz ~ 50.0MHz
TTL/CMOS
To tune to nominal fr.
with Vc=1.65±0.2V
2.4V (min.)
2.97V (min.)
0.4V (max.)
0.33 (max.)
Standard: ±80ppm
(min.)
1.62VDC
0.3V to 3.0V
1.0MHz ~ 50.0MHz
TTL/CMOS
To tune to nominal fr.
with Vc=2.5±0.2V
2.4V (min.)
4.5V (min.)
0.4V (max.)
0.5V (max.)
Std: ±80ppm (min.)
±200ppm available
2.5VDC
0.5V to 4.5V
Linearity:
Modulation Bandwidth:
Input Impedance:
Slope Polarity:
Ageing:
RoHS Status:
Tri-State
Enable:
Disable:
EUROQUARTZ LIMITED Blacknell Lane CREWKERNE Somerset UK TA18 7HE
Tel: +44 (0)1460 230000 Fax: +44 (0)1460 230001 info@euroquartz.co.uk www.euroquartz.co.uk
EURO
QUARTZ
7.0 x 5.0 x 1.8mm 6 pad SMD
G576 VCXO
625.0kHz ~ 50.0MHz
Page 2 of 2
PHASE NOISE
27.0MHz
3.3V supply
Offset:
10Hz
-40dBc/Hz
100Hz
-104dBc/Hz
1kHz
-132dBc/Hz
10kHz
-147dBc/Hz
100kHz
-152dBc/Hz
1MHz
-150dBc/Hz
FREQUENCY STABILITY OVER OPERATING TEMPERATURE RANGE PART NUMBER CODES
Stability
Commercial 'C'
-10° to +70°C
Industrial 'I'
-40° to +85°C
±25ppm
A
D
±50ppm
B
E
±100ppm
C
F
PART NUMBERING PROCEDURE
Example = 3G576B-80N-27.000
3 G576 B - 80 N - 27.000
Supply Voltage
18 = +1.8V
25 = +2.5V
3 = +3.3V
5 = +5.0V
Part Type Code
G576
Stability over temperature range
A, B, C, D, E or F
(See table above)
Pulling Range ±ppm
Pull Range Determinator
M = Maximum
N = Minimum
T = Typical
(Tolerance is ±20%)
Centre Frequency in MHz
EUROQUARTZ LIMITED Blacknell Lane CREWKERNE Somerset UK TA18 7HE
Tel: +44 (0)1460 230000 Fax: +44 (0)1460 230001 info@euroquartz.co.uk www.euroquartz.co.uk
