A4942: Three-Phase Sensorless Fan Driver
The A4942 three phase motor driver incorporates BEMF sensing to eliminate the requirement for Hall sensors
in fan applications.
A closed loop speed control system is integrated into the IC. This allows accurate setting of maximum and
minimum speeds via selection of external resistors. The speed is controlled by duty cycle demand applied to
the PWM input.
The PWM input is allowed to operate over a wide frequency range.
Current limiting is integrated to allow saving the cost and PCB space of an external sense resistor. The current
limit function includes an adjustable soft start to minimize load on the power supply while the fan is ramping up
to speed.
The A4942 is supplied in a 20-contact 4 mm × 4 mm QFN package (suffix ES) with exposed pad for enhanced
thermal dissipation. The package is lead (Pb) free, with 100% matte tin leadframe plating.
DATASHEETS
Contact Your Local Sales Rep
SAMPLE & BUY
Contact Your Local Sales Rep
RECEIVE PRODUCT ALERTS
We'll notify you when there are
updates to his product.
Sign Up
Product Image
Sensorless (no Hall sensors required)
Closed loop speed control
Minimal external components
PWM speed input
FG speed output
Lock detection
Soft start
Overcurrent protection
Soft switching for reduced aud ble noise
Click the image to view larger
1
2
Part Number Specifications and Availability
Part Number
Package Type
Temperature
RoHS
Compliant
Part Composition /
RoHS Data
Comments
Samples
Check
Distributor Stock
Check
Distributor Stock
A4942GESTR-T
20-lead QFN
-40 ° C to 105 ° C
Yes
View Data
New
Contact your
local sales rep
