DUAL-IN-LINE SOCKETS
Clinch Pin
Open Frame
•
Special lock-down feature
prevents floating of socket
during soldering.
•
Open insulator with
ladder construction.
•
Sockets are XY stackable.
•
Socket pins feature closed
end construction eliminat-
ing any solder wicking
problems.
Series 101
Total number
of pins
Quantity
per tube
Ordering Information
A
0.3
0.4
0.7
0.8
0.9
1.0
1.2
1.4
1.1
1.2
1.4
1.6
2.0
2.4
3.2
B
0.3
0.3
0.3
0.3
0.3
0.3
0.3
0.3
0.4
0.6
0.6
0.6
0.6
0.6
0.9
C
0.4
0.4
0.4
0.4
0.4
0.4
0.4
0.4
0.5
0.7
0.7
0.7
0.7
0.7
1.0
67
50
28
25
22
20
16
14
18
16
14
12
10
8
6
For RoHS compliance,
select plating code.
For the all gold option
(XX=13) also change
part number from
101-XX-XXX-41-56X000
to
101-13-XXX-41-56X100
6
8
14
16
18
20
24
28
22
24
28
32
40
48
64
101-XX-306-41-56X000
XX= Plating Code
See Below
101-XX-308-41-56X000
101-XX-314-41-56X000
101-XX-316-41-56X000
101-XX-318-41-56X000
101-XX-320-41-56X000
101-XX-324-41-56X000
101-XX-328-41-56X000
101-XX-422-41-56X000
101-XX-624-41-56X000
101-XX-628-41-56X000
101-XX-632-41-56X000
101-XX-640-41-56X000
101-XX-648-41-56X000
101-XX-964-41-56X000
Clinch Pins:
Two Opposite Corner Pins
X = 0
Four Corner Pins
X = 8
SPECIFY PLATING CODE XX=
13
10μ” Au
30μ” Au
91
10μ” Au
93
30μ” Au
99
200μ” Sn/Pb
41
200μ” Sn
10μ” Au
43
200μ” Sn
30μ” Au
44
200μ”Sn
200μ” Sn
Sleeve (Pin)
Contact (Clip)
200μ” Sn/Pb
200μ” Sn/Pb
200μ”Sn/Pb
